Contact us to receive an offer.
| Manufacturer | BIGLIA |
|---|---|
| Model | B-501M |
| Year | 1996 |
| Location | Germany
|
The BIGLIA B-501M CNC lathe, manufactured in 1996, is designed for precision turning tasks with versatile machining capabilities. It features a maximum turning length of 500 mm and can handle diameters over the bed up to 520 mm. The machine accommodates bar stock diameters up to 68 mm and allows machining passes up to 250 mm. It is equipped with an 80 mm spindle bore and a spindle motor rated at 22 kW, providing spindle speeds up to 4000 rpm. The lathe offers an X-axis travel of 2105 mm and a Z-axis travel of 500 mm. A 12-position turret supports a variety of tool sizes with rapid indexing, enhancing operational efficiency. Motorized tools include six positions with rotation speeds from 50 to 3000 rpm powered by a 3.7 kW motor. The CNC control system is based on the GE Fanuc 0-T, enabling precise axis control with a minimum programmable increment of 0.001 degrees on the C-axis and rapid speeds up to 80 rpm. The tailstock has an automatic barrel travel of 100 mm and a CM4 taper. Overall dimensions measure 4000 mm in length, 1900 mm in width, and 1800 mm in height, with a total weight of 4700 kg, inclusive of a chip conveyor. The machine is fitted with an Autoblok 210 BB chuck featuring hardened jaws and a Filtermist FI4/8 smoke extractor to improve working conditions. Visual inspection confirms the presence of a tool turret loaded with multiple tool holders and drill bits, as well as coolant nozzles positioned near the tool holders. The base of the machine shows visible wear and some rust stains, consistent with typical use over time. This BIGLIA B-501M CNC lathe is suitable for workshops seeking a robust and versatile turning center equipped with comprehensive tooling and control features.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
CNC lathe BIGLIA B501 M, manufactured in 1996, designed for precision turning operations. The machine offers a maximum turning length of 500 mm and a maximum diameter over the bed of 520 mm, accommodating workpieces up to 68 mm in diameter from bar stock and up to 250 mm per pass. The lathe is equipped with an 80 mm spindle bore and a spindle motor delivering 22 kW of power, allowing rotational speeds of up to 4000 rpm. The X-axis travel is 2105 mm, while the Z-axis travel is 500 mm, providing versatile machining capabilities. A 12-position turret supports various tool sizes with rapid indexing times, enhancing productivity. The machine includes motorized tools with six positions and a rotation range of 50 to 3000 rpm powered by a 3.7 kW motor. The CNC control is based on the GE Fanuc 0-T system, offering precise axis control with a minimum programmable increment of 0.001 degrees on the C-axis and rapid speeds of up to 80 rpm. The tailstock features an automatic barrel travel of 100 mm and a CM4 taper. Overall dimensions of the lathe are 4000 mm in length, 1900 mm in width, and 1800 mm in height, with a weight of 4700 kg, including a chip conveyor. The machine is equipped with an Autoblok 210 BB chuck with hardened jaws and a Filtermist FI4/8 smoke extractor to improve working conditions. Visual inspection shows the lathe has an enclosure with a sliding door on the left side and a control panel mounted on the right side with buttons and a screen. The chuck and tool holder are visible inside the lathe bed.
The exterior shows signs of wear and paint chipping, and the interior metal surfaces exhibit some wear and dents, which is typical for used machinery of this age. This CNC lathe BIGLIA B501 M is suitable for workshops requiring a robust and versatile turning center with complete tooling and control features.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Factory – small or medium company |
| Active since | 2026 |
| Offers online | 1 |
| Last activity | March 25, 2026 |
CNC lathe BIGLIA B501 M, manufactured in 1996, designed for precision turning operations. The machine offers a maximum turning length of 500 mm and a maximum diameter over the bed of 520 mm, accommodating workpieces up to 68 mm in diameter from bar stock and up to 250 mm per pass. The lathe is equipped with an 80 mm spindle bore and a spindle motor delivering 22 kW of power, allowing rotational speeds of up to 4000 rpm. The X-axis travel is 2105 mm, while the Z-axis travel is 500 mm, providing versatile machining capabilities. A 12-position turret supports various tool sizes with rapid indexing times, enhancing productivity. The machine includes motorized tools with six positions and a rotation range of 50 to 3000 rpm powered by a 3.7 kW motor. The CNC control is based on the GE Fanuc 0-T system, offering precise axis control with a minimum programmable increment of 0.001 degrees on the C-axis and rapid speeds of up to 80 rpm. The tailstock features an automatic barrel travel of 100 mm and a CM4 taper. Overall dimensions of the lathe are 4000 mm in length, 1900 mm in width, and 1800 mm in height, with a weight of 4700 kg, including a chip conveyor. The machine is equipped with an Autoblok 210 BB chuck with hardened jaws and a Filtermist FI4/8 smoke extractor to improve working conditions. Visual inspection shows the lathe has an enclosure with a sliding door on the left side and a control panel mounted on the right side with buttons and a screen. The chuck and tool holder are visible inside the lathe bed.
The exterior shows signs of wear and paint chipping, and the interior metal surfaces exhibit some wear and dents, which is typical for used machinery of this age. This CNC lathe BIGLIA B501 M is suitable for workshops requiring a robust and versatile turning center with complete tooling and control features.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
The BIGLIA B-501M CNC lathe, manufactured in 1996, is designed for precision turning tasks with versatile machining capabilities. It features a maximum turning length of 500 mm and can handle diameters over the bed up to 520 mm. The machine accommodates bar stock diameters up to 68 mm and allows machining passes up to 250 mm. It is equipped with an 80 mm spindle bore and a spindle motor rated at 22 kW, providing spindle speeds up to 4000 rpm. The lathe offers an X-axis travel of 2105 mm and a Z-axis travel of 500 mm. A 12-position turret supports a variety of tool sizes with rapid indexing, enhancing operational efficiency. Motorized tools include six positions with rotation speeds from 50 to 3000 rpm powered by a 3.7 kW motor. The CNC control system is based on the GE Fanuc 0-T, enabling precise axis control with a minimum programmable increment of 0.001 degrees on the C-axis and rapid speeds up to 80 rpm. The tailstock has an automatic barrel travel of 100 mm and a CM4 taper. Overall dimensions measure 4000 mm in length, 1900 mm in width, and 1800 mm in height, with a total weight of 4700 kg, inclusive of a chip conveyor. The machine is fitted with an Autoblok 210 BB chuck featuring hardened jaws and a Filtermist FI4/8 smoke extractor to improve working conditions. Visual inspection confirms the presence of a tool turret loaded with multiple tool holders and drill bits, as well as coolant nozzles positioned near the tool holders. The base of the machine shows visible wear and some rust stains, consistent with typical use over time. This BIGLIA B-501M CNC lathe is suitable for workshops seeking a robust and versatile turning center equipped with comprehensive tooling and control features.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
| Client type | Factory – small or medium company |
| Active since | 2026 |
| Offers online | 1 |
| Last activity | March 25, 2026 |
