| Manufacturer | Bilion |
|---|---|
| Model | 50T SELECT H 80 TP DIXIT 3 |
| Year | 2011 |
| Location | France
|
Overview
This is an injection module with detailed technical parameters listed in the original description. Below is a systematic summary of the available data for the main features of the injection and clamping units, as well as general parameters and additional equipment. Some fields in the description do not contain values and are marked as unspecified.
Injection Module
- Screw diameter: 25 mm
- Calculated injection volume (shot): 39 cm³
- L/D ratio: 20 L/D
- Maximum injection flow rate: 98 cm³/s
- Material pressure: 2040 bar
- Plastification capacity for PS: unspecified
- Screw speed: unspecified (rpm)
- Hydraulic motor torque: unspecified (Nm)
- Hydraulic motor power: unspecified (HP)
- Number of temperature zones: unspecified
Clamping Mechanism
- Clamping force: 500 kN
- Opening stroke: 250 mm
- Minimum mold thickness: 150 mm
- Maximum distance between plates: 650 mm
- Distance between columns: 350 x 300 mm
- Plate dimensions: 440 x 490 mm
General Features and Equipment
- Heater system power: unspecified (kW)
- Total installed power: 29 kW
- Oil quantity: unspecified (L)
- Dimensions: unspecified (m)
- Weight: unspecified (Kg)
- Equipment: 4 hydraulic cores
- Quality control cover
- Commissioning year: 2011
- Operating hours: unspecified (h)
- Tonnage: 50
Notes
- The description contains several unfilled fields (e.g., screw speed, plastification capacity, oil quantity, dimensions, and weight). If these data are critical for your decision, it is advisable to request additional information from the seller.
- No data regarding service history, tests, condition at sale, or warranty are provided; such claims are not included in the available description.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
