Price on request
View price| Metal length | 3000 mm |
| Power | 3000 W |
| Metal width | 1500 mm |
| Type | Fiber |
| Option to cut tubes | yes |
| Max thickness | 22 mm |
| CNC | yes |
| CNC type | |
| Travel X | 3000 mm |
| Travel Y | 1500 mm |
| Max weight of the workpiece | 1200 kg |
| ------------------- | |
| worked hours | |
| hours under power | |
| state | new |
| At local norms | --------- |
| status | in production |
| Last availability date | 14/05/2026 |
The Otinus FLV-3015-OT-6023 fiber laser cutting machine is designed for precision cutting of metal sheets up to 3000 x 1500 mm in size, with a maximum cutting thickness of 22 mm for carbon steel. It features a powerful 3000 W fiber laser source and supports a maximum workpiece weight of 1200 kg. The machine offers a travel range of 3000 mm in the X-axis and 1500 mm in the Y-axis, ensuring versatility for various cutting tasks.
Constructed with a robust welded frame and massive legs, this laser cutter provides stability during operation. It is equipped with Fuji Japanese servo drives and a bevel rack and pinion drive system, delivering high-speed performance and exceptional cutting accuracy. The cutting head uses a RayTools auto-focus system to optimize cut quality.
A notable feature is the rotary tube cutting attachment on the left side, enabling the cutting of cylindrical and rectangular sections with precise positioning relative to the laser head. This attachment facilitates complex cuts through edges of tubes and profiles.
User convenience is enhanced by ball transfer units embedded in the cutting surface, allowing heavy metal plates to be moved smoothly during loading. Additionally, waste collection drawers beneath the machine aid in easy collection and removal of small cut parts.
The control panel, mounted on an adjustable arm on the right side, includes a screen with a Windows-based system and CypCut software for part programming, file import/export, and adjustment of power and cutting speed. The laser head can also be operated via a wireless remote control.
Safety features include emergency lights and an audible alarm system to alert operators to hazardous conditions. The machine is delivered with a Specialist Assistance Package, providing expert guidance on CAD drawings, material selection, and operating parameters. Buyers also receive one year of access to the Otinus Academy e-learning platform and a free comprehensive set of ready-to-use CAD drawings for immediate cutting applications.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Specifications
-Maximum sheet size: 3000 x 1500 mm
-Max section height: 230 mm
-Max section length: 6000 mm
-X/Y positioning accuracy: ±0.05 mm/m
-X/Y positioning repeatability: ±0.03 mm
-Maximum travel speed: 60000 mm/min
-Maximum acceleration: 0.7 G
-Maximum load: 1200 kg
-Motor power output: 4.0 kW
-Energy consumption: 15.0 kW
-Source brand: Raycus or MAX Photonics to choose from
-Input voltage: ~3×400 V 50 Hz
-Ingress protection rating: IP54
Cutting thickness
-Carbon steel: recommended thickness 20.0 mm, maximum thickness 22.0 mm
-Stainless steel: recommended thickness 8.0 mm, maximum thickness 10.0 mm
-Aluminum: recommended thickness 6.0 mm, maximum thickness 8.0 mm
-Brass: recommended thickness 5.0 mm, maximum thickness 6.0 mm
Structure
The machine is very stable due to its welded structure on massive legs. Fuji Japanese servo drives with robust bevel rack and pinion drive ensure high speed and exceptional accuracy of the cutting head.
Tube cutting attachment
The machine is equipped with a rotary tube cutting attachment to position a section relative to the laser head. This solution allows for easy cutting of circular or rectangular sections including cuts passing through edges.
The ABL system automatically replenishes the grease in the rails.
User-friendliness
The fiber laser cutter is fully adapted to the needs of the user, ensuring maximum comfort during its operation. The heavy plates are made easier to handle with ball transfer units embedded in the surface, allowing the plates to roll smoothly during loading. Collecting small parts is much easier thanks to the waste collection trolleys, which can be pulled out using a convenient handle.
RayTools cutting head with auto-focus.
Control panel
The control of the fiber laser occurs is carried out via the control panel with keyboard and mouse. The computer includes the Windows system and CypCut software, which comes with functions such as:
-part programming,
-file import and export,
-adjustment of power output and cutting speed.
Installed software has lifetime licenses
Wireless remote
The control of the laser head is carried out by a wireless remote control.
Safety
The fiber laser cutting machine is delivered with all necessary measures to ensure the safety of users. Emergency lights with an audible alarm system activate in situations that compromise user safety, alerting to the danger.
Assistance by a specialist
We strive to maintain constant communication with our Customers. To support this, each purchased machine includes a Specialist Assistance Package with dedicated hours of expert guidance.
Within the service, our technicians may:
-Prepare or redesign CAD drawings,
-Advise on material and gas selection,
-Assist in the selection of operating parameters for different materials.
The remaining time can be checked in the Otinus Customer Panel.
Otinus Academy
This is an ever-growing e-learning platform created for Otinus brand customers. By purchasing this machine, you'll receive one year's access to online courses, allowing you to easily train a new employee or refresh your training knowledge!
Free drawing package
Each Otinus laser cutter includes a comprehensive set of ready-to-use CAD drawings. The designs included are ready-made as they can be immediately cut in any format. Our technician will show you how to do that during training. The drawings will be useful to anyone who wants to make various types of decorative items.
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
| Client type | Machinery manufacturer |
| Active since | 2025 |
| Offers online | 25 |
| Last activity | June 3, 2026 |
Otinus Polska Sp. z o.o. is one of Poland’s most trusted names in metalworking machinery, offering cutting-edge solutions under the Otinus brand. With over a decade of experience and a strong in-house production setup, Otinus delivers reliable and efficient machines tailored for today’s industrial needs—ranging from fiber laser cutters and plasma machines to press brakes, shears, and machining centers.
What sets Otinus apart is their full-service approach: from helping customers choose the right equipment to installation, training, and ongoing support. Their modern showroom in Bydgoszcz allows buyers to see the machines in action and test them under real conditions—ensuring confident investments with fast ROI.
Otinus machines are built for performance, safety, and durability, making them a smart choice for manufacturers looking to boost productivity and stay competitive. Whether you're upgrading your production line or expanding your capabilities, Otinus offers the right technology backed by expert service.
Specifications
-Maximum sheet size: 3000 x 1500 mm
-Max section height: 230 mm
-Max section length: 6000 mm
-X/Y positioning accuracy: ±0.05 mm/m
-X/Y positioning repeatability: ±0.03 mm
-Maximum travel speed: 60000 mm/min
-Maximum acceleration: 0.7 G
-Maximum load: 1200 kg
-Motor power output: 4.0 kW
-Energy consumption: 15.0 kW
-Source brand: Raycus or MAX Photonics to choose from
-Input voltage: ~3×400 V 50 Hz
-Ingress protection rating: IP54
Cutting thickness
-Carbon steel: recommended thickness 20.0 mm, maximum thickness 22.0 mm
-Stainless steel: recommended thickness 8.0 mm, maximum thickness 10.0 mm
-Aluminum: recommended thickness 6.0 mm, maximum thickness 8.0 mm
-Brass: recommended thickness 5.0 mm, maximum thickness 6.0 mm
Structure
The machine is very stable due to its welded structure on massive legs. Fuji Japanese servo drives with robust bevel rack and pinion drive ensure high speed and exceptional accuracy of the cutting head.
Tube cutting attachment
The machine is equipped with a rotary tube cutting attachment to position a section relative to the laser head. This solution allows for easy cutting of circular or rectangular sections including cuts passing through edges.
The ABL system automatically replenishes the grease in the rails.
User-friendliness
The fiber laser cutter is fully adapted to the needs of the user, ensuring maximum comfort during its operation. The heavy plates are made easier to handle with ball transfer units embedded in the surface, allowing the plates to roll smoothly during loading. Collecting small parts is much easier thanks to the waste collection trolleys, which can be pulled out using a convenient handle.
RayTools cutting head with auto-focus.
Control panel
The control of the fiber laser occurs is carried out via the control panel with keyboard and mouse. The computer includes the Windows system and CypCut software, which comes with functions such as:
-part programming,
-file import and export,
-adjustment of power output and cutting speed.
Installed software has lifetime licenses
Wireless remote
The control of the laser head is carried out by a wireless remote control.
Safety
The fiber laser cutting machine is delivered with all necessary measures to ensure the safety of users. Emergency lights with an audible alarm system activate in situations that compromise user safety, alerting to the danger.
Assistance by a specialist
We strive to maintain constant communication with our Customers. To support this, each purchased machine includes a Specialist Assistance Package with dedicated hours of expert guidance.
Within the service, our technicians may:
-Prepare or redesign CAD drawings,
-Advise on material and gas selection,
-Assist in the selection of operating parameters for different materials.
The remaining time can be checked in the Otinus Customer Panel.
Otinus Academy
This is an ever-growing e-learning platform created for Otinus brand customers. By purchasing this machine, you'll receive one year's access to online courses, allowing you to easily train a new employee or refresh your training knowledge!
Free drawing package
Each Otinus laser cutter includes a comprehensive set of ready-to-use CAD drawings. The designs included are ready-made as they can be immediately cut in any format. Our technician will show you how to do that during training. The drawings will be useful to anyone who wants to make various types of decorative items.
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
