| Manufacturer | ARBURG |
|---|---|
| Model | Allrounder 2000 T 2000-800 |
| Year | 2019 |
| Location | Germany
|
Detailed technical description
This injection moulding machine is specified with separate technical data for the clamping and injection sides, together with overall dimensions, weight and on-board interfaces. The information below follows the provided machine specifications.
Clamping side
- Clamping force: 2000 kN
- Plate dimensions (height x width): 1772 x 800 mm
- Minimum installation height: 400 mm
- Maximum plate spacing: 900 mm
- Opening stroke: 500 mm
- Rotary table diameter: 2000 mm
- Ejector stroke: 175 mm
- Ejector force: 45 kN
- Mould (tool) weight capacity: 6,000 kg
Injection side
- Screw diameter: 50 mm
- Displacement (shot volume): 392 ccm
- Injection pressure: 2,000 bar
- Screw length: 20 l/d
- Screw stroke: 200 mm
- Screw speed: 60 min
- Screw torque: 880 N
- Number of heating zones: 8
- Nozzle stroke: 400 mm
Dimensions & weight
- Machine dimensions (L x W x H): 4.11 m x 2.65 m x 4.81 m
- Total weight: 22,000 kg
Equipment and interfaces
- On-screen text: German and English
- 16A CEE socket
- Hydraulic core pullers (4x)
- Air valve (1x)
- Machine fitted with rotary table
- Machine fitted with water tank
- Machine without material hopper
- Levelling elements
- EUROMAP 67 handling interface
- EUROMAP 73 interface
- OPC interface
Notes
All specifications above are taken from the provided product details. No additional condition statements (for example, regarding operational status, testing, refurbishment or warranty) are included.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Technical data – clamping side
Clamping force: 2000 kN
Plate dimensions (h x w): 1772 x 800 mm
Minimum installation height: 400 mm
Maximum plate spacing: 900 mm
Opening stroke: 500 mm
Rotary table diameter: 2000 mm
Ejector stroke: 175 mm
Ejector force: 45 kN
Mould weight: 6,000 kg
Technical data – injection side
Screw diameter: 50 mm
Displacement: 392 ccm
Injection pressure: 2,000 bar
Screw length: 20 l/d
Screw stroke: 200 mm
Screw speed: 60 min
Screw torque: 880 N
Number of heating zones: 8
Nozzle stroke: 400 mm
Dimensions & Weight
Machine dimensions LxWxH: 4.11 m x 2.65 m x 4.81 m
Total weight: 22,000 kg
Equipment
On-screen text in German
On-screen text in English
16A CEE socket
Hydraulic core puller (4x)
Air valve (1x)
Machine with rotary table
Machine with water tank
Machine without material hopper
Levelling elements
EUROMAP 67 handling interface
EUROMAP 73 interface
OPC interface
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Machinery dealer |
| Active since | 2007 |
| Offers online | 24 |
| Last activity | Oct. 28, 2026 |
Technical data – clamping side
Clamping force: 2000 kN
Plate dimensions (h x w): 1772 x 800 mm
Minimum installation height: 400 mm
Maximum plate spacing: 900 mm
Opening stroke: 500 mm
Rotary table diameter: 2000 mm
Ejector stroke: 175 mm
Ejector force: 45 kN
Mould weight: 6,000 kg
Technical data – injection side
Screw diameter: 50 mm
Displacement: 392 ccm
Injection pressure: 2,000 bar
Screw length: 20 l/d
Screw stroke: 200 mm
Screw speed: 60 min
Screw torque: 880 N
Number of heating zones: 8
Nozzle stroke: 400 mm
Dimensions & Weight
Machine dimensions LxWxH: 4.11 m x 2.65 m x 4.81 m
Total weight: 22,000 kg
Equipment
On-screen text in German
On-screen text in English
16A CEE socket
Hydraulic core puller (4x)
Air valve (1x)
Machine with rotary table
Machine with water tank
Machine without material hopper
Levelling elements
EUROMAP 67 handling interface
EUROMAP 73 interface
OPC interface
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
Detailed technical description
This injection moulding machine is specified with separate technical data for the clamping and injection sides, together with overall dimensions, weight and on-board interfaces. The information below follows the provided machine specifications.
Clamping side
- Clamping force: 2000 kN
- Plate dimensions (height x width): 1772 x 800 mm
- Minimum installation height: 400 mm
- Maximum plate spacing: 900 mm
- Opening stroke: 500 mm
- Rotary table diameter: 2000 mm
- Ejector stroke: 175 mm
- Ejector force: 45 kN
- Mould (tool) weight capacity: 6,000 kg
Injection side
- Screw diameter: 50 mm
- Displacement (shot volume): 392 ccm
- Injection pressure: 2,000 bar
- Screw length: 20 l/d
- Screw stroke: 200 mm
- Screw speed: 60 min
- Screw torque: 880 N
- Number of heating zones: 8
- Nozzle stroke: 400 mm
Dimensions & weight
- Machine dimensions (L x W x H): 4.11 m x 2.65 m x 4.81 m
- Total weight: 22,000 kg
Equipment and interfaces
- On-screen text: German and English
- 16A CEE socket
- Hydraulic core pullers (4x)
- Air valve (1x)
- Machine fitted with rotary table
- Machine fitted with water tank
- Machine without material hopper
- Levelling elements
- EUROMAP 67 handling interface
- EUROMAP 73 interface
- OPC interface
Notes
All specifications above are taken from the provided product details. No additional condition statements (for example, regarding operational status, testing, refurbishment or warranty) are included.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
