With their capacity to carry out intricate milling and machining operations on five axes simultaneously, 5-axis machining centres have completely changed the metalworking sector. In comparison to conventional 3-axis machines, these cutting-edge machines provide simultaneous 5-axis machining, increased accuracy, more adaptability, and less tool wear. 5-axis machining centres enable the production of complex geometries, multi-sided components, and higher surface finishes in a single setup by removing the need for several setups and part repositioning.
5-axis machining centres are excellent in producing components with complicated geometries, such as turbine blades, orthopaedic implants, and complex automotive parts, making them ideal for sectors like aerospace, automotive, medical, and energy. When thinking about purchasing one, it is important to carefully examine variables including machine size, spindle power, tool capacity, and control system.
Showing 1 - 20 out of 616
France
2019
| Axis X | 762 mm |
|---|---|
| Axis Z | 507 mm |
| Type | Continuous |
| Table length | 630 mm |
| Max. part weight | 300 kg |
| Spindle taper | CT 40 |
| Spindle motor power | 22.4 kW |
| Axis Y | 508 mm |
|---|---|
| Type | Vertical |
| CNC | |
| Table width | 500 mm |
| Number of tool pockets | 40 |
| Max. spindle speed | 15000 rpm |
France
2018
| Axis X | 600 mm |
|---|---|
| Axis Z | 750 mm |
| Type | Continuous |
| Max. part weight | 400 kg |
| Spindle taper | HSK-A63 |
| Spindle motor power | 39 kW |
| Axis Y | 855 mm |
|---|---|
| Type | Horizontal |
| CNC | SIEMENS 840D sl |
| Number of tool pockets | 60 |
| Max. spindle speed | 21000 rpm |
| Axis X | 1800 mm |
|---|---|
| Axis Z | 1100 mm |
| Table length | 1700 mm |
| Max. part weight | 5000 kg |
| Spindle taper | |
| Spindle motor power | 44 kW |
| Axis Y | 2000 mm |
|---|---|
| CNC | Heidenhain TNC 430 |
| Table width | 1400 mm |
| Number of tool pockets | 60 |
| Max. spindle speed | 10000 rpm |
Germany
2006
| Axis X | 1600 mm |
|---|---|
| Axis Z | 1000 mm |
| Table length | 1500 mm |
| Max. part weight | 4000 kg |
| Spindle taper | |
| Spindle motor power | 44 kW |
| Axis Y | 1250 mm |
|---|---|
| CNC | CNC0684 |
| Table width | 1250 mm |
| Number of tool pockets | 60 |
| Max. spindle speed | 10000 rpm |
Germany
2012
| Axis X | 1250 mm |
|---|---|
| Axis Z | 620 mm |
| Table length | 1350 mm |
| Max. part weight | 1000 kg |
| Spindle taper | SK 40 |
| Spindle motor power | 22 kW |
| Axis Y | 620 mm |
|---|---|
| CNC | Heidenhain ITCN530 |
| Table width | 620 mm |
| Number of tool pockets | 60 |
| Max. spindle speed | 15000 rpm |
| Axis X | 500 mm |
|---|---|
| Axis Z | 400 mm |
| CNC | Heidenhain iTNC 530 |
| Table length | 500 mm |
| Max. part weight | 200 kg |
| Spindle taper | |
| Spindle motor power | 35 kW |
| Axis Y | 450 mm |
|---|---|
| Type | Vertical |
| Type of axis | 1x head + 1x bed |
| Table width | 380 mm |
| Number of tool pockets | 30 |
| Max. spindle speed | 18000 rpm |
| Number of pallets | 1 |
Switzerland
2005
| Axis X | 600 mm |
|---|---|
| Axis Z | 450 mm |
| Table width | 450 mm |
| Number of tool pockets | 220 |
| Max. spindle speed | 20000 rpm |
| Axis Y | 450 mm |
|---|---|
| CNC | HEIDENHAIN ITNC 530 |
| Max. part weight | 200 kg |
| Spindle taper |
Germany
2009
| Axis X | 800 mm |
|---|---|
| Axis Z | 800 mm |
| Table length | 800 mm |
| Max. part weight | 1000 kg |
| Spindle taper | hska 100 |
| Spindle motor power | 44 kW |
| Axis Y | 800 mm |
|---|---|
| CNC | siemens 840d powerline |
| Table width | 630 mm |
| Number of tool pockets | 180 |
| Max. spindle speed | 10000 rpm |
| Number of pallets | 2 |
| Axis X | 200 mm |
|---|---|
| Axis Z | 280 mm |
| Table length | 200 mm |
| Spindle taper |
| Axis Y | 220 mm |
|---|---|
| CNC | |
| Max. part weight | 15 kg |
| Max. spindle speed | 42000 rpm |
Taiwan
2013
| Axis X | 800 mm |
|---|---|
| Axis Z | 650 mm |
| CNC | |
| Table width | 800 mm |
| Spindle taper | CAT40 / HSK A63 (depending on configuration) |
| Spindle motor power | 44 kW |
| Axis Y | 950 mm |
|---|---|
| Type | Vertical |
| Table length | 800 mm |
| Number of tool pockets | 60 |
| Max. spindle speed | 12000 rpm |
| Number of pallets | 1 |
Switzerland
2005
| Axis X | 600 mm |
|---|---|
| Axis Z | 450 mm |
| Table length | 450 mm |
| Number of tool pockets | 220 |
| Max. spindle speed | 20000 rpm |
| Axis Y | 450 mm |
|---|---|
| CNC | HEIDENHAIN ITNC 530 |
| Max. part weight | 200 kg |
| Spindle taper |
Germany
2011
| Axis X | 550 mm |
|---|---|
| Axis Z | 500 mm |
| Type | Continuous |
| Type of axis | Tilting bed |
| Table width | 500 mm |
| Number of tool pockets | 323 |
| Max. spindle speed | 20000 rpm |
| Number of pallets | 1 |
| Axis Y | 1000 mm |
|---|---|
| Type | Vertical |
| CNC | FANUC Professional 5 |
| Table length | 500 mm |
| Max. part weight | 350 kg |
| Spindle taper | |
| Spindle motor power | 25 kW |
Germany
2005
| Axis X | 1400 mm |
|---|---|
| Axis Z | 1200 mm |
| Table length | 800 mm |
| Number of tool pockets | 140 |
| Max. spindle speed | 10000 rpm |
| Axis Y | 1200 mm |
|---|---|
| CNC | fanuc 18 imb mapps2 |
| Table width | 800 mm |
| Spindle taper | bt 50 |
| Number of pallets | 2 |
| Axis X | 500 mm |
|---|---|
| Axis Z | 400 mm |
| Type | Continuous |
| Type of axis | 1x head + 1x bed |
| Table width | 400 mm |
| Number of tool pockets | 30 |
| Max. spindle speed | 10000 rpm |
| Axis Y | 450 mm |
|---|---|
| Type | Vertical |
| CNC | Heidenhain iTNC 530 - ERGOline |
| Table length | 500 mm |
| Max. part weight | 200 kg |
| Spindle taper | |
| Spindle motor power | 13 kW |
| Axis X | 685 mm |
|---|---|
| CNC | FANUC FS-31iA5 |
| Spindle taper | |
| Spindle motor power | 18.5 kW |
| Axis Y | 125 mm |
|---|---|
| Number of tool pockets | 12 |
| Max. spindle speed | 12000 rpm |
| Axis X | 120 mm |
|---|---|
| Axis Z | 200 mm |
| Table length | 190 mm |
| Number of tool pockets | 27 |
| Max. spindle speed | 40000 rpm |
| Axis Y | 120 mm |
|---|---|
| CNC | Siemens Sinumerik 840D |
| Max. part weight | 10 kg |
| Spindle taper | HSK-32 |
| Axis X | 200 mm |
|---|---|
| Axis Z | 280 mm |
| Table length | 200 mm |
| Max. part weight | 15 kg |
| Spindle taper |
| Axis Y | 220 mm |
|---|---|
| CNC | HEIDENHAIN iTNC530 |
| Table width | 200 mm |
| Number of tool pockets | 60 |
| Max. spindle speed | 42000 rpm |
Switzerland
2003
| Axis X | 3500 mm |
|---|---|
| Axis Z | 1400 mm |
| Max. part weight | 4000 kg |
| Spindle taper | ISO SK 50 |
| Axis Y | 1200 mm |
|---|---|
| CNC | HEIDENHAIN ITNC 530 |
| Number of tool pockets | 30 |
| Max. spindle speed | 4000 rpm |
Switzerland
2009
| Axis X | 200 mm |
|---|---|
| Axis Z | 280 mm |
| Number of tool pockets | 60 |
| Max. spindle speed | 42000 rpm |
| Axis Y | 200 mm |
|---|---|
| CNC | HEIDENHAIN ITNC 530 |
| Spindle taper | hsk e32 |
Switzerland
2002
| Axis X | 1940 mm |
|---|---|
| Axis Z | 700 mm |
| Table length | 1800 mm |
| Max. part weight | 3500 kg |
| Spindle taper | hsk e63 |
| Spindle motor power | 150 kW |
| Axis Y | 1200 mm |
|---|---|
| CNC | FANUC 18 M |
| Table width | 1120 mm |
| Number of tool pockets | 32 |
| Max. spindle speed | 15000 rpm |
A 5-axis machining centre is a computer numerical control (CNC) machine that can perform complex milling and machining operations on five different axes simultaneously. Unlike traditional 3-axis machines, which can only move in the X, Y, and Z planes, 5-axis machines can also rotate around the A and B axes. This additional range of motion allows for greater flexibility and precision when manufacturing intricate parts and components.
Simultaneous 5-Axis Machining: The ability to cut and shape material along five axes simultaneously results in reduced setup times, enhanced precision, and superior surface finishes. This capability is particularly advantageous when manufacturing complex, contoured parts that require multiple setups on a conventional 3-axis machine.
Improved Accuracy: By eliminating the need for multiple setups and part repositioning, 5-axis machining centres minimize the potential for human error and inconsistencies in the final product. This translates to higher quality, more accurate parts, and reduced scrap rates.
Enhanced Versatility: The advanced motion capabilities of 5-axis machines allow for the creation of highly intricate geometries and multi-sided parts in a single setup. This versatility enables manufacturers to take on a broader range of projects and expand their offerings to customers.
Reduced Tool Wear: The simultaneous movement of the cutting tool and workpiece in a 5-axis machining centre reduces the overall stress on the tool, resulting in less wear and longer tool life. This can lead to significant cost savings over time.
Such machining centres have found applications in various industries, including aerospace, automotive, medical, and energy. They are particularly well-suited for manufacturing components with complex geometries, such as:
When considering machine, it is essential to evaluate factors such as machine size, spindle power, tool capacity, and control system. Additionally, it is crucial to consider the level of after-sales support and training provided by the machine's manufacturer. By carefully weighing these factors, engineers, manufacturers, and buyers can make informed decisions that maximize their return on investment.
DMG MORI: A German-Japanese company producing a wide range of advanced machining centers, including 5-axis machines, for various industries.
Haas Automation: An American manufacturer offering a diverse lineup of 5-axis machining centers, known for their affordability and quality.
Mazak Corporation: A Japanese company with a long history of producing high-quality, innovative CNC machines, including multi-tasking and 5-axis machining centers.
Okuma: A Japanese company with a global presence, renowned for its state-of-the-art machining centers that cater to a wide range of industries and applications.
Hermle: A German manufacturer with a reputation for producing high-precision 5-axis machining centers, often used in the aerospace and automotive industries.
Hurco: An American company specializing in CNC machine tools, including a range of 5-axis machining centers designed for high-speed and high-precision operations.
GF Machining Solutions: A Swiss manufacturer offering a comprehensive portfolio of advanced machining centers, including 5-axis machines, for various industries.
Matsuura: A Japanese manufacturer known for producing high-quality, high-speed 5-axis machining centers with a focus on automation and advanced technology.
Mikron: A Swiss company that manufactures high-performance milling machines and machining centers, including a variety of 5-axis models suitable for various industries.
Chiron: A German company specializing in CNC vertical machining centers, offering 5-axis machines designed for high-speed and precision manufacturing.
Makino: A Japanese manufacturer with a long-standing reputation for producing advanced CNC machine tools, including a range of high-quality 5-axis machining centers.
The price range can vary significantly depending on factors such as the machine's size, features, capabilities, brand, and age (new vs. used). As a rough estimate, 5-axis machining centers can typically cost anywhere from 150 000€ to over 1 million €.
Entry-level or smaller ones may start around 150 000€ to 250,000€, while mid-range models with more features and capabilities can range from 250 000€ to 600 000€. High-end, large-scale 5-axis machines with advanced functionalities and specialized features can easily exceed 600 000€, with some machines reaching prices over 1 million €.
It's important to note that these price ranges are general estimates, and the actual cost of a specific machine can vary based on the manufacturer, model, and any additional features or accessories included. When considering a purchase, it's crucial to weigh the machine's capabilities and features against its price to determine the best fit for your specific needs and budget. Additionally, it's essential to factor in ongoing costs such as maintenance, tooling, and software when evaluating the overall investment.
Focussing on a range of price for used machine, you can count between 50 000€ and 190 000€
You can always use our pricing Algorithm Valorexo to pinpoint a fair market price.
Please make sure you agree on all the details with the seller or ask your Exapro Agent for support.
