Contact us to receive an offer.
| Manufacturer | Martin |
|---|---|
| Model | T27 |
| Year | |
| Location | Germany
|
| Category | Moulders - Spindle moulding machines |
| Spindle Ø | 40 mm |
| Max. spindle speed | 4500 rpm |
| Engine power | 7.5 kW |
| Length x width x height | 1800.0 × 1050.0 × 1600.0 |
| Weight | 670 kg |
| worked hours | |
| hours under power | |
| state | good |
| At local norms | --------- |
| status | |
| Datasheet | Martin T27 |
| Last availability date | 16/10/2026 |
| Product id | P260810077 |
| Language |
Фреза с долен шпиндел Martin T27
Spodní frézka Martin T27
Martin T27 Spindelfræser
Martin T27 Tischfräse
Φρέζα με κάθετο άξονα Martin T27
Martin T27 Spindle moulder
Tupí Martin T27
Toupie Martin T27
Donjovretena glodalica Martin T27
Martin T27 Alsómaró
Toupie Martin T27
Martin T27 Apatinio veleno frezavimo staklės
Martin T27 Tafelfrees
Frezarka dolnowrzecionowa Martin T27
Tupia Martin T27
Mașină de frezat cu ax vertical Martin T27
Martin T27 Фрезерный станок с нижним шпинделем
Donjovretena glodalica Martin T27
Martin T27 Spindelfräs
Alt milli freze makinesi Martin T27
|
Dowel Cutter Martin — Dowel Cutting and Slotting Machine, Type T27
Overview
This machine is a Martin T27 dowel cutter designed for dowel cutting and slotting operations. The specification list below details the machine’s milling and sawing capabilities, adjustments, and shipping dimensions as provided.
Milling (Milling Shaft)
- Spindle speed of milling shaft: 3000 and 4500 rpm
- Height adjustment range of milling shaft: 145 mm
- Maximum diameter of milling tool: 390 mm
- Maximum clamping height: 135 mm
- Spindle diameter: 40 mm
- Milling motor: 5.5 / 7.5 kW
Cutting Saw
- Speed of cutting saw: 3000 rpm
- Height adjustability of cutting saw: 190 mm
- Maximum cutting height of cutting saw: 100 mm
- Maximum saw blade diameter: 350 mm
- Saw blade spindle diameter: 30 mm
- Motor power for cutting saw: 1.1 kW
- Lateral adjustability of cutting saw: 250 mm
Table and Travel
- Travel distance of sliding table: 1270 mm
Shipping Dimensions and Weights
- Machine on pallet: 670 kg; pallet size 1800 mm x 1050 mm x H 1600 mm
- Sliding table on pallet: 83 kg; pallet size 1200 mm x 800 mm x H 1300 mm
- Stop bar approx. 10 kg; package size 1860 mm x 160 mm x 160 mm
Notes
All specifications above are presented as provided. No additional accessories, condition statements, or operational guarantees are included beyond the listed specifications.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Dowel Cutter Martin
Dowel Cutting and Slotting Machine
Type T27
Spindle Speed of Milling Shaft 3000 + 4500 rpm
Height Adjustment Range of Milling Shaft 145 mm
Maximum Diameter of Milling Tool 390 mm
Maximum Clamping Height 135 mm
Spindle Diameter 40 mm
Milling Motor 5.5 / 7.5 kW
Speed of Cutting Saw 3000 rpm
Height Adjustability of Cutting Saw 190 mm
Maximum Cutting Height of Cutting Saw 100 mm
Maximum Saw Blade Diameter 350 mm
Lateral Adjustability of Cutting Saw 250 mm
Motor Power Cutting Saw 1.1 kW
Saw Blade Spindle Diameter 30 mm
Travel Distance of Sliding Table 1270 mm
Shipping Dimensions
Machine on Pallet 670 kg
1800 mm x 1050 mm x H 1600 mm
Sliding Table on Pallet 83 kg
1200 mm x 800 mm x H 1300 mm
Stop Bar approx. 10 kg
1860 mm x 160 mm x 160 mm
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
