| Manufacturer | LECTRA |
|---|---|
| Model | VECTOR iX2 |
| Year | 2023 |
| Location | Romania
|
Automatic Lectra Vector Fashion iX2 cutting system, purchased new at the end of 2023. The machine was commissioned on 1 January 2024 and decommissioned in March 2025, after 593 operating hours. According to the description provided, it is in excellent condition and is still installed. The stated configuration and technical specifications are subject to confirmation upon inspection.
Key technical specifications:
• Installed power: 15 kW; low-consumption vacuum system.
• Effective cutting-window width: 1.82 m (72 inches).
• Vacuum compression height: 2.5 cm.
• Cutting speed: minimum 80 m/min; acceleration: minimum 8 m/s².
• Minimum unloading conveyor length: 2.2 m.
• Table height: 75.7 cm; noise level: below 75 dB.
• Operating conditions: 10–43 °C and humidity below 95%, non-condensing.
• Operating system: Windows 10, 64-bit.
• Supported formats: Lectra, Gerber and Investronica proprietary formats, as well as DXF, AAMA, ISO 6983 and RS274D.
The listed features include patented Eclipse technology for cutting while the conveyor is moving, optimization for cutting tangent pieces, and a digitally controlled dynamic vacuum system. The system provides video-assisted marker positioning, a heated drill with digital temperature control, and a programmable sharpening system. It also includes blade-break detection, automatic marker-height adjustment, and cutting-path optimization.
Also listed are more than 120 built-in sensors, automated diagnostics, preventive-maintenance alerts, and an electronic maintenance log. The touchscreen interface displays information on vacuum, blade condition, and energy consumption. The description also includes an upward exhaust-air extraction system, an energy-saving function, and restart after a power interruption.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Lectra Vector iX2 automatic cutting system – 2023, only 593 hours, like new
Lectra Vector Fashion iX2 automatic cutter for sale, purchased new at the end of 2023. It was put into operation on 1 January 2024 and decommissioned in March 2025 after only 593 hours of use. The machine is in excellent condition and is still installed in our factory in , where it can be inspected and demonstrated on request (5 working days’ notice).
Original purchase value: .
Main specifications
Installed power: 15 kW, very low-consumption vacuum unit
Machine width: [103" / 118"]
Effective cutting window width: 1.82 m (72")
Compressed lay height (under vacuum): 2.5 cm
Cutting speed: min. 80 m/min
Acceleration: min. 8 m/s²
Unloading conveyor: min. 2.2 m
Table height: 75.7 cm
Steel blade: 1.45 x 5
Noise level: < 75 dB
Operating conditions: 10–43°C, humidity < 95% (non-condensing)
Operating system: Windows 10, 64-bit
Compatible formats: native Lectra, Gerber and Investronica, DXF, AAMA, ISO 6983, RS274D
Key features
Eclipse patented technology: cuts while the conveyor advances, for maximum throughput
Optimized cutting of tangent pieces
Dynamic, digitally controlled vacuum system
Video-assisted lay positioning
Heated drill with digital temperature control
Programmable sharpening system
Blade breakage detection, automatic lay height control and automatic cutting path optimization
Over 120 built-in sensors for reporting and diagnostics
Automated diagnostics, preventive maintenance warnings and an electronic maintenance log
Touchscreen interface with real-time monitoring of vacuum, blade status and power consumption
Long-lasting consumables
Upward-directed exhaust system, plus automatic energy saving and restart after power failure
Condition: Excellent, like new | Status: Decommissioned, still installed | CE: [Yes]
Features listed according to the original Lectra specification; final configuration to be confirmed upon inspection. Full technical specification and further photos available on request.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| cutting-automated-cutting-machines-lectra-vector-ix2-p261026084_1.pdf | Download |
| Client type | Factory – small or medium company |
| Active since | 2026 |
| Offers online | 1 |
| Last activity | Oct. 26, 2026 |
Lectra Vector iX2 automatic cutting system – 2023, only 593 hours, like new
Lectra Vector Fashion iX2 automatic cutter for sale, purchased new at the end of 2023. It was put into operation on 1 January 2024 and decommissioned in March 2025 after only 593 hours of use. The machine is in excellent condition and is still installed in our factory in , where it can be inspected and demonstrated on request (5 working days’ notice).
Original purchase value: .
Main specifications
Installed power: 15 kW, very low-consumption vacuum unit
Machine width: [103" / 118"]
Effective cutting window width: 1.82 m (72")
Compressed lay height (under vacuum): 2.5 cm
Cutting speed: min. 80 m/min
Acceleration: min. 8 m/s²
Unloading conveyor: min. 2.2 m
Table height: 75.7 cm
Steel blade: 1.45 x 5
Noise level: < 75 dB
Operating conditions: 10–43°C, humidity < 95% (non-condensing)
Operating system: Windows 10, 64-bit
Compatible formats: native Lectra, Gerber and Investronica, DXF, AAMA, ISO 6983, RS274D
Key features
Eclipse patented technology: cuts while the conveyor advances, for maximum throughput
Optimized cutting of tangent pieces
Dynamic, digitally controlled vacuum system
Video-assisted lay positioning
Heated drill with digital temperature control
Programmable sharpening system
Blade breakage detection, automatic lay height control and automatic cutting path optimization
Over 120 built-in sensors for reporting and diagnostics
Automated diagnostics, preventive maintenance warnings and an electronic maintenance log
Touchscreen interface with real-time monitoring of vacuum, blade status and power consumption
Long-lasting consumables
Upward-directed exhaust system, plus automatic energy saving and restart after power failure
Condition: Excellent, like new | Status: Decommissioned, still installed | CE: [Yes]
Features listed according to the original Lectra specification; final configuration to be confirmed upon inspection. Full technical specification and further photos available on request.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
Automatic Lectra Vector Fashion iX2 cutting system, purchased new at the end of 2023. The machine was commissioned on 1 January 2024 and decommissioned in March 2025, after 593 operating hours. According to the description provided, it is in excellent condition and is still installed. The stated configuration and technical specifications are subject to confirmation upon inspection.
Key technical specifications:
• Installed power: 15 kW; low-consumption vacuum system.
• Effective cutting-window width: 1.82 m (72 inches).
• Vacuum compression height: 2.5 cm.
• Cutting speed: minimum 80 m/min; acceleration: minimum 8 m/s².
• Minimum unloading conveyor length: 2.2 m.
• Table height: 75.7 cm; noise level: below 75 dB.
• Operating conditions: 10–43 °C and humidity below 95%, non-condensing.
• Operating system: Windows 10, 64-bit.
• Supported formats: Lectra, Gerber and Investronica proprietary formats, as well as DXF, AAMA, ISO 6983 and RS274D.
The listed features include patented Eclipse technology for cutting while the conveyor is moving, optimization for cutting tangent pieces, and a digitally controlled dynamic vacuum system. The system provides video-assisted marker positioning, a heated drill with digital temperature control, and a programmable sharpening system. It also includes blade-break detection, automatic marker-height adjustment, and cutting-path optimization.
Also listed are more than 120 built-in sensors, automated diagnostics, preventive-maintenance alerts, and an electronic maintenance log. The touchscreen interface displays information on vacuum, blade condition, and energy consumption. The description also includes an upward exhaust-air extraction system, an energy-saving function, and restart after a power interruption.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
