Price on request
View price| Power in tons | 22 T |
| Metal length | 3000 mm |
| Power | 4000 W |
| Metal width | 1500 mm |
| Max thickness | 8 mm |
| CNC type | |
| Travel X | 3120 mm |
| Travel Y | 1250 mm |
| Max weight of the workpiece | 230 kg |
| ------------------- | |
| worked hours | |
| hours under power | 69000 hours |
| state | good |
| At local norms | --------- |
| status | packed |
| Datasheet | Trumpf TruMatic 7000 |
| Last availability date | 28/05/2026 |
This listing features a Trumpf Trumatic 7000 K02 combining machine, manufactured in 2011. It is designed for laser cutting and punching operations with a punching force of 22 tons and a laser power of 4000 W. The machine accommodates metal sheets up to 3000 mm in length and 1500 mm in width.
The Trumatic 7000 K02 comes equipped with a stable C-frame for easy access and riding ball tables. It includes a linear magazine for tool stations and clamps, featuring 21 tool stations and 4 clamps with a foot switch for clamp closing. The machine is fitted with a flap for punch parts measuring 500 x 500 mm, including sensors, and a fast flap for laser parts of the same size, also sensor-equipped. It features FocusLine, NitroLine, and FastLine functions, along with additional Xp- and Yp-axes, and an ejector cylinder for laser parts. The setup allows retrofit capability for conveyor belts on both punching and laser sides.
The laser system is a CO2 TruFlow 2700 with optimized standby and a maintenance-free radial turbine blower. The cutting head uses a lens with a 170 mm focal length and a universal quick-change device with bus connection. The electro-hydraulic punching head offers a rotatable single tool adapter with 360° rotation, manually adjustable presser foot force, programmable presser foot modes, tool length compensation, spray tool lubrication, and a chip vacuum system with state monitoring.
Control is managed via Rexroth IndraMotion MTX with a 15" TFT color screen and includes teleservice by internet and an automatic shutdown device. Data transfer options include USB and RJ45 network connections. Safety features include CE marking, bidirectional lightguards, quick switch-off hydraulic, and sheet collision detection.
Advanced functions include MultiTool, MultiBend, tapping, marking, engraving, deburring and rolling, softpunch, active die with spray lubrication, height movable clamps, repositioning cylinders, brush tables with loading and unloading aids, and a blow-out device for small parts.
Automation accessories visible and included are the SheetMaster sheet feeding system with suction frame (3000 x 1500 mm), peeler cup, vacuum sensor, central lubrication, sheet thickness sensor for double sheet check, and automatic clamp closing. The GripMaster system is also present, featuring a sheet skeleton with sensor, a 400 mm scissor table, and a tiltable sheet skeleton pallet (3000 x 1500 mm).
The machine is fitted with multiple conveyor belts and pallet platforms for efficient sheet handling, each labeled with a maximum load capacity of 3000 kg. The overall condition appears clean and well-maintained, located in a spacious and well-lit industrial warehouse environment. The control panel with display and emergency stop button is mounted on a stand near the machine for convenient operation.
This comprehensive setup is suitable for high-precision laser cutting and punching tasks in industrial applications requiring automated sheet handling and versatile tooling options.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Trumpf Trumatic 7000 1600 4000W (K02) FMC
Year: 2011
Machine hours: about 69.000 / 65.500 / 15.250 h
Standard equipement
- Stable C-frame for easy access
- Riding ball tables
- Linear magazine for tool stations and clamps
- 21 tool stations, 4 clamps – foot switch for closing of clamps
- Flap for punch parts 500 x 500 mm incl. sensor
- FocusLine
- NitroLine
- FastLine
- Additional Xp- and Yp- axis
- Ejector cylinder for laser parts
- Retrofit capability for conveyor belts (punching and laser side)
- Fast flap for laser parts 500 x 500 mm incl. sensor
- Liftable laser cutting support
- Slag cone detection
TRUMPF Laser
- CO2-Laser TruFlow 2700 incl. optimized standby
- Maintenance-free radial turbine blower
- Radio-frequency excitation
- Laser control TASC 3
Cutting head
- Lens cutting head with 170mm focal length
- Universal quickchange device for cutting head (UTI) with bus connection
- ControlLine
Punching head
- Electro-hydraulic punching head
- Rotatable single tool adapter 360° Rotation
- Presser foot force manually adjustable
- Programmable presser foot (active / passive / repositioning)
- Tool length compensation
- Spray tool lubrication
- Chip vacuum system with state monitoring
- Calculation of filling level in the punching console
- Level monitoring of tapping and tool lubrication
Control
- Control based on Rexroth IndraMotion MTX
- 15" TFT colour screen
- Teleservice by internet
- Automatic shut down device
- Production plan
Data transfer
- USB interface, RJ45 network connection
Safety
- CE-marking
- Bidirectional lightguards
- Quick switch-off hydraulic
- Sheet collision detection
Advanced equipement
- TruFlow 4000
- Function MultiTool
- Function MultiBend
- Function tapping
- Function marking
- Function Engraving
- Function Deburring and Rolling
- Function Softpunch
- Active die
- Spray lubrification for die
- Height movable clamps
- Repositioning cylinders
- Brush tables with loading and unloading aid
- Blow-out device small parts
Automation
Sheetmaster
Standard equipement
- Suction frame 3000 x 1500
- Peeler cup
- Vacuum sensor
- Central lubrification
- Sheet thickness sensor for double sheet check
- Clamp closing automatically
GripMaster
Standard equipement
- Sheet skeleton with sensor
- Scissor table 400 mm
- Sheet skeleton pallet tiltable 3000 x 1500
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
What capabilities does this Trumpf Trumatic 7000 K02 have?
This Trumpf Trumatic 7000 K02 is a combining machine that features both laser and punch capabilities.
When was this Trumpf Trumatic 7000 K02 manufactured?
This Trumpf Trumatic 7000 K02 was manufactured in the year 2011.
The following questions and answers are generated using artificial intelligence based on the product information available. They are provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
