The DMG DMU 50 is a five-axis machining centre manufactured in 2018. Its listed axis travels are 650 mm in X, 520 mm in Y and 475 mm in Z. The table measures 630 mm by 500 mm and has a stated maximum part weight of 300 kg. Machine weight is 7,420 kg.
The machine is specified with a Siemens 840D sl control system and a speedMASTER spindle with a maximum speed of 15,000 rpm and power of 21 kW. The spindle taper is SK 40. A 30-position tool magazine is listed. The description specifies five-axis simultaneous machining and a swivel rotary table.
Other listed features include internal coolant supply, a chip conveyor, and air blast through the spindle centre. Optional equipment listed includes a Renishaw OMP60 workpiece probe, a Heidenhain TT160 tool measurement system, 3D quickSET, ATC, an electronic handwheel, and a rinsing gun. These items are described as optional equipment and should not be assumed to be included.
A separate operator console with a display and keypad is present. The machining area can be viewed through the front window, and a side access area is open. The exterior appears to have no obvious visible damage. The machine is marked DMU 50.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Seller's description
This 5-axis DMG DMU 50 was manufactured in 2018. It features a working table size of Ø 630 x 500 mm and a maximum table load of 300 kg. The machine is equipped with a high-speed spindle capable of 15,000 rpm and a tool magazine with 30 positions. If you are looking to get high-quality machining capabilities, consider the DMG DMU 50 vertical machining centre we have for sale. Contact us for further details.Control System: CELOS with Siemens 840D sl Operate (21.5-inch ERGOline Multi-Touch display) Machining Type: 5-axis simultaneous machining Working Table / NC Swivel Rotary Table: Ø 630 x 500 mm Swivel / Rotary Axes: B: -35° to +110°, C: 360° Rapid Traverse X / Y / Z: 42 m/min Main Spindle: speedMASTER 20 - 15,000 rpm (SK40 / CAT40 taper) Spindle Power: 21 kW (40% duty cycle) / 16 kW (100% duty cycle) Tool Magazine: 30 positions (SK40) Operating Hours (Control/On-Hours): 33,089 h Spindle Hours: 18,597 h Internal Coolant Supply (IKZ): 40 bar / 600 l with paper band filter and cabin root Chip Conveyor: Scraper belt type
Optional Equipment: Renishaw PP60 optical infrared workpiece probe (OMP60) Heidenhain TT160 tool measurement / length, diameter, and breakage detection 3D quickSET (kinematics check and correction) ATC (Application Tuning Cycle) Electronic handwheel Manual double switch filter (25 µm) Air blast through spindle center (selectable via M-function) Rinsing gun for chip flushing
The image was generated by AI. Images available on request Control Brand: SIEMENS Control Model: 840D sl Machine Weight: 7420 kg Number of Axes: 5 Tool Stations: 30 Spindle Power: 21 kW Spindle Speed: 15000 RPM Table Length: 500 mm Table Load: 300 kg Table Width: 630 mm Taper Size: SK 40 X-axis Travel: 650 mm Y-axis Travel: 520 mm Z-axis Travel: 475 mm
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
GINDUMAC GmbH is a dynamic German company specializing in the global trade of used industrial machinery. Our international team of more than 30 employees supports manufacturers worldwide in buying and selling high-quality used equipment across sectors such as metalworking, sheet metal, plastics, woodworking, and automation.
Through a data-driven, digital approach, the company delivers accurate machine valuations, professional inspections, and end-to-end transaction management — ensuring a transparent, secure, and efficient sales process for both buyers and sellers.
Seller's description
This 5-axis DMG DMU 50 was manufactured in 2018. It features a working table size of Ø 630 x 500 mm and a maximum table load of 300 kg. The machine is equipped with a high-speed spindle capable of 15,000 rpm and a tool magazine with 30 positions. If you are looking to get high-quality machining capabilities, consider the DMG DMU 50 vertical machining centre we have for sale. Contact us for further details.Control System: CELOS with Siemens 840D sl Operate (21.5-inch ERGOline Multi-Touch display) Machining Type: 5-axis simultaneous machining Working Table / NC Swivel Rotary Table: Ø 630 x 500 mm Swivel / Rotary Axes: B: -35° to +110°, C: 360° Rapid Traverse X / Y / Z: 42 m/min Main Spindle: speedMASTER 20 - 15,000 rpm (SK40 / CAT40 taper) Spindle Power: 21 kW (40% duty cycle) / 16 kW (100% duty cycle) Tool Magazine: 30 positions (SK40) Operating Hours (Control/On-Hours): 33,089 h Spindle Hours: 18,597 h Internal Coolant Supply (IKZ): 40 bar / 600 l with paper band filter and cabin root Chip Conveyor: Scraper belt type
Optional Equipment: Renishaw PP60 optical infrared workpiece probe (OMP60) Heidenhain TT160 tool measurement / length, diameter, and breakage detection 3D quickSET (kinematics check and correction) ATC (Application Tuning Cycle) Electronic handwheel Manual double switch filter (25 µm) Air blast through spindle center (selectable via M-function) Rinsing gun for chip flushing
The image was generated by AI. Images available on request Control Brand: SIEMENS Control Model: 840D sl Machine Weight: 7420 kg Number of Axes: 5 Tool Stations: 30 Spindle Power: 21 kW Spindle Speed: 15000 RPM Table Length: 500 mm Table Load: 300 kg Table Width: 630 mm Taper Size: SK 40 X-axis Travel: 650 mm Y-axis Travel: 520 mm Z-axis Travel: 475 mm
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
The DMG DMU 50 is a five-axis machining centre manufactured in 2018. Its listed axis travels are 650 mm in X, 520 mm in Y and 475 mm in Z. The table measures 630 mm by 500 mm and has a stated maximum part weight of 300 kg. Machine weight is 7,420 kg.
The machine is specified with a Siemens 840D sl control system and a speedMASTER spindle with a maximum speed of 15,000 rpm and power of 21 kW. The spindle taper is SK 40. A 30-position tool magazine is listed. The description specifies five-axis simultaneous machining and a swivel rotary table.
Other listed features include internal coolant supply, a chip conveyor, and air blast through the spindle centre. Optional equipment listed includes a Renishaw OMP60 workpiece probe, a Heidenhain TT160 tool measurement system, 3D quickSET, ATC, an electronic handwheel, and a rinsing gun. These items are described as optional equipment and should not be assumed to be included.
A separate operator console with a display and keypad is present. The machining area can be viewed through the front window, and a side access area is open. The exterior appears to have no obvious visible damage. The machine is marked DMU 50.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
GINDUMAC GmbH is a dynamic German company specializing in the global trade of used industrial machinery. Our international team of more than 30 employees supports manufacturers worldwide in buying and selling high-quality used equipment across sectors such as metalworking, sheet metal, plastics, woodworking, and automation.
Through a data-driven, digital approach, the company delivers accurate machine valuations, professional inspections, and end-to-end transaction management — ensuring a transparent, secure, and efficient sales process for both buyers and sellers.
