| Manufacturer | Otinus |
|---|---|
| Model | FLV-3015-CT-6023 3kW / VF1530-3000W |
| Year | 2025 |
| Location | Poland
|
A selection of our machines is available for immediate delivery. Model: Fiber Laser cutting machine FLV-3015-CT-6023 3kW / VF1530-3000W.
Key specifications
- Maximum sheet size: 3000 × 1500 mm
- Max section height: 230 mm; max section length: 6000 mm
- X/Y positioning accuracy: ±0.05 mm/m; repeatability: ±0.03 mm
- Maximum travel speed: 120000 mm/min; maximum acceleration: 1.5 G
- Motor power output: 3.0 kW
- Source brand: Raycus or MAX Photonics (customer choice)
- Input voltage: ~3×400 V 50 Hz
- Ingress protection rating: IP54
Recommended and maximum cutting thicknesses
- Carbon steel: recommended 18.0 mm, maximum 20.0 mm
- Stainless steel: recommended 8.0 mm, maximum 10.0 mm
- Aluminum: recommended 6.0 mm, maximum 8.0 mm
- Brass: recommended 5.0 mm, maximum 6.0 mm
Structure and motion
The machine has a welded structure on substantial legs for stability. Motion is driven by Fuji Japanese servo drives with a bevel rack-and-pinion drive intended to provide high speed and cutting-head accuracy. An ABL system is included for automatic replenishment of grease in the rails.
Cutting tools and attachments
The unit is supplied with a rotary tube cutting attachment for positioning sections relative to the laser head to enable cutting of circular and rectangular tubes, including edge-passing cuts. A RayTools cutting head with auto-focus is specified.
User interface and accessories
Control is via a control panel with keyboard and mouse; the computer runs Windows with CypCut software that supports part programming, file import/export, and adjustment of power and cutting speed. The installed software has lifetime licenses. A wireless remote is provided for laser-head control. The work surface includes ball-transfer units to ease plate handling and waste collection trolleys for small parts removal.
Safety, support and training
Safety measures include emergency lights with an audible alarm system. Each machine purchase includes a Specialist Assistance Package with dedicated expert hours for tasks such as CAD drawing preparation/redesign, material and gas selection advice, and parameter selection support. Buyers receive one year of access to Otinus Academy e-learning courses, a CAD drawing package, and 12 months’ access to LibreCad. The standard offer includes a four-day training and installation package (detailed schedule included with the purchase) and an 8-hour phone/online support package valid for 12 months.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
A selection of our machines is available for IMMEDIATE DELIVERY.
Fiber Laser cutting machine FLV-3015-CT-6023 3kW / VF1530-3000W
Specifications
Maximum sheet size: 3000 x 1500 mm
Max section height: 230 mm
Max section length: 6000 mm
X/Y positioning accuracy: ±0.05 mm/m
X/Y positioning repeatability: ±0.03 mm
Maximum travel speed: 120000 mm/min
Maximum acceleration: 1.5 G
Motor power output: 3.0 kW
Source brand: Raycus or MAX Photonics to choose from
Input voltage: ~3×400 V 50 Hz
Ingress protection rating: IP54
Cutting thickness
Carbon steel: recommended thickness 18.0 mm, maximum thickness 20.0 mm
Stainless steel: recommended thickness 8.0 mm, maximum thickness 10.0 mm
Aluminum: recommended thickness 6.0 mm, maximum thickness 8.0 mm
Brass: recommended thickness 5.0 mm, maximum thickness 6.0 mm
Structure
The machine is very stable due to its welded structure on massive legs. Fuji Japanese servo drives with robust bevel rack and pinion drive ensure high speed and exceptional accuracy of the cutting head.
Tube cutting attachment
The machine is equipped with a rotary tube cutting attachment to position a section relative to the laser head. This solution allows for easy cutting of circular or rectangular sections including cuts passing through edges.
The ABL system automatically replenishes the grease in the rails.
User-friendliness
The fiber laser cutter is fully adapted to the needs of the user, ensuring maximum comfort during its operation. The heavy plates are made easier to handle with ball transfer units embedded in the surface, allowing the plates to roll smoothly during loading. Collecting small parts is much easier thanks to the waste collection trolleys, which can be pulled out using a convenient handle.
RayTools cutting head with auto-focus.
Control panel
The control of the fiber laser occurs is carried out via the control panel with keyboard and mouse. The computer includes the Windows system and CypCut software, which comes with functions such as:
part programming,
file import and export,
adjustment of power output and cutting speed.
Installed software has lifetime licenses
Safety
The fiber laser cutting machine is delivered with all necessary measures to ensure the safety of users. Emergency lights with an audible alarm system activate in situations that compromise user safety, alerting to the danger.
Assistance by a specialist
We strive to maintain constant communication with our Customers. To support this, each purchased machine includes a Specialist Assistance Package with dedicated hours of expert guidance.
Within the service, our technicians may:
Prepare or redesign CAD drawings,
Advise on material and gas selection,
Assist in the selection of operating parameters for different materials.
The remaining time can be checked in the Otinus Customer Panel.
Otinus Academy
This is an ever-growing e-learning platform created for Otinus brand customers. By purchasing this machine, you'll receive one year's access to online courses, allowing you to easily train a new employee or refresh your training knowledge!
Free drawing package
Each Otinus laser cutter includes a comprehensive set of ready-to-use CAD drawings. The designs included are ready-made as they can be immediately cut in any format. Our technician will show you how to do that during training. The drawings will be useful to anyone who wants to make various types of decorative items.
Included in the price
4-day training including machine installation
2 day up to 8 hours—machine installation and training
3 day up to 8 hours—independent work on the machine with the assistance of an Otinus technician with possibility of making specific parts used by the Customer—1 day to 8 hours
4 day up to 8 hours—an additional training session online available within 12 months for any questions that may arise during machine operation.
Consultation with a specialist
Telephone: Monday to Saturday, from 7:30 a.m. to 9:00 p.m., with an 8-hour support package valid for 12 months.
Online: Monday to Saturday, from 7:30 a.m. to 9:00 p.m., with an 8-hour support package valid for 12 months.
Access to Otinus Academy courses
LibreCad - 12 month access
In addition, you will receive
CAD drawing package
Terms of cooperation
The Customer is responsible for the machine during unloading and transport within their facility.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Machinery manufacturer |
| Active since | 2025 |
| Offers online | 25 |
| Last activity | Oct. 22, 2026 |
Otinus Polska Sp. z o.o. is one of Poland’s most trusted names in metalworking machinery, offering cutting-edge solutions under the Otinus brand. With over a decade of experience and a strong in-house production setup, Otinus delivers reliable and efficient machines tailored for today’s industrial needs—ranging from fiber laser cutters and plasma machines to press brakes, shears, and machining centers.
What sets Otinus apart is their full-service approach: from helping customers choose the right equipment to installation, training, and ongoing support. Their modern showroom in Bydgoszcz allows buyers to see the machines in action and test them under real conditions—ensuring confident investments with fast ROI.
Otinus machines are built for performance, safety, and durability, making them a smart choice for manufacturers looking to boost productivity and stay competitive. Whether you're upgrading your production line or expanding your capabilities, Otinus offers the right technology backed by expert service.
A selection of our machines is available for IMMEDIATE DELIVERY.
Fiber Laser cutting machine FLV-3015-CT-6023 3kW / VF1530-3000W
Specifications
Maximum sheet size: 3000 x 1500 mm
Max section height: 230 mm
Max section length: 6000 mm
X/Y positioning accuracy: ±0.05 mm/m
X/Y positioning repeatability: ±0.03 mm
Maximum travel speed: 120000 mm/min
Maximum acceleration: 1.5 G
Motor power output: 3.0 kW
Source brand: Raycus or MAX Photonics to choose from
Input voltage: ~3×400 V 50 Hz
Ingress protection rating: IP54
Cutting thickness
Carbon steel: recommended thickness 18.0 mm, maximum thickness 20.0 mm
Stainless steel: recommended thickness 8.0 mm, maximum thickness 10.0 mm
Aluminum: recommended thickness 6.0 mm, maximum thickness 8.0 mm
Brass: recommended thickness 5.0 mm, maximum thickness 6.0 mm
Structure
The machine is very stable due to its welded structure on massive legs. Fuji Japanese servo drives with robust bevel rack and pinion drive ensure high speed and exceptional accuracy of the cutting head.
Tube cutting attachment
The machine is equipped with a rotary tube cutting attachment to position a section relative to the laser head. This solution allows for easy cutting of circular or rectangular sections including cuts passing through edges.
The ABL system automatically replenishes the grease in the rails.
User-friendliness
The fiber laser cutter is fully adapted to the needs of the user, ensuring maximum comfort during its operation. The heavy plates are made easier to handle with ball transfer units embedded in the surface, allowing the plates to roll smoothly during loading. Collecting small parts is much easier thanks to the waste collection trolleys, which can be pulled out using a convenient handle.
RayTools cutting head with auto-focus.
Control panel
The control of the fiber laser occurs is carried out via the control panel with keyboard and mouse. The computer includes the Windows system and CypCut software, which comes with functions such as:
part programming,
file import and export,
adjustment of power output and cutting speed.
Installed software has lifetime licenses
Safety
The fiber laser cutting machine is delivered with all necessary measures to ensure the safety of users. Emergency lights with an audible alarm system activate in situations that compromise user safety, alerting to the danger.
Assistance by a specialist
We strive to maintain constant communication with our Customers. To support this, each purchased machine includes a Specialist Assistance Package with dedicated hours of expert guidance.
Within the service, our technicians may:
Prepare or redesign CAD drawings,
Advise on material and gas selection,
Assist in the selection of operating parameters for different materials.
The remaining time can be checked in the Otinus Customer Panel.
Otinus Academy
This is an ever-growing e-learning platform created for Otinus brand customers. By purchasing this machine, you'll receive one year's access to online courses, allowing you to easily train a new employee or refresh your training knowledge!
Free drawing package
Each Otinus laser cutter includes a comprehensive set of ready-to-use CAD drawings. The designs included are ready-made as they can be immediately cut in any format. Our technician will show you how to do that during training. The drawings will be useful to anyone who wants to make various types of decorative items.
Included in the price
4-day training including machine installation
2 day up to 8 hours—machine installation and training
3 day up to 8 hours—independent work on the machine with the assistance of an Otinus technician with possibility of making specific parts used by the Customer—1 day to 8 hours
4 day up to 8 hours—an additional training session online available within 12 months for any questions that may arise during machine operation.
Consultation with a specialist
Telephone: Monday to Saturday, from 7:30 a.m. to 9:00 p.m., with an 8-hour support package valid for 12 months.
Online: Monday to Saturday, from 7:30 a.m. to 9:00 p.m., with an 8-hour support package valid for 12 months.
Access to Otinus Academy courses
LibreCad - 12 month access
In addition, you will receive
CAD drawing package
Terms of cooperation
The Customer is responsible for the machine during unloading and transport within their facility.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
A selection of our machines is available for immediate delivery. Model: Fiber Laser cutting machine FLV-3015-CT-6023 3kW / VF1530-3000W.
Key specifications
- Maximum sheet size: 3000 × 1500 mm
- Max section height: 230 mm; max section length: 6000 mm
- X/Y positioning accuracy: ±0.05 mm/m; repeatability: ±0.03 mm
- Maximum travel speed: 120000 mm/min; maximum acceleration: 1.5 G
- Motor power output: 3.0 kW
- Source brand: Raycus or MAX Photonics (customer choice)
- Input voltage: ~3×400 V 50 Hz
- Ingress protection rating: IP54
Recommended and maximum cutting thicknesses
- Carbon steel: recommended 18.0 mm, maximum 20.0 mm
- Stainless steel: recommended 8.0 mm, maximum 10.0 mm
- Aluminum: recommended 6.0 mm, maximum 8.0 mm
- Brass: recommended 5.0 mm, maximum 6.0 mm
Structure and motion
The machine has a welded structure on substantial legs for stability. Motion is driven by Fuji Japanese servo drives with a bevel rack-and-pinion drive intended to provide high speed and cutting-head accuracy. An ABL system is included for automatic replenishment of grease in the rails.
Cutting tools and attachments
The unit is supplied with a rotary tube cutting attachment for positioning sections relative to the laser head to enable cutting of circular and rectangular tubes, including edge-passing cuts. A RayTools cutting head with auto-focus is specified.
User interface and accessories
Control is via a control panel with keyboard and mouse; the computer runs Windows with CypCut software that supports part programming, file import/export, and adjustment of power and cutting speed. The installed software has lifetime licenses. A wireless remote is provided for laser-head control. The work surface includes ball-transfer units to ease plate handling and waste collection trolleys for small parts removal.
Safety, support and training
Safety measures include emergency lights with an audible alarm system. Each machine purchase includes a Specialist Assistance Package with dedicated expert hours for tasks such as CAD drawing preparation/redesign, material and gas selection advice, and parameter selection support. Buyers receive one year of access to Otinus Academy e-learning courses, a CAD drawing package, and 12 months’ access to LibreCad. The standard offer includes a four-day training and installation package (detailed schedule included with the purchase) and an 8-hour phone/online support package valid for 12 months.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
| Client type | Machinery manufacturer |
| Active since | 2025 |
| Offers online | 25 |
| Last activity | Oct. 22, 2026 |
Otinus Polska Sp. z o.o. is one of Poland’s most trusted names in metalworking machinery, offering cutting-edge solutions under the Otinus brand. With over a decade of experience and a strong in-house production setup, Otinus delivers reliable and efficient machines tailored for today’s industrial needs—ranging from fiber laser cutters and plasma machines to press brakes, shears, and machining centers.
What sets Otinus apart is their full-service approach: from helping customers choose the right equipment to installation, training, and ongoing support. Their modern showroom in Bydgoszcz allows buyers to see the machines in action and test them under real conditions—ensuring confident investments with fast ROI.
Otinus machines are built for performance, safety, and durability, making them a smart choice for manufacturers looking to boost productivity and stay competitive. Whether you're upgrading your production line or expanding your capabilities, Otinus offers the right technology backed by expert service.
