Used CNC Swiss Lathes for Sale 200

CNC Swiss-type lathes use a sliding headstock and guide bushing to support the workpiece immediately adjacent to the cutting tool, eliminating deflection on slender parts with high length-to-diameter ratios. Modern Swiss machines offer driven tools, sub-spindles, and six or more CNC axes that produce finished parts — including milling, cross-drilling, and threading — in a single operation. Bar capacities typically span 1mm to 38mm for medical devices, electronics, watchmaking, and precision connector production.

Used CNC Swiss lathes on Exapro cover the full bar capacity range. Filter by bar diameter, axis count, and guide bushing capability. Submit an enquiry through the listing page for specifications.

Showing 1 - 20 out of 200

Relevancy Manufacturer Product year (recent) Product year (old) Price (high to low) Price (low to high) Date added (newest) Date added (oldest)
Swiss-type lathes use a fundamentally different machining approach from conventional CNC lathes. The headstock slides along the Z-axis, feeding bar stock through a guide bushing that supports the workpiece immediately adjacent to the cutting tool. This close support eliminates deflection, enabling exceptionally accurate turning of slender parts with length-to-diameter ratios that would cause vibration and inaccuracy on conventional lathes.

Guide bushing operation is the defining feature, supporting the bar stock within millimetres of the cutting zone. The unsupported workpiece length remains constant regardless of part length, maintaining consistent cutting conditions from the first feature to the last. For parts like bone screws, dental implants, electrical pins, and watch components, this precision is non-negotiable.

Modern CNC Swiss machines have evolved far beyond simple turning. Current platforms offer driven tools on both main and sub-spindle sides, enabling milling, drilling, cross-drilling, and even gear cutting without removing the part. Six, seven, or more CNC axes work simultaneously, producing finished parts that drop into a collection bin requiring no secondary operations.

Bar capacity typically ranges from 1mm to 38mm, with the majority of machines handling 3mm to 25mm stock. The bar feeder system — integral to Swiss lathe productivity — must match the machine's speed and accuracy requirements. Verify bar feeder compatibility and condition when evaluating used machines.

Guide-bushing-less operation — available on some modern Swiss machines — accepts drawn bar stock rather than precision-ground material, reducing material costs. However, removing the guide bushing changes the machine's deflection characteristics and may limit the maximum slenderness ratio achievable on certain part geometries.

Browse used CNC Swiss lathes on Exapro to compare bar capacities, axis configurations, and guide bushing options from verified sellers.

When browsing used Swiss lathes on Exapro, check guide bushing bore condition and concentricity, verify spindle accuracy at operating speed, and inspect the precision of driven tool positions. Request sample parts produced on the machine to evaluate actual machining capability under realistic production conditions rather than relying solely on specification sheets.
