| Manufacturer | WOTAN |
|---|---|
| Model | Rapid 2R/6-1500/2 |
| Year | 1979 |
| Location | Germany
|
Machine overview:
This listing is for a WOTAN Rapid 2R/6-1500/2 5-axis horizontal machining centre. The machine was manufactured in 1979 and carries a documented rebuild from 2015. Control is by a SIEMENS 840D. The unit is offered in its current condition: as-is, where-is.
Axis travels and table:
- X–Y–Z travel: 2000 mm x 1250 mm x 800 mm
- Additional W-axis travel listed: 1000 mm
- Table nominal size: 1250 x 1600 mm
- Maximum table load: 6000 kg
Spindle and drive:
- Spindle speed range: 3.2–1250 rpm (maximum listed 1250 rpm)
- Spindle diameter: 130 mm
- Spindle taper: SK 50
- Number of speed steps: 49
- Main drive power (100% duty cycle): 45 kW
Motion and axis details:
- Total axes: 5
- B-axis rotation: 360° with a listed B-axis rapid of 3 rpm
- Rapid traverse (general): 5000 mm/min
- Feed rate range: 1–2000 mm/min
Electrical and other technical data:
- Type of current and frequency: 3-phase, 50 Hz
- Operating voltage: 400 V
- Control voltage: DC 24 V
- Connected load: 76 kVA
- Rated current of equipment: 110 A
- Recommended rated fuse: 180 A (delay-action)
Typical applications:
- Typical workpiece materials: gray cast iron, cast steel
- Typical workpiece components referenced: housings, planet carriers
Notes:
All specifications above are taken from the provided machine data. The machine is offered as-is, where-is; no statement is made about current operational status, testing, refurbishment, or warranty beyond the provided rebuild date.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Type: 5-axis horizontal machining centre
Brand: WOTAN
Model: Rapid 2R/6-1500/2
Year of manufacture: 1979
Year of latest rebuild: 2015
X–Y–Z travel: 2000 mm x 1250 mm x 800 mm
Table: 1250 x 1600 mm, max load 6000 kg
Spindle: speed range 3.2–1250 rpm; spindle diameter 130 mm
Main drive power: 45 kW
Control: SIEMENS 840D
Axes: 5
Taper size: SK 50
B-axis: rotation 360°, rapid 3 rpm
Rapid traverse: 5000 mm/min
Feed range: 1–2000 mm/min
Electrical characteristics: 3-phase 50 Hz, 400 V; control voltage DC 24 V
Connected load: 76 kVA
Rated current of equipment: 110 A; Fuse: 180 A (delay-action)
Typical workpiece materials: Gray cast iron, cast steel
Typical workpiece components: Housings, planet carriers
Condition: as-is, where-is
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
