Contact us to receive an offer.
| Manufacturer | REISHAUER |
|---|---|
| Model | US |
| Year | |
| Location | Switzerland
|
Machine specifications
Maximum grinding length: 450 mm. Maximum clamping length: 1,055 mm. Maximum workpiece diameter: 250 mm. The stated thread-diameter range is 2–250 mm. Workpiece spindle bore: 45 mm. Maximum workpiece weight between centres: 200 kg. Maximum thread pitch: 100 mm; no minimum thread-pitch value is provided. Maximum angular pitch is +40° / −40°. Maximum module: 10.
Grinding wheel specifications
Wheel diameter: 280–350 mm. Wheel width: 4–40 mm. Wheel bore: 40 mm. The grinding-wheel speed has 6 steps, ranging from 1,700 to 2,540 rpm.
Spindle and electrical data
The workpiece spindle head has 27 speed steps, with a stated maximum speed of 160 rpm; no minimum speed is specified. Electrical supply: 3-phase, 380 V, 50 Hz. Grinding spindle motor: 4 kW. Total power requirement: 15 kVA.
Weight and overall dimensions
Approximate machine weight: 4,700 kg. Overall dimensions: 3,300 mm long, 1,930 mm wide and 1,800 mm high.
Listed accessories
The description lists a coolant system, a set of grinding wheels, a set of flanges, a redressing device, a set of gears, a set of centres and an oil mist extractor. No further details about the accessories or the machine’s operating condition are provided.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Max. grinding length 450 mm
Max. clamping length 1055 mm
Max. work piece diameter 250 mm
Thread diameter:
min. 2 mm
max 250 mm
Workpiece spindle bore 45 mm
Workpiece weight on centres max. 200 kg
Thread pitch:
min. mm
max 100 mm
Max. angle pitch + 40 °
Max. angle pitch - 40 °
Max. module 10
Grinding wheels:
Diameter:
min. 280 mm
max 350 mm
Width:
min. 4 mm
max 40 mm
Bore 40 mm
Grinding-wheel speeds:
number (steps) 6
from 1700 t/min
up to 2540 t/min
Work-piece spindle head speed:
number (steps) 27
from t/min
up to 160 t/min
Voltage 50 Hz 3x 380 Volt
Grinding spindle motor 4 kW
Total power required 15 kVA
Machine's weight about 4700 kg
Overall dimensions machine:
Length 3300 mm
Width 1930 mm
Height 1800 mm
Various accessories:
Coolant system
Set of grinding wheels
Set of flanges
Redressing device
Set of gears
Set of centers
Oil mist extractor
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Machinery dealer |
| Active since | 2014 |
| Offers online | 255 |
| Last activity | Oct. 29, 2026 |
Max. grinding length 450 mm
Max. clamping length 1055 mm
Max. work piece diameter 250 mm
Thread diameter:
min. 2 mm
max 250 mm
Workpiece spindle bore 45 mm
Workpiece weight on centres max. 200 kg
Thread pitch:
min. mm
max 100 mm
Max. angle pitch + 40 °
Max. angle pitch - 40 °
Max. module 10
Grinding wheels:
Diameter:
min. 280 mm
max 350 mm
Width:
min. 4 mm
max 40 mm
Bore 40 mm
Grinding-wheel speeds:
number (steps) 6
from 1700 t/min
up to 2540 t/min
Work-piece spindle head speed:
number (steps) 27
from t/min
up to 160 t/min
Voltage 50 Hz 3x 380 Volt
Grinding spindle motor 4 kW
Total power required 15 kVA
Machine's weight about 4700 kg
Overall dimensions machine:
Length 3300 mm
Width 1930 mm
Height 1800 mm
Various accessories:
Coolant system
Set of grinding wheels
Set of flanges
Redressing device
Set of gears
Set of centers
Oil mist extractor
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
Machine specifications
Maximum grinding length: 450 mm. Maximum clamping length: 1,055 mm. Maximum workpiece diameter: 250 mm. The stated thread-diameter range is 2–250 mm. Workpiece spindle bore: 45 mm. Maximum workpiece weight between centres: 200 kg. Maximum thread pitch: 100 mm; no minimum thread-pitch value is provided. Maximum angular pitch is +40° / −40°. Maximum module: 10.
Grinding wheel specifications
Wheel diameter: 280–350 mm. Wheel width: 4–40 mm. Wheel bore: 40 mm. The grinding-wheel speed has 6 steps, ranging from 1,700 to 2,540 rpm.
Spindle and electrical data
The workpiece spindle head has 27 speed steps, with a stated maximum speed of 160 rpm; no minimum speed is specified. Electrical supply: 3-phase, 380 V, 50 Hz. Grinding spindle motor: 4 kW. Total power requirement: 15 kVA.
Weight and overall dimensions
Approximate machine weight: 4,700 kg. Overall dimensions: 3,300 mm long, 1,930 mm wide and 1,800 mm high.
Listed accessories
The description lists a coolant system, a set of grinding wheels, a set of flanges, a redressing device, a set of gears, a set of centres and an oil mist extractor. No further details about the accessories or the machine’s operating condition are provided.
