Contact us to receive an offer.
| Manufacturer | FAT |
|---|---|
| Model | 270 SA |
| Year | |
| Location | Spain
|
The FAT 270 SA is a robust metal band saw designed for precise cutting of various metal profiles. It features a cutting arm painted in red, mounted on a sturdy gray base. The machine offers versatile cutting angles of 90°, 45°, and 60°, enabling it to handle a range of cutting tasks efficiently.
This band saw accommodates different cutting capacities depending on the angle: it can cut round materials up to 215 mm at 90°, 155 mm at 45°, and 90 mm at 60°. For square profiles, the maximum cutting sizes correspond to the same dimensions. Rectangular materials can be cut up to 250×150 mm at 90°, 145×165 mm at 45°, and 90×90 mm at 60°.
The saw uses a metal band blade measuring 2450 mm in length and 27 mm in width. It operates with a cutting speed of up to 70 m/min and offers variable belt speeds of 35 and 70 m/min, allowing for adaptability based on material and cutting requirements. The machine is powered by an engine with a power rating of 0.7 kW.
Additional technical features include a cutting accuracy of 0.1 mm every 100 mm, cutting down speed options from 0 to 200 mm/min, and a fast lowering speed of 3500 mm/min. The working table height is 800 mm, which supports comfortable operation.
The FAT 270 SA is equipped with a control panel featuring two knobs and a pressure gauge, facilitating precise adjustments during operation. It also includes a clamping mechanism to securely hold materials during cutting. The machine weighs approximately 380 kg and measures 1550 mm in length, 1850 mm in width, and 1800 mm in height.
The condition of the machine shows signs of use, with visible wear and dust on its surfaces. It is currently placed on a wooden pallet, which aids in mobility and storage. This band saw is suitable for industrial metal cutting applications requiring versatility and precision.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Make: FAT
Model: 270 SA
Cutting angle:
90° / 45° / 60°
Cutting capacity:
Round: 215 mm / 155 mm / 90 mm
Square: 215 mm / 155 mm / 90 mm
Rectangular: 250×150 mm / 145×165 mm / 90×90 mm
Tape dimensions (L x W x H): 2450 x 27 x 0,9 mm
Working table height: 800 mm
Power of the belt rotation motor: 0.55 / 0.7 kW
Power of the cooling electric pump: 0,1 kW
Power of the hydraulic pump: 0,37 kW
Belt speed: 35 / 70 m/min
Cutting down speed: 0 / 200 mm/min
Cutting accuracy: 0,1 mm every 100 mm
Fast lowering speed: 3500 mm/min
Dimensions (L x W x H): 1550 x 1850 x 1800 mm
Weight: 380 kg
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
