Price on request
View price| ------------------- | |
| worked hours | |
| hours under power | |
| state | excellent |
| At local norms | --------- |
| status | |
| Last availability date | 03/05/2026 |
This Solar Panel Production Line, manufactured in Germany in 2021, is designed for efficient and automated photovoltaic module assembly. The production line measures 48,600 mm in length and 11,500 mm in width, providing a substantial footprint for high-volume manufacturing.
The line requires a compressed air supply with a minimum steady pressure of 8 bar, dry and oil-free, supported by a 200-liter reservoir. Production temperature is maintained between 22°C and 24°C to ensure optimal processing conditions. The electrical power supply specifications include voltages of 230VAC and 400VAC, 50 Hz frequency, and a three-phase connection (L1/L2/L3/N/PE) with a maximum voltage deviation of 10V and a total power requirement of 250 KVA. Additionally, nitrogen gas is needed at a flow rate of 15 liters per minute and a minimum pressure of 275 kPa.
The production line incorporates several key pieces of equipment:
- A stringer capable of processing 600 cells per hour, featuring automated cell loading and ribbon placement, as well as automated layup into boxes.
- A manual foil cutter station equipped with two rolls for EVA and backsheet materials.
- A fully automated layup station with a 90 MW capacity, which centers and places strings automatically.
- Manual stations for foil placement and bus soldering, including two soldering stations.
- A refurbished laminator capable of processing two panels per cycle, designed for 72-cell panels.
- A manual tape applicator for placing tape on the laminate.
- A trim station with a lifter and 360° turntable.
- Semi-automated frame and junction box (J-Box) stations.
- A final optical inspection station equipped with a camera and screen to detect defects.
- An LED flasher capable of over two million flashes without lamp replacement, suitable for panels measuring 2 x 1 meter.
- A high potential (Hi-Pot) tester compliant with TÜV standard procedures.
The machinery is housed within a large enclosed metal casing featuring glass windows that allow viewing of internal components. A control panel with emergency stop button, multiple switches, and ventilation grills is located on the right side of the machine. The equipment appears clean and well-maintained, situated in a spacious industrial environment with visible piping and ductwork overhead.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Solar Panel Production Line
Compressed Air:
Pressure: minimum 8 bar steady
Quality: dryed, oilfree
Reservoir in L : 200
Productiontemperature:
22C° - 24C°
Powersupply:
Voltage: 230VAC, 400VAC
Frequence: 50HZ
Phases: L1/L2/L3/N/PE
Range: max. 10V DEVIATION
Total KVA: 250
Nitrogen:
lpm: 15
kpa: min. 275
The Line Mainly Comprise Following Equipment:
600 cells / h stringer refurbished
Automated cell loading and ribbon placement
Automated layup in boxes
Manual Foil Cutter
Manual cutting of the foil
With two rolls for EVA and backsheet
Fully automated Layup 90 MW
Automated centering of the strings
Automated placement of the strings
Foil Piacing Station
Manual station to place lamination foil
Inline station
Manual Busing Station
With two soldering stations
Laminator Refurbished - 2 Panels / Cycle
For up to 2 panels per cycle (72 celt design)
Tape Aplicator
Placing tape on the faminate
Manual tool
Trim Station - Lifter
Lifting up the laminate
360° turn table
Frame Station Semi
J-Box Station
Final Optical Inspectiog
Check for optical defects
With camera and screen
LED Flasher
More than 2 million flashes without changing the LED lamps
For panels with 2x x 1m
Hi-Pot Test
High potential test
According TÜV standard procedure
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
What is the capacity of this Germany Solar Panel Production Line?
This Germany Solar Panel Production Line has a capacity of up to 25 MW.
Is this production line semi-manual or fully automated?
This production line is semi-manual/automated with a magazine box for strings.
What type of handling system does this equipment use?
This equipment features a vacuum gripper system for handling strings.
What features are included in this Germany Solar Panel Production Line?
This Germany Solar Panel Production Line includes a string tester and an automated camera for visualization.
What are the electrical requirements for this production line?
This production line operates on 220 Volt, 50 Hertz, and 16 Ampere electrical supply.
What is the minimum pneumatic supply required for this equipment?
This equipment requires a pneumatic supply of a minimum of 6 bar.
What type of loading and unloading system does this production line have?
This production line includes a manual loading and unloading system for glass and laminates.
When was this Germany Solar Panel Production Line manufactured?
This Germany Solar Panel Production Line was manufactured in 2021.
The following questions and answers are generated using artificial intelligence based on the product information available. They are provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
| Client type | Factory – small or medium company |
| Active since | 2023 |
| Offers online | 1 |
| Last activity | May 3, 2026 |
