| Manufacturer | Haagen & Rinau |
|---|---|
| Model | Unimix SRM 200 |
| Year | 1993 |
| Location | France
|
This Haagen & Rinau Unimix SRM 200 is a vacuum mixer designed for industrial applications, manufactured in 1993. It features a stainless steel mixing tank with a volume capacity of 406 liters. The mixer operates at a maximum temperature of 143°C and can work under a pressure range from -1 to 3 bars. The vessel is double jacketed, with a jacket capacity of 34 liters, allowing heating up to 151°C and a maximum jacket pressure of 4 bars.
The mixing system includes slow mixing via a central stirring mechanism combined with scrapers and fixed counter action, powered by a 7.5 kW motor. Fast mixing is achieved by an emulsifier located at the bottom of the tank, which facilitates suction and recirculation of the product, with a power range of 8 to 12 kW.
The unit is equipped with an integrated electrical cabinet controlled by a Siemens S5 controller. The hydraulic unit controls the vertical movement and rotation of the cover with its mixing tool, tilting of the tank, and vertical movement of the homogenizer located at the bottom of the tank. Notably, this model does not include a homogenizer.
From the images, the mixer is fitted with an electric motor mounted underneath the tank that drives the mixing mechanism. There is a pressure gauge positioned on top of the mixing tank, along with multiple valves and piping connections for process integration. The control panel bears the 'Unimix Haagen & Rinau' brand logo. The stainless steel construction and visible components suggest a robust design suitable for demanding mixing tasks. The current status mentions renovation in progress in the workshops, but no explicit operational condition is provided.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
// currently being renovated in our workshops //
Manufacturer : Haagen & Rinau
Model : Unimix SRM 200
Year : 1993
Type: vacuum mixer
Material : stainless steel
Vessel capacity: 406 L
Maximum temperature: 143°C
Pressure: – 1 / 3 bars
Double jacket capacity: 34 L
Maximum temperature: 151°C
Pressure: 4 bars
Slow mixing : Central stirring + scrapers. Fixed counter action
Power: 7,5 KW
Fast mixing: emulsifier at the bottom of the tank. Suction and recirculation of the product.
Power : 8 / 12 KW
Integrated electrical cabinet.
Siemens S5 controller
Hydraulic unit:
– Up and down of the cover with its mixing tool
– Rotation of the cover with its mixing tool
– Tilting of the tank
– Up and down of the homogeniser at the bottom of the tank.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
What retrofitting is being done on this Haagen & Rinau Unimix SRM 200?
This Haagen & Rinau Unimix SRM 200 liquid mixer is currently in the process of being retrofitted.
What is the condition of the machine?
This equipment is in pretty good condition.
What documentation is available for this equipment?
The seller has only the electrical documentation available.
What needs to be reassembled on this Haagen & Rinau Unimix SRM 200?
This Haagen & Rinau Unimix SRM 200 liquid mixer requires reassembly of the bottom homogeniser.
Are any parts being reconditioned for this mixer?
Parts for the mixer are currently being reconditioned.
The following questions and answers are generated using artificial intelligence based on the product information available. They are provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
