| Manufacturer | FPT |
|---|---|
| Model | DINO |
| Year | |
| Location | Italy
|
Overview:
This listing is for an FPT DINO work center, classified as a 5-axis (or more) machining center. The machine’s stated work capacity is 2800 x 2200 x 800 mm (110.24 x 86.61 x 31.50 in), suitable for large part machining and complex multi-axis work.
Key specifications:
- Category / Type: Work Center, 5-axis or more
- CNC control: Heidenhain 430
- Work travels: Longitudinal (X) 2800 mm; Transversal (Y) 2200 mm; Vertical (Z) 800 mm
- Distance between columns: 1672 mm
Heads and spindles:
- Head 1: Type TULCE; spindle taper HSK63A; rotary axes A and C specified as 360.000 x 0.001°; maximum spindle speed 18,000 rpm; maximum power 20 kW; coolant: CTS 20 Bar
- Head 2: Type TVS; spindle taper HSK63A; maximum spindle speed 10,000 rpm; maximum power 44 kW; coolant: CTS 20 Bar
Feeds, table and tooling:
- Rapid feed rates (X, Y, Z): 35 m/min each
- Table dimensions: 3000 x 1200 mm (118.11 x 47.24 in)
- Table load capacity: 8000 kg
- Automatic tool changer (ATC): 40 positions
Additional data:
- Motor power listed as 63.2 HP
- Total machine weight listed as 41,300 kg
- High pressure coolant: 20 Bar
- CE certification: Yes
Important notice:
The technical details above are taken from the provided product data. Equipment condition, functional status, and any additional accessories are not represented here and should be confirmed with the seller. The information may be incomplete or inaccurate; prospective buyers are advised to inspect the machine and verify all specifications prior to purchase.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Category
Work Center
Type
5-axis or more
Brand
FPT
Model
DINO
Capacity
2800x2200x800 mm110.24x86.61x31.50 in
Technical Specifications
Convert toMetricImperial
WORK AREA
Longitudinal (X)
2800 mm110.24 in
Vertical (Z)
800 mm31.50 in
Transversal (Y)
2200 mm86.61 in
Distance between columns
1672 mm65.83 in
CNC
CNC
Heidenhain 430
HEAD 1
Type
TULCE
Spindle taper
HSK63A
Axis A
360.000x0.001 °
Axis C
360.000x0.001 °
Max speed
18000 Rpm
Max power
20 Kw
Coolant
CTS 20Bar
FEEDS
Rapid X
35 m/min1,377.95 ipm
Rapid Y
35 m/min1,377.95 ipm
Rapid Z
35 m/min1,377.95 ipm
TABLE
Dimension (LxWxH)
3000x1200 mm118.11x47.24 in
Load capacity
8000 Kg
ATC
Positions
40
HEAD 2
Type
TVS
Spindle taper
HSK63A
Max speed
10000 Rpm
Max power
44 Kw
Coolant
CTS 20Bar
EXTRA
Motor power
63.2 HP
Total machine weight
41300 Kg
High pressure
20Bar
CE certification
Yes
The data provided are based on information available to us, where possible obtained from manufacturers; therefore, despite good faith, due to the nature and complexity of the equipment, this information may be incomplete and/or inaccurate, and their correctness cannot be guaranteed and does not constitute any contractual obligation. We recommend always inspecting the equipment and requesting confirmation of the data.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Machinery dealer |
| Active since | 2007 |
| Offers online | 181 |
| Last activity | Oct. 29, 2026 |
