New offers - Food processing machines 887

General SKU: 214U093 Location: Barneveld CE: ✓ Make: Hermann Waldner Pressure Working pressure jacket: 6 Bar Main Features Material: Stainless steel Volume: 2300 Ltr. Surface: 14.4 m2 Specified Features - Drying oven Tray dryer: ✓ Stainless steel housing: ✓ Stainless steel trays: ✓ Heating surface: 14.4m² Drying chamber capacity: 2300 Ltr. Drying chamber sizes: 970x1000x1750 mm Max. temperature: -10/120 °C With jacket: 10 Ltr. Max. temperature: -10/180 °C Number of trays: 34 Distance between the trays: 35 mm Tray capacity: 21Ltr. Container sizes: 530x800x50 mm With 1 door: ✓ With jacket: ✓ Drying ovens Material: Stainless steel 1.4539 (904L) General Type: HW-17.2 H Machine number: 5175 Year of construction: 2016 With switchgear: (as is) Floorspace: 1,3x1,65 m Total height: 2,6 m Weight: 1600 kg ATEX designed: ✓ Extra information Extra Specifications: This tray dryer must be heated by steam. Material: Stainless steel

General SKU: 302U610 Make: De Dietrich No.: 65104 Year of construction: 2003 Location: Barneveld Pressure Working pressure: 3 Bar Vacuum possible: ✓ Working pressure jacket: 4 Bar Vacuum possible jacket: ✓ Main Features Material: Glass Volume: 6000 Ltr. Motor: 5 KW Specified Features - Glass-lined Reactor Reactor: ✓ Capacity: 6937 / 39,5 Ltr. Vessel sizes: Dia:2200x2500 mm Dished bottom: ✓ Dished top side: ✓ Manhole: Dia: 770mm Top connections: DN 350, DN250(2x),DN100(4x) Outlet: DN100 With jacket: 712Ltr. Max. temperature: -10/150° With propellor stirrer: impeller Motor: 5kW, 400Volt, 1500rpm (EX) (no type plate!) Speed mixing shaft: 96rpm With jacket: ✓ Glass Reactors Material: Glass - Enamel (3009) General Floorspace: 2,2x2,2 m Total height: 4,6 m Weight: 6200 kg CE: ✓ Extra information Extra Specifications: Volume 712 Ltr. Material: Glass

General SKU: 354T1003 Make: Chemtech International Ltd Type: 212W and WH 35F No.: CC9816-01 and CC 9816-07 Year of construction: 1998 Mounted on frame: ✓ Pressure Working pressure: 40 Bar Working pressure jacket: 13.8 Bar Main Features Material: Stainless steel Motor: 7.5 KW Surface: 1 m2 Specified Features - Scraped surface heat exchanger Scraped surface heat exchanger: ✓ Number of stages:: 2 Heating surface: 1,03m² Heating surface shell: ±0,28 Heating surface rotor: ±0,25m² Capacity: 200kg/h Cylinder sizes: Dia: 152x600mm Max. temperature: 0-195°C With jacket: ✓ Rotor can be cooled/heated: ✓ Max. temperature: 0-195°C Inlet: Dia: 50mm, 38mm Outlet: Dia: 50mm, 38mm Motor: 1.1kW, 400/690volt, 1465rpm With post treatment cylinder: ✓ Heating surface: ±0,5m² Cylinder sizes: Dia: 280x570mm Motor: 7,5kW, 400/690Volt, 1430rpm Material: Stainless steel 1.4306 (304L), Stainless steel 1.4401 (316) With jacket: ✓ General Location: Barneveld Floorspace: 3,55x0,85m Total height: 2,6m Weight: 1340kg CE: ✓ Extra information Extra Specifications: * Specifications Chemtech 212-W -product side working pressure: 40bar test pressure: 60bar max temperature: 195°C capacity: 2.6ltr. medium: grease motor data: 1.1kW, 400/690volt, 1465rpm product inlet: 50mm product outlet: 50mm the rotor is equipped with 2 floating scraper -jacket side working pressure: 13.8bar test pressure: 20.7bar max temperature: 195°C capacity: 11.2ltr …

General SKU: 411S991 Location: Barneveld Main Features Material: Chromed Motor: 11 KW Surface: 6.28 m2 Specified Features - Roll dryer Roll dryer: ✓ Double roll: ✓ Roll surface: 6,28 m² Roll sizes: dia. 1000x2000 mm Steam heating: ✓ With knife discharge: ✓ Motor: 11 kW, 500 Volt Roll speed: 2-8 rpm With jacket: ✓ Material: Cast iron, Cast Iron Hard Chromium, Rubber With jacket: ✓ General Make: Georg Dietzel (D) Type: EA 630 Extra information Extra Specifications: Small roll: dia. 210x2000 mm, area: 1.3 m², material: 1.1830, rubberized Spare roll Material: Chromed

General SKU: 345S1064 Make: Gab Neumann Location: Barneveld Type: N-B-2,5 Pressure Vacuum possible: ✓ Working pressure shell: 6 Bar Working pressure tubes: 3 Bar Main Features Shell (Material): Graphite Tube (Material): Graphite Surface: 1.75 m2 Specified Features - Shell and tube heat exchanger Heat exchanger: ✓ Vertical: ✓ Heating surface: 1,75 m² Tube capacity: 9 Ltr. Max. temperature: -60/165 °C Shell capacity: 12 Ltr. Max. temperature: -60/80 °C Shell connections: DN10, DN50 Cover connections: DN50 (2x) Material: Graphite General No.: 10927-8694 Year of construction: 1991 Floorspace: 0,5x0,5 m Total height: 1 m Weight: 250 kg

General SKU: 345S761 Location: Barneveld Make: Unex Heatexchanger GmbH (DE) Type: Hybrid No.: HB 25228400028 Pressure Working pressure: 6 Bar Vacuum possible: ✓ Main Features Material: Stainless steel Surface: 5.7 m2 Specified Features - Plate heat exchanger Plate heat exchangers: ✓ Number of stages:: 1 Heating surface: 5,7 m2 Capacity: 42 Ltr Connections: DN80(2x), DN 50(2x) Max. temperature: -30/200°C. Material: Stainless steel 1.4571 (316Ti) General Year of construction: 2000 Floorspace: 1,0x0,7 M Total height: 1,0 M Weight: 260 KG Extra information Extra Specifications: Condenser Material: Stainless steel

General SKU: 070A418 Make: Stork Plaatwellerij Velsen No.: 1308 Year of construction: 1979 Location: Barneveld Pressure Working pressure: 4.5 Bar Vacuum possible: ✓ Working pressure jacket: 3 Bar Main Features Material: Stainless steel Volume: 800 Ltr. Motor: 11 KW Specified Features - Stainless Steel Reactor Reactor: ✓ Capacity: 1000 l, Useful 800 l Vessel sizes: dia. 1042 x 1000mm Dished bottom: ✓ Conical bottom: ✓ Dished top side: ✓ Manhole: hand hole dia. 200 mm Top connections: dia. 150 mm + dia. 40 mm + 2x dia. 25 mm Outlet: dia. 145 mm With jacket: vollume: 80 Ltr Max. temperature: 150°C With propellor stirrer: make Ekato, type EM-060 With paddle stirrer: ✓ Motor: 11,0 KW, (380/660 Volt, 960 rpm (Ex)) Speed mixing shaft: 99 rpm With jacket: ✓ Stainless Steel Reactors Material: Stainless steel 1.4571 (316Ti) General Floorspace: 1,4 x 1,4 m Total height: 3,0 m Weight: 1600 kg ATEX designed: ✓ Material: Stainless steel

General SKU: 079P422 Make: Haagen+Rinau Type: SO 700 No.: 8713258 Year of construction: 1983 Mounted on legs: ✓ Pressure Working pressure: 3 Bar Vacuum possible: ✓ Working pressure jacket: 10 Bar Main Features Material: Stainless steel Volume: 993 Ltr. Motor: 1.2 KW Specified Features - Stainless Steel Reactor Reactor: ✓ Capacity: 993 Ltr. Vessel sizes: Dia. 1000 x 100mm Dished bottom: ✓ Outlet: Dia. 40mm With jacket: ✓ Max. temperature: 160/183 Dgr.C. With propellor stirrer: ✓ Motor: 0,7/1,2 kW (380 V) Speed mixing shaft: 425/940 rpm With jacket: ✓ Stainless Steel Reactors Material: Stainless steel 1.4571 (316Ti) General Location: Barneveld With switchgear: (as is) Floorspace: 2,0 x 1,3 m Total height: 4,5 m Weight: 2500 kg Extra information Extra Specifications: - Mirror polished - Hydraulic lifting cover and stirrer Material: Stainless steel

General SKU: 201P093 Make: SGL Technik Gmbh Meitingen (DE) Type: RS-77-2-5515.1 No.: 76461/1A Year of construction: 1998 Location: Barneveld Material Tube material: Graphite Diabon-NS1 G20-3-170 Pressure Working pressure shell: 6 Bar Working pressure tubes: 6 Bar Main Features Shell (Material): Mild steel Tube (Material): Graphite Surface: 8 m2 Specified Features - Shell and tube heat exchanger Heat exchanger: ✓ Vertical: ✓ Notified body: TÜV Heating surface: 8 m² Tube capacity: 62 l Number of tubes:: 55 Tube diameter: 37 mm Tube length: 1.500 mm Wall thickness tubes: 5 mm Max. temperature: 170°C Shell capacity: 100 l Shell diameter: 460 mm Shell length: 1.380 mm Wall thickness shell: 6 mm Max. temperature: 170°C Shell connections: (2x) DN80, DN40 Cover connections: (2x) DN150 Material: Mild steel General Floorspace: 0,7 x 0,7 m Total height: 2.2 m Weight: 600 kg

General SKU: 259P364 Make: ITT standard plateflow (usa) Type: PF 35 No.: A50535-01 Year of construction: 1995 Mounted on frame: ✓ Pressure Working pressure: 10.3 Bar Main Features Material: Stainless steel Surface: 13 m2 Size length: 380 mm Sizes width: 350 mm Specified Features - Plate heat exchanger Plate heat exchangers: ✓ Heating surface: +/- 13m2 Number of platens: 41 Plate sizes: 380x850 mm Connections: (4x) 110 mm Max. temperature: 110 degr.C Material: Stainless steel General Location: Barneveld Floorspace: 0,9X05 M Total height: 1,0 M Weight: 500 KG Extra information Extra Specifications: indicated size is platen size Material: Stainless steel

General SKU: 026F110 Make: Freude Titan GmbH & Co. KG Sinsheim No.: 18414 Year of construction: 2010 Mounted on legs: ✓ Pressure Working pressure shell: 0.5 Bar Working pressure tubes: 3 Bar Tubular vacuum possible: ✓ Main Features Shell (Material): Stainless steel Tube (Material): Hastelloy Surface: 13 m2 Specified Features - Shell and tube heat exchanger Heat exchanger: ✓ Horizontal: ✓ Heating surface: 13 m2 Tube capacity: 2x 15,5 Ltr Number of tubes:: 106 Tube diameter: 10mm Tube length: 4000mm Wall thickness tubes: 1 mm Max. temperature: -196/+100 Degr. C. Shell capacity: 51 Ltr Max. temperature: -196 / +100°C Shell with expansion joint: ✓ Shell connections: 2x dia. 50mm Cover connections: 2x dia. 50mm + 2x dia. 25mm Material: Stainless steel 2.4602 (Hastelloy C-22) General Location: Barneveld Floorspace: 4,5 x 0,4 m Total height: 0,9 m Weight: 200 kg CE: ✓

General SKU: 031H071 Make: API Schmidt-Bretten Location: Barneveld CE: ✓ Type: Sigma X49 SBL Pressure Working pressure: 10 Bar Main Features Material: Stainless steel Surface: 90.2 m2 Size length: 1100 mm Sizes width: 400 mm Specified Features - Plate heat exchanger Plate heat exchangers: ✓ Heating surface: 90,2 m² Capacity: 86/87 l. Number of platens: 222 Plate sizes: ± 1120x400mm Connections: 4x dia. 100mm Max. temperature: 100 °C. Capacity: 700 kW Material: Stainless steel 1.4404 (316L) General No.: PA-90136 Year of construction: 2006 Floorspace: 1,7x0,6 m Total height: 1,6 m Weight: 875 kg Extra information Extra Specifications: sealing material NBR indicated size is platen size, capacity is 700 KG platen sizes: 400 x 1120 mm Material: Stainless steel

General SKU: 274P409 Location: Barneveld Make: Hellmich Behälter- und Apparatebau (DE) No.: 4972 Pressure Working pressure: 6 Bar Working pressure jacket: 2.5 Bar Main Features Material: Stainless steel Volume: 13300 Ltr. Motor: 15 KW Specified Features - Stainless Steel Reactor Reactor: ✓ Capacity: 13300 l Vessel sizes: dia.2300mm x2700mm Dished bottom: ✓ Dished top side: ✓ Manhole: dia.500mm Top connections: (8x)dia.80mm, (3x)dia.50mm, dia.100mm Outlet: dia.100mm Half coil jacketed: (488 l) Max. temperature: 120 °C With paddle stirrer: type FGRLR-80D Motor: 15 kW, 290/500 V Speed mixing shaft: 59 rpm With jacket: ✓ Stainless Steel Reactors Material: Stainless steel 1.4541 (321) General Year of construction: 1998 Mounted on legs: ✓ Floorspace: 2,6x2,6 m Total height: 5,5 m Weight: 6000 kg Material: Stainless steel

General SKU: R0906 Make: Walter Stöcklin AG (CH) Type: 6300 L No.: 1330 Year of construction: 1985 Location: Barneveld Pressure Working pressure: 3.2 Bar Vacuum possible: ✓ Working pressure jacket: 16 Bar Main Features Material: Stainless steel Volume: 6300 Ltr. Motor: 11.2 KW Specified Features - Stainless Steel Reactor Reactor: ✓ Capacity: 6300 l (8500 l) Vessel sizes: ø 2000 x 3050 mm Dished bottom: ✓ Dished top side: ✓ Manhole: ø 600 mm Top connections: 5x DN150, 2x DN250 Outlet: ø 125 mm Half coil jacketed: 280 l Max. temperature: —30/200 °C With paddle stirrer: "Ekato EM100-D" Motor: 3,07/11,2 kW, 380 V, (Ex) Speed mixing shaft: 6.9—69 rpm With jacket: ✓ Stainless Steel Reactors Material: Stainless steel 1.4435 (316L) General Floorspace: 2,4 x 2,4 m Total height: 4,9 m Weight: 4500 kg ATEX designed: ✓ Material: Stainless steel

General SKU: 029G111 Make: Tool-Temp AG Romanshorn Type: TT-20.000 WK/R-404 A Mach.No.: 97-13868 Year of construction: 1997 Main Features Heating (medium): Electric Capacity: 6.9 KW Temp.: 40 °C Specified Features - Temperature control unit Temperating machine: "Chiller" Heating medium:: R-404 A Electric capacity: 6.900 W With cooling: ✓ Temperature: +10/+40°C. With pump: ✓ Motor: 1,1 kW With temperature controller: ✓ General Location: Barneveld Mounted on wheels: ✓ With switch: ✓ Floorspace: 1,2 x 0,8 m Total height: 1,6 m Weight: 350 kg

General SKU: R0894 Make: Le Carbone AG Type: Polybloc NF 610 G No.: 17496 Year of construction: 1997 Location: Barneveld Pressure Working pressure shell: 6 Bar Working pressure tubes: 6 Bar Main Features Shell (Material): Mild steel Tube (Material): Graphilor Surface: 16.3 m2 Specified Features - Shell and tube heat exchanger Heat exchanger: ✓ Vertical: ✓ Heating surface: 16,3 m² Tube capacity: 93,9 l. Max. temperature: 165°C Shell capacity: 80 l. Shell diameter: 660 mm Shell length: 1370 mm Max. temperature: 165°C Shell connections: 2x DN150 Cover connections: 2x DN200 Material: Graphite Graphilor XBS General Floorspace: 0,9x0,9 m Total height: 1,7 m Weight: 1250 kg

General SKU: R0893 Make: Le Carbone-Lorraine AG (FRA) Location: Barneveld Type: Polybloc NF610G Pressure Working pressure shell: 6 Bar Working pressure tubes: 6 Bar Main Features Shell (Material): Mild steel Tube (Material): Graphilor Surface: 24.5 m2 Specified Features - Shell and tube heat exchanger Heat exchanger: ✓ Vertical: ✓ Heating surface: 24.5 m2 Tube capacity: 134.1 Ltr Max. temperature: 165 Degr.C. Shell capacity: 100 l. Shell diameter: 660mm Shell length: 1900mm Max. temperature: 165 degr. C Shell connections: 2x DN150 Cover connections: 2x DN200 Capacity: 134.1 Ltr Material: Graphite Graphilor XBS General No.: 17324 Year of construction: 1989 Floorspace: 1,0x0.9 M Total height: 2.4 M Weight: 1500 KG

General SKU: R0830 Make: Jaeggi Bern (CH) Location: Barneveld Type: 35 m² Pressure Working pressure shell: 6 Bar Working pressure tubes: 10 Bar Main Features Shell (Material): Stainless steel Tube (Material): Stainless steel Surface: 35 m2 Specified Features - Shell and tube heat exchanger Heat exchanger: ✓ Horizontal: ✓ Heating surface: 35 m² Tube capacity: 164 l. U-type: ✓ Number of tubes:: 120 Tube diameter: 16 mm Tube length: 6000 mm Wall thickness tubes: 1 mm Max. temperature: 200°C Shell capacity: 206 l Shell diameter: 406 mm Shell length: 3000 mm Wall thickness shell: 4 mm Max. temperature: 200°C Shell connections: dia. 65 mm (2x) dia 15 mm (1x) Cover connections: dia. 100 mm (2x) Material: Stainless steel 1.4435 (316L) General No.: 1894 Year of construction: 1990 Floorspace: 3.7 x 0.7 m Total height: 1.3 m Weight: 750 kg

General SKU: 309N511 Make: GEA Ahlborn GmbH&Co Sarstedt Type: NT-250 S B-10 No.: 140/10838 Year of construction: 2007 Location: Barneveld Pressure Working pressure: 6 Bar Main Features Material: Stainless steel Surface: 79.9 m2 Specified Features - Plate heat exchanger Plate heat exchangers: ✓ Heating surface: 79,9 m2 Capacity: 2x 151,8 Ltr Number of platens: 87 Connections: (4x) dia.250mm Max. temperature: 60 Degr.C. Material: Stainless steel (Sandvik 254 SMO) General Floorspace: 1,6x0,9 M Total height: 2,3 M Weight: 2322 KG Material: Stainless steel

General SKU: 345S656 Make: ENCO Energie Componenten GmbH (AT) No.: T7178/1 Year of construction: 2011 Location: Barneveld Pressure Working pressure: 3.2 Bar Vacuum possible: ✓ Working pressure jacket: 9 Bar Vacuum possible jacket: ✓ Main Features Material: Stainless steel Volume: 4250 Ltr. Motor: 5.5 KW Specified Features - Stainless Steel Reactor Reactor: ✓ Capacity: netto 4250 Ltr,(bruto 5800 Ltr) Vessel sizes: dia.1792 x1730mm Dished bottom: ✓ Dished top side: ✓ Manhole: DN450 Top connections: Dn100(2x), DN80, DN50(2x), DN25 Outlet: DN80 With jacket: 185 Ltr Internal heating spiral: 135 Ltr Max. temperature: -60 / 200°C With paddle stirrer: SDR 30-06 V Motor: 5,5 KW, 230/400 Volt (EExdeIICT4) Speed mixing shaft: 93rpm With jacket: ✓ Stainless Steel Reactors Material: Stainless steel 1.4539 (904L), Stainless steel 1.4571 (316Ti), Stainless steel 2.4602 (Hastelloy C-22) General Floorspace: 2,1x2,1m Total height: 2,92 Weight: 2300kg CE: ✓ ATEX designed: ✓ Extra information Extra Specifications: "Tank material: 1.4539 (904L) Shaft and agitator material: 1.4571 (316Ti) Material for internal heating: 2.4602 (Hastelloy C-22)" Material: Stainless steel
