The SPINNER TC600-65-MCY is a high-performance CNC lathe manufactured in 2024, designed with a 45-degree inclined bed and hardened, ground sliding guides to ensure precision and durability. It features strokes of X=275 mm and Z=700 mm, providing ample machining range. This single-spindle turret lathe is equipped with a Y-axis and a servo-driven turret with 16 stations, all capable of driven tooling, utilizing a BMT45 tool clamping system.
The main spindle supports bar diameters up to 65 mm and operates at speeds up to 4,000 rpm. It includes an integrated water-cooled spindle motor delivering a maximum power of 34 kW and torque of 325 Nm. The spindle is equipped with a hydraulic hollow clamping chuck with a 65 mm bar pitch.
For workholding, the machine includes an SMW-Autoblok power chuck with a 250 mm diameter and three cams, supplied with both soft and hardened overlapping cams for versatility. The CNC tailstock features an integrated bearing, programmable clamping force, and parallel travel to the main spindle, with foot pedal control for tailstock quill movement during loading.
The lathe incorporates direct measurement in the X-axis for enhanced accuracy. It is controlled by a FANUC 32iTB system with a 15-inch LCD color flat panel display and full-size keypad. The control supports path control with a Fanuc user interface, offering 256 KByte user memory and storage for up to 64 program numbers. Connectivity options include USB and Ethernet interfaces.
Advanced machining cycles such as tapping, deep hole drilling, deburring, grooving, contour programming, tool radius compensation, chamfering, and corner rounding are included.
The machine features an enclosed work area with a viewing window, allowing safe observation of operations. A tool turret is visible inside the work area, and a chip conveyor is attached to the right side of the machine for efficient chip removal. The control panel is conveniently located on the right side with multiple buttons and knobs for operational control.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
SPINNER TC600 with strokes X=275 mm, Z=700 mm
In 45 degree inclined bed design
With hardened and ground sliding guides
Equipped as a single-spindle turret lathe
with driven tools
Y-axis
Turret with driven tool stations
All stations can be driven, servo revolver
Adjustable turning speed
Tool clamping system on turret: BMT45
Number of stations in turret: 16
Spindle 1 in version up to 4.000 rpm - 65 mm
Integrated water-cooled spindle motor
With hydraulic hollow clamping chuck, 65 mm bar pitch
Speed range: 0-4,000 rpm
Maximum power: 34 kW / 325 Nm
SMW-Autoblok power chuck
250 mm diameter, 3 cams, model BHD
Set of soft cams, set of hardened overlapping cams
Pedal
CNC tailstock with integrated bearing
Travel as CNC axis parallel to the main spindle
Programmable clamping force
Foot pedal control to move tailstock quill in loading mode
Direct measurement in the X-axis
FANUC 32iTB control system with basic functions:
Path control with Fanuc user interface
15" Fanuc LCD color flat panel display, full-size keypad
256 KByte user memory, max. 64 program numbers
USB interface for downloading/storing NC programs
Ethernet interface
GE Fanuc "Turning" process cycles for tapping, deep hole drilling, deburring, grooving
Contour programming, tool radius compensation, chamfering, and corner rounding
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
