Kolbus DA 270

Manufacturer	Kolbus
Model	DA 270
Category	Case making machines

Used Kolbus DA 270 Case making machine Sold

France 2003

Max.Size:67 x 39 cm (26 x 15 inch) Counter stacker Padded Case device Motorized format adjustment Inside Lining Board Pre-stacker Viscosity control device Board Centre Strip

Used KOLBUS DA 270 Case making machine Sold

United Kingdom 2002

Min case size 140 x 205 mm, Max case size 670 x 390 mm, Max board thickness 4mm, Board Pre-stacker, Padded Case device, Inside Lining, Board Centre Strip, Viscosity control device, counter stacker, motorized format adjustment, 65 cycles/min

Kolbus DA 270 Case-Binding machine Sold

France 2010

Board soft Centre Strip Board cutter Viscosity control device Max.Size:67 x 39 cm (26 x 15 inch)

Kolbus DA 270 Case making machine Sold

Germany 2002

Built in 2002 Size max: 670x390 mm Size min: 205x140 mm Speed: 3.900 c/h

Kolbus DA 270 Case packer Sold

Germany 2003

Built in 2003 Size max 670x390 mm min 205x140 mm Speed 3.900 c/h

Used Kolbus DA 270 Case maker Sold

Poland 2010

We have for sale Kolbus DA 270: Year: 2010 Cover size max: 670 x 390 mm Cover size min : 205 x 140 mm Speed : 65 cycl/min Condition: Perfect Location : Europe Available immediately

KOLBUS DA 270 Case making machine Sold

Portugal 2003

Kolbus DA 270 year 2003

Kolbus DA 270 Case making machine Sold

Netherlands 2006

Kolbus DA 270 Case making machine Programmable automatic setting, motorized adjustments Board prestacking conveyor Board cutter: PS Centre strip infeed Chopper for the centre strip waste Viscosity control Glue unit with pre-heated glue tube Cloth feeder Pressing station Stacking delivery TECHNICAL SPECIFICATIONS Specifications are subject to manufacturers changes in similar models Maximum open case size : 670 x 390 mm Maximum open case size : 205 x 140 mm Joint width: 4 – 15 mm Width between boards: 14 – 120 mm Turning in width: 8 – 15 mm Cloth width: 223 – 708 mm Cloth height: 130 – 428 mm Board thickness: 1 – 4 mm. Board width: 95 – 328 mm Board height: 140 – 390 mm Board center strip thickness: 1 – 4 mm. Board center strip width: 6 – 90 mm Centre strip roll thickness: 0,3 – 0,6 mm Centre strip roll thickness: 6 – 90 mm Maximum mechanical speed: 65 cycles/min Full specifications on request CONNECTION & DIMENSIONS Machine dimensions: 6200 x 3000 x 2200 mm Weight: 5850 kg Power supply: 400 V, 50Hz, 3 phases Power supply: 28 Nm3/h – 6 bar

Kolbus DA 270 Case Making Machine Sold

USA 2005

Kolbus DA 270 casemaker year 2005 Copilot System with touchscreen Board prestacking conveyor Cloth feeder for non-stop operation with pile magazine Counter stacker delivery with following roller conveyor Programmable automatic setting, motorized adjustment, fault indication Device for processing centre strip rolls Technical details Case size min (width x height) (mm): 205 x 140 mm Case size max (width x height) (mm): 670 x 390 mm Cloth width: 223 - 708 mm Cloth height: 130 - 428 mm Board thickness: 1 - 4 mm Mechanical speed max: 65 cycles/min Available after agreement

Sell your machines to buyers worldwide

Join 10,000+ companies already selling with us

Reach 500,000+ monthly visitors

Sell faster at a great price

No hidden fees, it's free

Sell your machine

or contact us

Kolbus DA 270 Case making machine Sold

Poland 2010

Cover size max: 670 x 390 mm Resolution of the cover min: 205 x 140 mm Speed: 65 cycl / min

Used KOLBUS DA 270 Case making machine Sold

Poland 2010

Used KOLBUS DA 270 Sold

Germany 2009

KOLBUS DA 270 - year: 2009. - ser. nr. 21x counter 45,19 Mio cases - basic machine Inch. board pre-stacking conveyors (3x400 volt, 65 cycles) - roll center strip device incl. chopper - animal glue processing - viscomat - with board center strip magazine - with small format + large format (height + width) attachments - adapter for plate preparation - available immediately

Kolbus DA 270 Case making machine Sold

Bulgaria 2005

Kolbus DA 270 casemaker year 2005 Copilot System with touchscreen Board prestacking conveyor Cloth feeder for non-stop operation with pile magazine Counter stacker delivery with following roller conveyor Programmable automatic setting, motorized adjustment, fault indication Device for processing centre strip rolls Technical details Case size min (width x height) (mm): 205 x 140 mm Case size max (width x height) (mm): 670 x 390 mm Cloth width: 223 - 708 mm Cloth height: 130 - 428 mm Board thickness: 1 - 4 mm Mechanical speed max: 65 cycles/min Available after agreement

Kolbus DA270 Case making machine Sold

Czech Republic 2002

Equipped with: . Board prestacking conveyor for automatic magazine reloading (stream and pile feeding) Centre strip infeed for the spine strip made of roll material, holding capacity for 2 centre strip rolls, longitudinal and cross cutting device Chopper for the centre strip waste Device for automatic pasting and changing of endless spine strip with the machine running Cloth feeder for non stop operation with pile magazine, max. stacking height 160 mm Miss cloth control during the separation process Counter stacker delivery with following roller conveyor Moveable gluing station for processing hot-glue with glue preparation unit in the premelter, heated glue application roller and scraper roller Glue application adjustment by outside control Viscosity control device for automatic water supply to ensure constant glue viscosity Pressing roller device for crease-free connection of the cover material with boards and spine strip Device for producing padded cases Device for inside lining with hot-glue Automatic case counter Programmable automatic setting, motorized adjustments, fault indication Single case request for control purposes done from the operating side Board centre strip magazine Device for inside lining with cold-glue . Technical specifications: Max. open cover size : 670 x 390 mm Min. open cover size : 205 x 140 …

Kolbus DA 270 Case making machine Sold

Netherlands 2002

Kolbus DA 270 Case making machine Programmable automatic setting, motorized adjustments Board prestacking conveyor Centre strip infeed Chopper for the centre strip waste Third transporter for stiff spine board Viscosity control Glue unit with pre-heated glue tube Cloth feeder Pressing station Stacking delivery TECHNICAL SPECIFICATIONS Specifications are subject to manufacturers changes in similar models Maximum open case size : 670 x 390 mm Maximum open case size : 205 x 140 mm Joint width: 4 – 15 mm Width between boards: 14 – 120 mm Turning in width: 8 – 15 mm Cloth width: 223 – 708 mm Cloth height: 130 – 428 mm Board thickness: 1 – 4 mm. Board width: 95 – 328 mm Board height: 140 – 390 mm Board center strip thickness: 1 – 4 mm. Board center strip width: 6 – 90 mm Centre strip roll thickness: 0,3 – 0,6 mm Centre strip roll thickness: 6 – 90 mm Maximum mechanical speed: 65 cycles/min Full specifications on request CONNECTION & DIMENSIONS Machine dimensions: 6200 x 3000 x 2200 mm Weight: 5850 kg Power supply: 400 V, 50Hz, 3 phases Power supply: 28 Nm3/h – 6 bar

Kolbus DA 270 Case making machine Sold

Netherlands 2007

length	6200 mm
height	2200 mm

width	3000 mm
weight	5850 kg

Kolbus DA 270 Case making machine Sold

Spain 2007

length	6200 mm
height	2200 mm

width	3000 mm
weight	5850 kg

Kolbus DA 270 - Perfect Binders Sold

Poland 2004

length	205 mm

width	140 mm

-------------------
Length x width x height	6200.0 × 3000.0 × 2200.0
Weight	5850 kg
