Pfauter P400

TAILLEUSE PFAUTER P400 Year 1976 P630 Year 1974 P900 Year 1974 CE Machinery Machines all in good condition always maintained Tools will be left with the documentation machines

Table diameter: 400mm Tangential head Maximum tilt: 240 ° Race shifting Max: 100mm Distance Min / Max table / tailstock: 638 mm Speed Range: 80-500 rpm Radial feed: 0.2 to 2.45 mm / min Axial feed: 0.4 -4.9 mm / min

3 units available

After overhaul in 80ś Excellent condition Limited number of change gears

Year: 1968 Shifting Two cut cicle

Make - Pfauter (Germany) Model - P400 Max. Diameter of Gear - 400 mm Max. Module of Gear - 8 module Table Bore - 80 mm Many milling tools included

WORKING CAPACITY Max. module to cut: mm. 8 Max. diameter of piece: mm. 400 Max. travel of mill-holder slide: mm. 310 Min. nr. of cutting gears (indexing gear with one thread): 6 DIMENSIONS Diameter of piece-holder table: mm. 400 Bore diameter of table: mm. 80 Diameter of piece-holder spindle: mm. 36 Max. dimension of milling cutter: - diameter: mm. 160 - length: mm. 160 Diameter of spindle mill-holder: - with normal accessory: mm. 32, 40 - with special accessory: mm. 22, 27, 50 Centre distance between milling and piece: - max. centre distance: mm. 290 - min. centre distance: mm. 20 Cone morse: 4 Max. movement of milling cutter: - tangential cut: mm. 126 - shifting: mm. 120 NUMBER OF ROUND AND FEEDS Milling cutter rpm: rpm 80-500 Axial feed: mm/min 0.4-7.5 Radial feed: mm/min. 0.1-1.9 Tangential feed: mm/min. 0.16-3 ELECTRIC EQUIPMENT Voltage: V 220/380 Frequency: Hz 50 WEIGHT AND DIMENSIONS Weight of machine: kg. 6200 Length: mm. 4680 Width: mm. 2395 Height: mm. 2515
