| Manufacturer | NKMZ |
|---|---|
| Model | HOT ROLLING MILL LINE - ALUMINIUM APPLICATION - SLAB 300-350 MM, WIDTH: 740-1540 MM |
| Year | 1972 |
| Location | Germany
|
Qty. 1 Second-hand Hot Rolling Mill Line
Manufacturer: NKMZ • Built: 1972
Overview
This listing is for a single second-hand hot rolling mill line manufactured by NKMZ (built 1972). The mill is specified with a roll force of 2300 T and a periphery roll speed (Mill Speed) given as 0-24-210 m/min. The specification sheet below lists slab, rolled product and coiling capabilities, together with details for rolls, bearings, screws and hydraulic components.
Slab / Feed material
- Slab thickness: 300–350 mm
- Slab width: 740–1540 mm
- Slab length: 1100–3000 mm
- Slab weight: 1–2.7 T
- Slab temperature: 370–550 °C
Rolled product / Coils
- Rolled thickness (plate): 8–200 mm
- Rolled width (plate): 750–1550 mm
- Plate length: 2000–8000 mm
- Coiled thickness: 6–12 mm
- Coiled width: 700–1550 mm
- Coil I.D./O.D.: 750/1400 mm
- Coiling temperature: 300–350 °C
Rolls, bearings and mechanicals
- Back-up roll diameters: 1500–1400 mm
- Work roll diameters: 800–760 mm
- Roll barrel length: 1800 mm
- Back-up roll bearings: 10777/850X 850/1360 x 310 mm
- Work roll bearings: 77788 440/650 x 335 mm
- Breast roll diameter: 350 mm
- Roll body length: 1300 mm
Screw, hydraulic and auxiliary data
- Screw down speed: 8.7 / 17.4 m/min
- Screw diameter & pitch: 530 x 48 mm
- Ratio Motor to Screw: 47 kW
- Max. roll opening: 400 mm (Max opening limited by switch: 400 mm)
- Back-up roll balance cylinder: 400 x 665 mm
- Work roll balance cylinder: 180 mm
- Hydraulic pressure: 100 bar
- Housing post section: 5900 mm²
Notes
All specifications are reported as provided in the supplied equipment description. No additional information regarding operational status, recent testing or refurbishment is included in this description.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Qty. 1 Second-hand Hot Rolling Mill Line
Manufacturer: NKMZ Built: 1972 Roll Force: 2300 T
(Periphery roll speed)Mill Speed: 0-24-210 m/min.
Slab Thickness: 300-350 mm Width: 740-1540 mm Length: 1100-3000 mm
Slab Weight: 1-2.7 T Slab Temperature: 370 – 550 °C
Rolled Thickness: 8-200 mm Width: 750-1550 mm Plate Length: 2000-8000 mm
Coiled Thickness: 6 – 12 mm Coiled Width: 700-1550 mm
Coil I.D./O.D.: 750/1400 mm Coiling Temperature: 300-350 °C
Back-up Rolls Dia.: 1500 – 1400 mm Work Rolls Dia.: 800 – 760 mm
Roll Barrel Length: 1800 mm
Back-up Roll Bearings: 10777/850X 850/1360 x 310 mm
Work Roll Bearings: 77788 440/650 x 335 mm
Screw down speed: 8.7 / 17.4 m/min. Screw Dia. & Pitch: 530 x 48 mm
Ratio Motor to Screw: 47 kW Max. Roll Opening: 400 mm
Max Opening Limited by Switch: 400 mm
Back-up Roll Balance Cylinder: 400 x 665 mm
Work Roll Balance Cylinder: 180 mm Hydraulic Pressure: 100 bar
Housing Post Section: 5900 mm²
Breast Roll Diameter: 350 mm Roll Body Length: 1300 mm
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
