MORI SEIKI NZ1500T2Y CNC lathe

Top seller

Price on request

Make an offer
Manufacturer MORI SEIKI
Model NZ1500T2Y
Year 2007
Location Italy IT

Specifications

Category Lathes - CNC lathes
Turning length 810 mm
Turning Ø 320 mm
Ø above the bed 800 mm
Ø above transversing slide 800 mm
Length between centers 1130 mm
Type of CNC
X-axis 210 mm
Z-axis 810 mm
Spindle taper
Spindle bore 61 mm
Number of turrets 3
Number of tools on turret 16
Number of rotating tools 16
Turning speed 6000 rpm
Spindle motor power 22 kW
Tailstock no
Bar feeder no
Weight 8100 kg
worked hours
hours under power
state as-is, where-is
At local norms ---------
status
Datasheet Mori Seiki NZ1500T3Y3
Last availability date 28/10/2026
Product id P260723026
Language

Automatic description (AI-Generated)

Overview
This listing is for a MORI SEIKI NZ1500T2Y CNC lathe, specified with a capacity of ø320/52x260 mm (ø12.60/2.05x10.24 in). The machine is shown with a manufacture date of 11/2007 and noted as having entered service in 05/2008.

Key working area and notes
- Center height: 52 mm
- Maximum turning diameter: 320 mm (12.60 in)
- Additional notes: maximum swing 800 mm; distance between spindles 1130 mm

Spindles
- Main spindle: 6000 rpm maximum, ASA5" spindle nose, 61 mm (2.40 in) spindle bore, inner bearing diameter 100 mm (3.94 in), C-axis resolution 0.001°, C-axis speed 6000 rpm, maximum power 22 kW
- Sub spindle: 6000 rpm maximum, ASA5" spindle nose, 61 mm (2.40 in) spindle bore, inner bearing diameter 100 mm (3.94 in), C-axis resolution 0.001°, C-axis speed 6000 rpm, maximum power 22 kW
- Automatic B-axis positioning: 920 mm (36.22 in)
- Self-centering diameter: 152.4 mm (6.00 in)

Turrets and tooling
- Two 16-position turrets (TURRET 1 and second turret), each with 16 positions and 16 powered positions
- Powered tool speed: 6000 rpm
- Powered tool power: 7.5 kW
- TURRET 1 axes: X1 stroke 210 mm, Z1 stroke 810 mm, Y1 stroke +65 / -45 mm
- Rapid traverses: X axes 30 m/min, Z axes 50 m/min, Y1 axis 20 m/min
- Two powered tool holders listed

CNC and extras
- Drives: Fanuc
- CNC: MSX701 MAPPS III
- Machine dimensions: 3930 x 2710 mm (154.72 x 106.69 in)
- Total machine weight: 8100 Kg
- Total installed power: 77 kVA
- Tool presetting: yes
- Bar loader: yes

Notes
The technical data above is taken from the provided specifications. These data may be incomplete or contain inaccuracies; inspection and confirmation of the details are recommended prior to purchase.

The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.

Seller's description

Category
Lathe
Type
CNC
Brand
MORI SEIKI
Model
NZ1500T2Y
Capacity
ø320/52x260 mmø12.60/2.05x10.24 in
Year of manufacture
11/2007 (in service 05/2008)

Technical specifications
Convert toMetricImperial
WORKING AREA
Center height
52
Max turning diameter
320 mm12.60 in
Notes
max swing 800mm - distance between spindles 1130mm
MAIN SPINDLE
Maximum rotation speed
6000 rpm
Spindle nose
ASA5”
Spindle bore
61 mm2.40 in
Inner bearing diameter
100 mm3.94 in
C axis resolution
0.001 °
C axis speed
6000 rpm
Maximum power
22 kW
SUB SPINDLE
Maximum rotation speed
6000 rpm
Spindle nose
ASA5”
Spindle bore
61 mm2.40 in
Inner bearing diameter
100 mm3.94 in
Maximum power
22 kW
C axis resolution
0.001 °
C axis speed
6000 rpm
Automatic B axis positioning
920 mm36.22 in
Self-centering diameter
152.4 mm6.00 in
TURRET 1
Number of positions
16
Y1 axis stroke
+65 / -45 mm+2.56 / -1.77 in
X1 axis stroke
210 mm8.27 in
Z1 axis stroke
810 mm31.89 in
Powered tool power
7.5 kW
Powered tool speed
6000 rpm
Rapid traverse X1 axis
30 m/min1,181.10 ipm
Rapid traverse Z1 axis
50 m/min1,968.50 ipm
Rapid traverse Y1 axis
20 m/min787.40 ipm
Number of powered positions
16
TURRET
Number of positions
16
Number of powered positions
16
Powered tool speed
6000 rpm
Powered tool power
7.5 kW
X axis stroke
210 mm8.27 in
Rapid traverse X
30 m/min1,181.10 ipm
Z axis stroke
810 mm31.89 in
Rapid traverse Z
50 m/min1,968.50 ipm
CNC
Drives
Fanuc
CNC
MSX701 MAPPS III
EXTRA
Machine dimensions
3930x2710 mm154.72x106.69 in
Total machine weight
8100 Kg
Total installed power
77 kVA kW
Tool presetting
yes
Bar loader
yes
Powered tool holders
2
The supplied data is based on the information available to us, where possible obtained from manufacturers; therefore, despite good faith, given the nature and complexity of the equipment, these data may be incomplete and/or inaccurate and in no case their accuracy can be guaranteed nor constitute any contractual obligation. We always recommend inspecting the equipment and requesting confirmation of the data.

Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.


Client type Machinery dealer
Active since 2007
Offers online 181
Last activity Oct. 30, 2026

GAMBA MACCHINE S.R.L Top seller

GAMBA GIOVANNI S.R.L., known by its brand Gamba Macchine, is a trusted Italian company with over 70 years of experience in the machine tool industry. Based in Gardone Val Trompia in the heart of Italy’s industrial region, the company specializes in the sale of high-quality new and used metalworking machinery for chip removal processes.

Founded in 1950 by Giovanni Gamba, the company has grown into a reference point for precision and reliability in the European industrial market. Today, it is managed by the second and third generations of the Gamba family who continue to uphold a strong tradition of technical expertise and customer-oriented service.

Gamba Macchine operates from two strategic locations in the province of Brescia, offering a wide range of machinery from leading international manufacturers. Their deep knowledge of production processes allows them to assist clients in finding the most suitable and efficient solutions for their machining needs.

With a strong focus on quality, performance, and after-sales support, Gamba Macchine is the ideal partner for companies looking to invest in reliable and cost-effective metalworking solutions. Whether you need a single machine or a complete production line, Gamba Macchine delivers value, expertise, and confidence.

GAMBA MACCHINE S.R.L

Seller's description

Category
Lathe
Type
CNC
Brand
MORI SEIKI
Model
NZ1500T2Y
Capacity
ø320/52x260 mmø12.60/2.05x10.24 in
Year of manufacture
11/2007 (in service 05/2008)

Technical specifications
Convert toMetricImperial
WORKING AREA
Center height
52
Max turning diameter
320 mm12.60 in
Notes
max swing 800mm - distance between spindles 1130mm
MAIN SPINDLE
Maximum rotation speed
6000 rpm
Spindle nose
ASA5”
Spindle bore
61 mm2.40 in
Inner bearing diameter
100 mm3.94 in
C axis resolution
0.001 °
C axis speed
6000 rpm
Maximum power
22 kW
SUB SPINDLE
Maximum rotation speed
6000 rpm
Spindle nose
ASA5”
Spindle bore
61 mm2.40 in
Inner bearing diameter
100 mm3.94 in
Maximum power
22 kW
C axis resolution
0.001 °
C axis speed
6000 rpm
Automatic B axis positioning
920 mm36.22 in
Self-centering diameter
152.4 mm6.00 in
TURRET 1
Number of positions
16
Y1 axis stroke
+65 / -45 mm+2.56 / -1.77 in
X1 axis stroke
210 mm8.27 in
Z1 axis stroke
810 mm31.89 in
Powered tool power
7.5 kW
Powered tool speed
6000 rpm
Rapid traverse X1 axis
30 m/min1,181.10 ipm
Rapid traverse Z1 axis
50 m/min1,968.50 ipm
Rapid traverse Y1 axis
20 m/min787.40 ipm
Number of powered positions
16
TURRET
Number of positions
16
Number of powered positions
16
Powered tool speed
6000 rpm
Powered tool power
7.5 kW
X axis stroke
210 mm8.27 in
Rapid traverse X
30 m/min1,181.10 ipm
Z axis stroke
810 mm31.89 in
Rapid traverse Z
50 m/min1,968.50 ipm
CNC
Drives
Fanuc
CNC
MSX701 MAPPS III
EXTRA
Machine dimensions
3930x2710 mm154.72x106.69 in
Total machine weight
8100 Kg
Total installed power
77 kVA kW
Tool presetting
yes
Bar loader
yes
Powered tool holders
2
The supplied data is based on the information available to us, where possible obtained from manufacturers; therefore, despite good faith, given the nature and complexity of the equipment, these data may be incomplete and/or inaccurate and in no case their accuracy can be guaranteed nor constitute any contractual obligation. We always recommend inspecting the equipment and requesting confirmation of the data.

Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.


Specifications

Category Lathes - CNC lathes
Turning length 810 mm
Turning Ø 320 mm
Ø above the bed 800 mm
Ø above transversing slide 800 mm
Length between centers 1130 mm
Type of CNC
X-axis 210 mm
Z-axis 810 mm
Spindle taper
Spindle bore 61 mm
Number of turrets 3
Number of tools on turret 16
Number of rotating tools 16
Turning speed 6000 rpm
Spindle motor power 22 kW
Tailstock no
Bar feeder no
Weight 8100 kg
worked hours
hours under power
state as-is, where-is
At local norms ---------
status
Datasheet Mori Seiki NZ1500T3Y3
Last availability date 28/10/2026
Product id P260723026
Language

Automatic description (AI-Generated)

Overview
This listing is for a MORI SEIKI NZ1500T2Y CNC lathe, specified with a capacity of ø320/52x260 mm (ø12.60/2.05x10.24 in). The machine is shown with a manufacture date of 11/2007 and noted as having entered service in 05/2008.

Key working area and notes
- Center height: 52 mm
- Maximum turning diameter: 320 mm (12.60 in)
- Additional notes: maximum swing 800 mm; distance between spindles 1130 mm

Spindles
- Main spindle: 6000 rpm maximum, ASA5" spindle nose, 61 mm (2.40 in) spindle bore, inner bearing diameter 100 mm (3.94 in), C-axis resolution 0.001°, C-axis speed 6000 rpm, maximum power 22 kW
- Sub spindle: 6000 rpm maximum, ASA5" spindle nose, 61 mm (2.40 in) spindle bore, inner bearing diameter 100 mm (3.94 in), C-axis resolution 0.001°, C-axis speed 6000 rpm, maximum power 22 kW
- Automatic B-axis positioning: 920 mm (36.22 in)
- Self-centering diameter: 152.4 mm (6.00 in)

Turrets and tooling
- Two 16-position turrets (TURRET 1 and second turret), each with 16 positions and 16 powered positions
- Powered tool speed: 6000 rpm
- Powered tool power: 7.5 kW
- TURRET 1 axes: X1 stroke 210 mm, Z1 stroke 810 mm, Y1 stroke +65 / -45 mm
- Rapid traverses: X axes 30 m/min, Z axes 50 m/min, Y1 axis 20 m/min
- Two powered tool holders listed

CNC and extras
- Drives: Fanuc
- CNC: MSX701 MAPPS III
- Machine dimensions: 3930 x 2710 mm (154.72 x 106.69 in)
- Total machine weight: 8100 Kg
- Total installed power: 77 kVA
- Tool presetting: yes
- Bar loader: yes

Notes
The technical data above is taken from the provided specifications. These data may be incomplete or contain inaccuracies; inspection and confirmation of the details are recommended prior to purchase.

The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.


About this seller

Client type Machinery dealer
Active since 2007
Offers online 181
Last activity Oct. 30, 2026

GAMBA MACCHINE S.R.L Top seller

GAMBA GIOVANNI S.R.L., known by its brand Gamba Macchine, is a trusted Italian company with over 70 years of experience in the machine tool industry. Based in Gardone Val Trompia in the heart of Italy’s industrial region, the company specializes in the sale of high-quality new and used metalworking machinery for chip removal processes.

Founded in 1950 by Giovanni Gamba, the company has grown into a reference point for precision and reliability in the European industrial market. Today, it is managed by the second and third generations of the Gamba family who continue to uphold a strong tradition of technical expertise and customer-oriented service.

Gamba Macchine operates from two strategic locations in the province of Brescia, offering a wide range of machinery from leading international manufacturers. Their deep knowledge of production processes allows them to assist clients in finding the most suitable and efficient solutions for their machining needs.

With a strong focus on quality, performance, and after-sales support, Gamba Macchine is the ideal partner for companies looking to invest in reliable and cost-effective metalworking solutions. Whether you need a single machine or a complete production line, Gamba Macchine delivers value, expertise, and confidence.

GAMBA MACCHINE S.R.L
