| Manufacturer | TECHNO COATING ENGINEERING |
|---|---|
| Model | 2000/5 PLUS 4E |
| Year | 2005 |
| Location | Spain
|
Manufacturer: TECHNO COATING ENGINEERING
Model: 2000/5 PLUS 4E
Year Manufactured: 2005
This industrial extrusion line is designed for the production of multilayer stretch film with a film width of 2000 mm and a mechanical speed of up to 600 m/min. The system features a 5-layer film structure labeled ACBCD, utilizing LLDPE material. The total output capacity is 1350 kg/h.
The extrusion setup includes multiple extruders aligned in parallel. Key extruders include:
- Extruder 1 (Layer A): Screw diameter 80 mm, L/D ratio 30, bimetallic cylinder, motor power 85 kW AC, heating power 28 kW, RPM 130. Equipped with a gravimetric dosing unit for 4 components and a hydraulic screen changer.
- Extruder 2 (Layer B): Screw diameter 160 mm, L/D 30, bimetallic cylinder, motor power 300 kW AC, heating power 90 kW, RPM 110. Features include gravimetric dosing for 4 components, hydraulic screen changer, thermo regulation, cooling in grain feeding area, and an additional extruder for trimmed edge refeeding.
- Extruder 3 (Layer C): Screw diameter 130 mm, L/D 30, bimetallic cylinder, motor power 200 kW AC, heating power 75 kW, RPM 130. Also equipped with gravimetric dosing for 4 components and hydraulic screen changer.
- Extruder 4 (Layer D): Screw diameter 80 mm, L/D 30, bimetallic cylinder, motor power 85 kW AC, heating power 28 kW, RPM 130, with gravimetric dosing and hydraulic screen changer.
The system includes an EDI Autoflex IVH 40 extrusion head with adjustable gap from 0.1 to 1 mm, featuring a double-chamber airknife, double vacuum box, two 4 kW fans, and edge pinning. The die width is 2600 mm.
Downstream equipment includes two chill rollers with independent drives (first roller diameter 960 mm, second 450 mm; width 2700 mm), an automatic thickness control system with 91 thermobolts, and an E&L web guide system. The rewinder is a Colines model from 2015, capable of handling both hand and machine reels.
Additional features comprise edge slit, grinding and refeed system integrated into extruder B, pneumatic transport system between components, and buffering silos for material handling.
The machine is equipped with feeding hoppers labeled 'DOTECQ' above each extruder, multiple heating zones on extruder barrels with yellow protective covers on motor ends, and numerous interconnected pipes and hoses for material or cooling fluid transport. The overall condition appears clean and well-maintained with no visible damage or rust.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Manufacturer: TECHNO COATING ENGINEERING
Model: 2000/5 PLUS 4E
Year: 2004
Number of layers: 5
Overhaul/renovation: New winder 2015
Film structure: ACBCD
Material: Stretch film LLDPE
Film width (mm): 2000
Speed (m/min): 600 mechanical
Output (Kg/h): 1350
Extruder 1 Layer ref: : A
Screw diameter 1: 80mm
Description 1: Tecno Coating Engineering L/D 30. Bimetallic cylinder. Motor Power 85 kw AC. Heating power 28 kw. RPM 130. Gravimetric dosing unit, 4 components. Hydraulic screen changer.
Extruder 2 Layer ref:: B Screw diam 2: 160mm
Description 2: Tecno Coating Engineering. L/D30. Bimetallic cylinder. RPM 110. Motor power 300 kw AC. Heating power 90 kw. Gravimetric dosing unit, 4 components. Hydraulic screen changer. Thermo regulation and cooling in grain feeding area. Extruder B2 for trimmed edge refeeding. Screw diam. 130mm;
Extruder 3 Layer ref:: C Screw diam 3: 130mm
Description 3: Tecno Coating Engineering. L/D 30mm. Bimetallic cylinder. RPM 130. Motor power 200 kw AC; Heating power 75kw; Gravimetric dosing unit 4 components. Hydraulic screen changer.
Extruder 4 Layer ref: : D Screw diam 4: 80mm
Description 4: Tecno Coating Engineering. L/D 30. Bimetallic cylinder. Motor Power 85 kw AC. Heating power 28 kw. RPM 130. Gravimetric dosing unit 4 components. Hydraulic screen changer.
Head description: Brand EDI- Autoflex IVH 40. Gap 0,1-1mm. Airknife double chamber. Vacuum box, double. 2 fans 4 kw each; edge pinning.
Die width (mm): 2600
Chill roll unit: 2 chill rollers with independent drive. 1st 960mm diam; 2nd 450mm diam. Width 2700mm.
Thickness controll system: Automatic thickness control 91 Thermobolts
Web guide: E&L
Rewinder description: Hand reels and machine reels Make: Colines year 2015,
Additional Information:
Edge slit, grinding and refeed in extruder B through additional. Edge trim and recycling system, pneumatic transport system between all components. Buffering silos.
