| Manufacturer | Otinus |
|---|---|
| Model | FLV-3015-CT-6023 12kW / VF1530-12000W |
| Year | 2025 |
| Location | Poland
|
The Otinus FLV-3015-CT-6023 is a fiber laser cutting machine designed for precision cutting of metal sheets up to 3000 x 1500 mm in size. It features a powerful 12 kW laser source, suitable for cutting carbon steel with a maximum thickness of 35 mm, stainless steel up to 25 mm, and aluminum or brass up to 18 mm. The machine offers high positioning accuracy of ±0.05 mm/m and repeatability of ±0.03 mm, with a maximum travel speed of 120,000 mm/min and acceleration up to 1.5 G, ensuring efficient and precise cutting performance.
Constructed with a welded structure on massive legs, the machine provides excellent stability. It incorporates Fuji Japanese servo drives with a robust bevel rack and pinion drive system, contributing to the high speed and accuracy of the cutting head. A rotary tube cutting attachment is included, allowing for the cutting of circular or rectangular sections, including edge-passing cuts.
The cutting bed is equipped with metal slats for material support and a conveyor or material handling system to facilitate workflow. The laser cutting head is mounted on a gantry system above the cutting bed, and the interior is maintained clean and free of debris.
For user convenience, heavy plates can be handled more easily thanks to embedded ball transfer units on the surface that allow smooth rolling during loading. Waste collection trolleys with convenient handles simplify the collection of small parts. The RayTools cutting head features auto-focus capability.
Operation is managed via a control panel mounted on the right side, which includes a screen, keyboard, mouse, and a wireless remote control. The panel runs Windows with CypCut software, supporting part programming, file import/export, and adjustment of power output and cutting speed. An emergency stop button and safety measures such as audible alarms and emergency lights ensure user safety.
Additional features include an automatic grease replenishment system (ABL) for the rails and an IP54 ingress protection rating. The machine appears new, clean, and well maintained with no visible wear or damage. The Otinus brand name is prominently displayed on the machine.
Purchasing this machine includes a comprehensive package: a 4-day training program covering installation and operation, lifetime licenses for installed software, a CAD drawing package with ready-to-use designs, a Specialist Assistance Package offering expert guidance, and one-year access to the Otinus Academy e-learning platform for ongoing training and support.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Fiber Laser cutting machine FLV-3015-CT-6023 12kW / VF1530-12000W
Specifications
Maximum sheet size: 3000 x 1500 mm
Max section height: 230 mm
Max section length: 6000 mm
X/Y positioning accuracy: ±0.05 mm/m
X/Y positioning repeatability: ±0.03 mm
Maximum travel speed: 120000 mm/min
Maximum acceleration: 1.5 G
Motor power output: 12.0 kW
Energy consumption: 73.0 kW
Source brand: Raycus or MAX Photonics to choose from
Input voltage: ~3×400 V 50 Hz
Ingress protection rating: IP54
Cutting thickness
Carbon steel: recommended thickness 35.0 mm, maximum thickness 35.0 mm
Stainless steel: recommended thickness 25.0 mm, maximum thickness 25.0 mm
Aluminum: recommended thickness 18.0 mm, maximum thickness 18.0 mm
Brass: recommended thickness 18.0 mm, maximum thickness 18.0 mm
Structure
The machine is very stable due to its welded structure on massive legs. Fuji Japanese servo drives with robust bevel rack and pinion drive ensure high speed and exceptional accuracy of the cutting head.
Tube cutting attachment
The machine is equipped with a rotary tube cutting attachment to position a section relative to the laser head. This solution allows for easy cutting of circular or rectangular sections including cuts passing through edges.
The ABL system automatically replenishes the grease in the rails.
User-friendliness
The fiber laser cutter is fully adapted to the needs of the user, ensuring maximum comfort during its operation. The heavy plates are made easier to handle with ball transfer units embedded in the surface, allowing the plates to roll smoothly during loading. Collecting small parts is much easier thanks to the waste collection trolleys, which can be pulled out using a convenient handle.
RayTools cutting head with auto-focus.
Control panel
The control of the fiber laser occurs is carried out via the control panel with keyboard and mouse. The computer includes the Windows system and CypCut software, which comes with functions such as:
part programming,
file import and export,
adjustment of power output and cutting speed.
Installed software has lifetime licenses
Wireless remote
The control of the laser head is carried out by a wireless remote control.
Safety
The fiber laser cutting machine is delivered with all necessary measures to ensure the safety of users. Emergency lights with an audible alarm system activate in situations that compromise user safety, alerting to the danger.
Assistance by a specialist
We strive to maintain constant communication with our Customers. To support this, each purchased machine includes a Specialist Assistance Package with dedicated hours of expert guidance.
Within the service, our technicians may:
Prepare or redesign CAD drawings,
Advise on material and gas selection,
Assist in the selection of operating parameters for different materials.
The remaining time can be checked in the Otinus Customer Panel.
Otinus Academy
This is an ever-growing e-learning platform created for Otinus brand customers. By purchasing this machine, you'll receive one year's access to online courses, allowing you to easily train a new employee or refresh your training knowledge!
Free drawing package
Each Otinus laser cutter includes a comprehensive set of ready-to-use CAD drawings. The designs included are ready-made as they can be immediately cut in any format. Our technician will show you how to do that during training. The drawings will be useful to anyone who wants to make various types of decorative items.
Included in the price
4-day training including machine installation
2 day up to 8 hours—machine installation and training
3 day up to 8 hours—independent work on the machine with the assistance of an Otinus technician with possibility of making specific parts used by the Customer—1 day to 8 hours
4 day up to 8 hours—an additional training session online available within 12 months for any questions that may arise during machine operation.
Consultation with a specialist
Telephone: Monday to Saturday, from 7:30 a.m. to 9:00 p.m., with an 8-hour support package valid for 12 months.
Online: Monday to Saturday, from 7:30 a.m. to 9:00 p.m., with an 8-hour support package valid for 12 months.
Access to Otinus Academy courses
LibreCad - 12 month access
In addition, you will receive
CAD drawing package
Terms of cooperation
The Customer is responsible for the machine during unloading and transport within their facility.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
