| Manufacturer | TORNOS |
|---|---|
| Model | AS 14-6 |
| Year | |
| Location | Italy
|
This TORNOS AS 14-6 is a multispindle automatic lathe designed for efficient high-volume production. It features six spindles capable of handling bar stock with a maximum diameter of 14 mm for round bars, 10 mm for square bars, and 12 mm for hexagonal bars. The maximum feeding length is 75 mm, making it suitable for producing small to medium-sized parts. The spindle speed ranges from 900 to 6000 rpm across 16 selectable speeds, allowing for versatile machining operations. The machine supports 22 different production cycles, with output rates ranging from approximately 4.9 to 72 parts per minute, or cycle times between 12.2 and 0.84 seconds per part. The fixed ratio for cross slides 1 through 4 is 1:1, while the cam-driven cross slides 5 and 6 have an adjustable ratio between 0.8:1 and 1.2:1, providing flexibility in tool movement. Powered by a 7.5 hp motor running at 1450 rpm, this lathe includes three rapid feed options and six cross units for complex machining tasks. Additional features include pick-up and back drilling capabilities, cams, tool holders, gears, a chip conveyor, and a short pieces detector as standard accessories. The machine dimensions are approximately 2700 mm in length, 1000 mm in width, and 1650 mm in height, with a weight of 2200 kg. Visually, the lathe is equipped with a protective blue and transparent cover, a control panel with dials and switches on the front side, and a clearly visible TORNOS brand label on the side panel. The machine appears clean and well-maintained with no visible rust or damage, indicating good overall condition.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
6 spindles
Max bar size diameter: round 14 mm, square 10 mm, hexagonal 12 mm
Max feeding length 75 mm.
Spindle: number of speed 16, rounds for minute 900-6000 rpm. N. 22 production cycles
Range of production cycles: (parts for minute) 4.9 to 72. (second for parts) 12.2 to 0.84.
Fixed ratio of range with cross slides No. 1-2-3-4 1:1.
Adjustable ratio of the cam with cross slides No. 5 e 6 0.8:1 to 1.2:1
Motor power 7.5 hp. Motor speed 1450 rpm
N. 3 rapid feed
6 cross units. Machine dimension for shipment 7.5 m£. Pick up + back drilling. Cams, tool-holders, gears. Chips conveyor. Short pieces detector.Standard accessories
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Machinery dealer |
| Active since | 2013 |
| Offers online | 48 |
| Last activity | Oct. 18, 2026 |
6 spindles
Max bar size diameter: round 14 mm, square 10 mm, hexagonal 12 mm
Max feeding length 75 mm.
Spindle: number of speed 16, rounds for minute 900-6000 rpm. N. 22 production cycles
Range of production cycles: (parts for minute) 4.9 to 72. (second for parts) 12.2 to 0.84.
Fixed ratio of range with cross slides No. 1-2-3-4 1:1.
Adjustable ratio of the cam with cross slides No. 5 e 6 0.8:1 to 1.2:1
Motor power 7.5 hp. Motor speed 1450 rpm
N. 3 rapid feed
6 cross units. Machine dimension for shipment 7.5 m£. Pick up + back drilling. Cams, tool-holders, gears. Chips conveyor. Short pieces detector.Standard accessories
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
This TORNOS AS 14-6 is a multispindle automatic lathe designed for efficient high-volume production. It features six spindles capable of handling bar stock with a maximum diameter of 14 mm for round bars, 10 mm for square bars, and 12 mm for hexagonal bars. The maximum feeding length is 75 mm, making it suitable for producing small to medium-sized parts. The spindle speed ranges from 900 to 6000 rpm across 16 selectable speeds, allowing for versatile machining operations. The machine supports 22 different production cycles, with output rates ranging from approximately 4.9 to 72 parts per minute, or cycle times between 12.2 and 0.84 seconds per part. The fixed ratio for cross slides 1 through 4 is 1:1, while the cam-driven cross slides 5 and 6 have an adjustable ratio between 0.8:1 and 1.2:1, providing flexibility in tool movement. Powered by a 7.5 hp motor running at 1450 rpm, this lathe includes three rapid feed options and six cross units for complex machining tasks. Additional features include pick-up and back drilling capabilities, cams, tool holders, gears, a chip conveyor, and a short pieces detector as standard accessories. The machine dimensions are approximately 2700 mm in length, 1000 mm in width, and 1650 mm in height, with a weight of 2200 kg. Visually, the lathe is equipped with a protective blue and transparent cover, a control panel with dials and switches on the front side, and a clearly visible TORNOS brand label on the side panel. The machine appears clean and well-maintained with no visible rust or damage, indicating good overall condition.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
