| Manufacturer | Otinus |
|---|---|
| Model | FLV-3015-C2 12kW / VF1530-12000W |
| Year | 2025 |
| Location | Poland
|
The Otinus FLV-3015-C2 12kW / VF1530-12000W is a high-performance fiber laser cutting machine designed for precise and efficient metal processing. It accommodates metal sheets up to 3000 mm in length and 1500 mm in width, with a maximum cutting thickness of 34 mm. The machine offers excellent positioning accuracy of ±0.05 mm/m and repeatability of ±0.03 mm, supported by robust Fuji Japanese servo drives and a bevel rack and pinion drive system.
Powered by a 12 kW motor, this fiber laser cutter supports maximum travel speeds of 120,000 mm/min and accelerations up to 1.5 G. It operates on a ~3×400 V 50 Hz power supply and features an IP54 ingress protection rating. Users can select between Raycus or MAX Photonics laser sources.
The machine's welded structure on massive legs ensures stability during operation. It incorporates an automatic lubrication system (ABL) for rail maintenance. The cutting head is equipped with a RayTools auto-focus system to enhance cutting precision.
User-friendly features include ball transfer units embedded in the surface to facilitate handling of heavy plates and waste collection trolleys for easy removal of small parts. Control is managed via a panel located on the front right side, which includes a screen and buttons, alongside two smaller display screens positioned above it, providing additional visual information.
The control system runs on Windows with CypCut software, enabling part programming, file import/export, and adjustment of power output and cutting speed. A wireless remote control is also provided for laser head operation.
Safety is prioritized with emergency lights and audible alarms to alert users to hazardous situations. The machine is delivered with a comprehensive support package including installation, training, technical consultation, and access to the Otinus Academy e-learning platform.
Overall, the Otinus FLV-3015-C2 offers a stable, precise, and user-friendly solution for fiber laser cutting applications, backed by extensive customer support and training resources.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
A part of our machines is available IMMEDIATELY.
Fiber Laser cutting machine FLV-3015-C2 12kW / VF1530-12000W
Specifications
-Maximum sheet size: 3000 x 1500 mm
-X/Y positioning accuracy: ±0.05 mm/m
-X/Y positioning repeatability: ±0.03 mm
-Maximum travel speed: 120000 mm/min
-Maximum acceleration: 1.5 G
-Motor power output: 12.0 kW
-Energy consumption: 73.0 kW
-Source brand: Raycus or MAX Photonics to choose from
-Input voltage: ~3×400 V 50 Hz
-Ingress protection rating: IP54
Cutting thickness
-Carbon steel: recommended thickness 35.0 mm, maximum thickness 35.0 mm
-Stainless steel: recommended thickness 25.0 mm, maximum thickness 25.0 mm
-Aluminum: recommended thickness 18.0 mm, maximum thickness 18.0 mm
-Brass: recommended thickness 18.0 mm, maximum thickness 18.0 mm
Structure
The machine is very stable due to its welded structure on massive legs. Fuji Japanese servo drives with robust bevel rack and pinion drive ensure high speed and exceptional accuracy of the cutting head.
The ABL system automatically replenishes the grease in the rails.
User-friendliness
The fiber laser cutter is fully adapted to the needs of the user, ensuring maximum comfort during its operation. The heavy plates are made easier to handle with ball transfer units embedded in the surface, allowing the plates to roll smoothly during loading. Collecting small parts is much easier thanks to the waste collection trolleys, which can be pulled out using a convenient handle.
RayTools cutting head with auto-focus.
Control panel
The control of the fiber laser occurs is carried out via the control panel with keyboard and mouse. The computer includes the Windows system and CypCut software, which comes with functions such as:
-part programming,
-file import and export,
-adjustment of power output and cutting speed.
Installed software has lifetime licenses
Wireless remote
The control of the laser head is carried out by a wireless remote control.
Safety
The fiber laser cutting machine is delivered with all necessary measures to ensure the safety of users. Emergency lights with an audible alarm system activate in situations that compromise user safety, alerting to the danger.
Assistance by a specialist
We strive to maintain constant communication with our Customers. To support this, each purchased machine includes a Specialist Assistance Package with dedicated hours of expert guidance.
Within the service, our technicians may:
-Prepare or redesign CAD drawings,
-Advise on material and gas selection,
-Assist in the selection of operating parameters for different materials.
The remaining time can be checked in the Otinus Customer Panel.
Otinus Academy
This is an ever-growing e-learning platform created for Otinus brand customers. By purchasing this machine, you'll receive one year's access to online courses, allowing you to easily train a new employee or refresh your training knowledge!
Free drawing package
Each Otinus laser cutter includes a comprehensive set of ready-to-use CAD drawings. The designs included are ready-made as they can be immediately cut in any format. Our technician will show you how to do that during training. The drawings will be useful to anyone who wants to make various types of decorative items.
Technical Consultation
Our specialists help select the right machine and accessories based on technical drawings of the parts you plan to produce.
Included in the price
3-day training including machine installation
1 day to 8 hours—machine installation and training
2 day up to 8 hours—independent work on the machine with the assistance of an Otinus technician with possibility of making specific parts used by the Customer—1 day to 8 hours
3 day up to 8 hours—an additional training session online available within 12 months for any questions that may arise during machine operation.
Consultation with a specialist
Telephone: Monday to Saturday, from 7:30 a.m. to 9:00 p.m., with an 8-hour support package valid for 12 months.
Online: Monday to Saturday, from 7:30 a.m. to 9:00 p.m., with an 8-hour support package valid for 12 months.
Access to Otinus Academy courses
LibreCad - 12 month access
In addition, you will receive
CAD drawing package
Terms of cooperation
The Customer is responsible for the machine during unloading and transport within their facility.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Machinery manufacturer |
| Active since | 2025 |
| Offers online | 25 |
| Last activity | Oct. 22, 2026 |
Otinus Polska Sp. z o.o. is one of Poland’s most trusted names in metalworking machinery, offering cutting-edge solutions under the Otinus brand. With over a decade of experience and a strong in-house production setup, Otinus delivers reliable and efficient machines tailored for today’s industrial needs—ranging from fiber laser cutters and plasma machines to press brakes, shears, and machining centers.
What sets Otinus apart is their full-service approach: from helping customers choose the right equipment to installation, training, and ongoing support. Their modern showroom in Bydgoszcz allows buyers to see the machines in action and test them under real conditions—ensuring confident investments with fast ROI.
Otinus machines are built for performance, safety, and durability, making them a smart choice for manufacturers looking to boost productivity and stay competitive. Whether you're upgrading your production line or expanding your capabilities, Otinus offers the right technology backed by expert service.
