| Manufacturer | Schmidt |
|---|---|
| Model | SIGMA 17 RBL |
| Year | 1990 |
| Location | Netherlands
|
Schmidt SIGMA 17 RBL plate heat exchanger for industrial heat-transfer applications. The unit is identified as a Schmidt Bretten GmbH plate heat exchanger and has stainless-steel construction. Its listed heating surface is 4.4 m², and it is fitted with 26 plates. The listed connections are four 40 mm connections. The stated maximum operating temperature is 100 °C, and the listed working pressure is 10 bar.
Overall dimensions are 600 mm long, 300 mm wide and 1,100 mm high. The listed weight is 170 kg. These overall dimensions are separate from the plate-size information in the original specifications; plate dimensions are not included here.
The SIGMA 17 RBL is suitable for buyers seeking a plate heat exchanger with stainless-steel construction, a defined heating surface and multiple plate connections. Its compact stated footprint and overall height may be useful when assessing installation space, while the listed weight can assist with handling and transport planning. Confirm that its temperature and pressure ratings, connection arrangement and other listed characteristics suit the intended process before purchase.
The available description does not specify condition, operating status, service history or included accessories. No claim is made regarding testing or functionality. Further performance details, including flow rate and the fluids previously processed, are not stated.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
General
SKU: 040F329
Location: Barneveld
Type: Sigma 17 RBL
No.: 61/56219/06
Pressure
Working pressure: 10 Bar
Main Features
Material: Stainless steel
Surface: 4.4 m2
Size length: 190 mm
Sizes width: 850 mm
Specified Features - Plate heat exchanger
Plate heat exchangers: (1x) make Schmidt Bretten GmbH
Heating surface: 4,4 m2
Capacity: 6,5/6,0 Ltr
Number of platens: 26
Plate sizes: ± 190x850mm
Connections: 4x dia. 40mm
Max. temperature: 100 Degr. C.
Material: Stainless steel
General
Year of construction: 1990
Floorspace: 0,6x0,3 M
Total height: 1,1 M
Weight: 170 KG
Extra information
Extra Specifications: indicated size is platen size
Material: Stainless steel
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
