Type of machine: Press Line Company: Weingarten / Raskin Model: 1x ZS1200.34 & 4x 6031AE4 & 1x VK800.39.60 Year of manufacture: Not specified Last refurbishment: 2010 / 2020 Type of control: PLC Control name: Siemens S5 / S7 Freight basis: EXW Technical condition: As-is, where-is
Emanuel DEA 400/2500 Hydraulic Press Manufacturer: Emanuel Model: DEA 400/2500 Technical Condition: Excellent State: Visible Maximum Hammer Force at Pressing: Ton 400 Maximum Closing Force: Ton 160 Platen Dimensions: 2500 x 1800 mm Distance Between Front Platens: 2500 mm Maximum Distance Between Platens: 1200 mm Maximum Ram Stroke: 1000 mm Press Stroke: 450 mm Installed Power: Approximately 120 kW Weight: Approximately Ton 77 Additional Information: The press is CE marked and can be seen in operation at our Monza plant.
33 TON ABESEIKI HYDRAULIC DIE SPOTTING PRESS NEW 1988, MODEL CDS-2015-30S EQUIPPED WITH: PUSH BUTTON CONTROLS T-SLOTTED BED & RAM LOWER PLATEN SLIDING BED UPPER TILTING PLATEN FLOOR STANDING DESIGN NOTE: MACHINE APPEARS TO BE IN VERY GOOD CONDITION. Specifications Model CDS-2015-30S Year 1988 Condition Used Serial Number 8400606.0 Stock Number 26009 Tonnage capacity 33 TON Pull out capacity 14.33 TON Stroke length, maximum 70.87" Daylight opening 70.87" Bed area, l-r x f-b 78.74" X 59.05" Windows, approximately 30" WIDE Height 18'6" Horsepower 20 HP Electrical requirements 460/3/60
75 TON CINCINNATI-INC CNC GAP-FRAME HYDRAULIC PRESS New 2000, Model 75 OBS, EQUIPPED WITH: Cincinnati Pendant Mounted Microprocessor Control Quick Die Change System (Power Clamping For Tool Sets) 24" x 18" x 2-1/2" T-Slotted Bolster Plate Mounted On Slide 36" x 24" x 3.5" T-Slotted Bolster Plate Mounted On Bed CATALOG SPECIFICATIONS: Tonnage Capacity, Low Speed 75 TON Tonnage Capacity, Medium Speed 42 TON Stroke Length, Adjustable .75" to 8" Gap Length 14" Open Height, Maximum 14.25" Closed Height, Minimum 6.25" Slide Area, L-R x F-B 24" x 18" Slide Bolster Area, L-R x F-B 24" x 18" Bed Bolster Area, L-R x F-B 36" x 24" Distance Between Housings 25" Slide Speed, Pressing (High) 606 IPM Slide Speed, Pressing (Medium) 175 IPM Slide Speed, Pressing (Low) 61 IPM Slide Speed, Return (High) 695 IPM Slide Speed, Return (Low) 450 IPM Hydraulic Motor, Horsepower 20 HP
Offer title: NURİŞ MACHINE INDUSTRY NURİŞ 100 TON LAMINATION PRESS Manufacturer: NURİŞ MAKİNA SANAYİ Model: NURİŞ Year of manufacture: 1995 Year of manufacture approximate: Not specified Technical condition: as-is, where-is State: visible but unplugged
