Contact us to receive an offer.
| Manufacturer | MAZAK |
|---|---|
| Model | SLANT TURN 35 ATC |
| Year | 1989 |
| Location | France
|
MAZAK SLANT TURN 35 ATC — CNC Turning/Milling Center (model year 1989)
Overview
This MAZAK Slant Turn 35 ATC is a slant-bed CNC turning/milling center configured with a single turret and an automatic tool changer layout. It is equipped with a conversational Mazatrol T32-3 CNC control and supports both Mazatrol and ISO (EIA) programming formats.
Key specifications (as listed)
- Manufacturer: MAZAK
- Model: SLANT TURN 35 ATC
- Year manufactured: 1989
- Turning diameter (Turning Ø): 450 mm
- Turning length: 1,000 mm
- Length between centers: 1,500 mm
- X-axis travel: 338 mm
- Z-axis travel: 1,538 mm
- Spindle bore: 70 mm
- Number of turrets: 1
- Number of tools on turret: 12
- Maximum spindle speed (turning speed): 3,000 rpm
Features and equipment (from listing)
- Mazatrol T32-3 conversational CNC control
- 12-station/12-position turret with motorized/rotating tool capability
- C-axis capability
- Programmable tailstock
- 3-jaw hydraulic chuck
- Rotating/motorized tooling provision
- Chip conveyor
- Coolant system
- Foot controls
Documentation and inspection
The listing indicates original documentation is available. Condition and operational status should be confirmed with the seller prior to purchase; prospective buyers are advised to request further details, current photos, run/demonstration proof, and to arrange an inspection or testing as needed.
Notes
All technical values above are taken from the provided listing fields. Serial number, seller contact details and location have been omitted. If you would like, I can help draft specific questions to ask the seller (for example about recent maintenance, spindle condition, tooling included, or control memory/backups).
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
MAZAK SLANT TURN 35 ATC – CNC Turning/Milling Center
Manufacturer: Mazak
Model: Slant Turn 35 ATC
Year: 1989
Serial Number: 085891
CNC Control: Mazatrol T32-3
Technical Specifications
12-station turret
Motorized tools
C-axis
Programmable tailstock
3-jaw hydraulic chuck
Spindle bore: approx. Ø 70 mm
Spindle nose: A2-8
Turning diameter: up to 300 mm
Diameter over bed: 460 mm
Turning length: 1,000 mm
Travel: X 335 mm / Z 1,538 mm
Spindle speed: up to 3,000 rpm
Equipment
Mazatrol T32-3 conversational control
Mazatrol and ISO (EIA) programming
Rotating tools
Chip conveyor
Coolant system
Foot controls
Power supply
380 V three-phase
Weight
Approximately 5,000 kg (to be confirmed based on the machine’s exact configuration).
Condition
Machine is in working order; can be viewed while powered on.
Sold to upgrade the machine fleet.
All original documentation is available.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Factory – small or medium company |
| Active since | 2026 |
| Offers online | 2 |
| Last activity | Oct. 24, 2026 |
MAZAK SLANT TURN 35 ATC – CNC Turning/Milling Center
Manufacturer: Mazak
Model: Slant Turn 35 ATC
Year: 1989
Serial Number: 085891
CNC Control: Mazatrol T32-3
Technical Specifications
12-station turret
Motorized tools
C-axis
Programmable tailstock
3-jaw hydraulic chuck
Spindle bore: approx. Ø 70 mm
Spindle nose: A2-8
Turning diameter: up to 300 mm
Diameter over bed: 460 mm
Turning length: 1,000 mm
Travel: X 335 mm / Z 1,538 mm
Spindle speed: up to 3,000 rpm
Equipment
Mazatrol T32-3 conversational control
Mazatrol and ISO (EIA) programming
Rotating tools
Chip conveyor
Coolant system
Foot controls
Power supply
380 V three-phase
Weight
Approximately 5,000 kg (to be confirmed based on the machine’s exact configuration).
Condition
Machine is in working order; can be viewed while powered on.
Sold to upgrade the machine fleet.
All original documentation is available.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
MAZAK SLANT TURN 35 ATC — CNC Turning/Milling Center (model year 1989)
Overview
This MAZAK Slant Turn 35 ATC is a slant-bed CNC turning/milling center configured with a single turret and an automatic tool changer layout. It is equipped with a conversational Mazatrol T32-3 CNC control and supports both Mazatrol and ISO (EIA) programming formats.
Key specifications (as listed)
- Manufacturer: MAZAK
- Model: SLANT TURN 35 ATC
- Year manufactured: 1989
- Turning diameter (Turning Ø): 450 mm
- Turning length: 1,000 mm
- Length between centers: 1,500 mm
- X-axis travel: 338 mm
- Z-axis travel: 1,538 mm
- Spindle bore: 70 mm
- Number of turrets: 1
- Number of tools on turret: 12
- Maximum spindle speed (turning speed): 3,000 rpm
Features and equipment (from listing)
- Mazatrol T32-3 conversational CNC control
- 12-station/12-position turret with motorized/rotating tool capability
- C-axis capability
- Programmable tailstock
- 3-jaw hydraulic chuck
- Rotating/motorized tooling provision
- Chip conveyor
- Coolant system
- Foot controls
Documentation and inspection
The listing indicates original documentation is available. Condition and operational status should be confirmed with the seller prior to purchase; prospective buyers are advised to request further details, current photos, run/demonstration proof, and to arrange an inspection or testing as needed.
Notes
All technical values above are taken from the provided listing fields. Serial number, seller contact details and location have been omitted. If you would like, I can help draft specific questions to ask the seller (for example about recent maintenance, spindle condition, tooling included, or control memory/backups).
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
