Price on request
View price| Power in tons | 30 T |
| Metal length | 2500 mm |
| CNC type | AMNC |
| Metal width | 1250 mm |
| Max steel thickness | 4.5 mm |
| Number of tools | 58 |
| ------------------- | |
| worked hours | |
| hours under power | 116000 hours |
| state | excellent |
| At local norms | yes |
| status | visible |
| Last availability date | 28/05/2026 |
This listing features an Amada EMK 3510 NT CNC punching and nibbling machine, manufactured in 2008. The machine offers a punching force of 300 kN and accommodates sheet metal sizes up to 2500 x 1250 mm with a maximum steel thickness of 4.5 mm. It is equipped with a 58-station turret, including 4 AutoIndex stations, and operates with a servo-electric Twin Drive punching system. The working area measures 2500 x 1270 mm, extendable to 5000 x 1270 mm with repositioning, and the feed rates reach up to 100 m/min in the X direction and 80 m/min in the Y direction, with simultaneous movements up to 128 m/min.
The machine frame is a bridge frame design, with AC-Servo motors driving the turret and table. Pneumatic clamps secure the sheets during operation. Electrical requirements are 400V/50Hz, with power consumption ranging from 1 kW to 7 kW. Air consumption for the machine is approximately 250 l/min, with an additional 250 l/min for the air jet vacuum system.
Included with the machine is the Loader L III 250 automatic loading unit, capable of handling sheet sizes from 700 x 300 mm up to 2500 x 1250 mm and material thicknesses between 0.5 and 8.0 mm. The loader supports a maximum loading weight of 250 kg and stack height of 300 mm, with pallets able to hold up to 3000 kg. It features three magnets per pallet, 28 suction cups, and double sheet control with a thickness detector.
The unloading unit, Parts Remover PR III UL 250, accommodates parts sized from 200 x 200 mm up to 1000 x 1000 mm, with a maximum part weight of 25 kg. It includes a storage table measuring 3400 x 1200 mm and can handle stack heights up to 400 mm with maximum weights of 2000 kg on the skeleton table and 4000 kg on the storage table. The feed rates for unloading are up to 120 m/min in the X direction and 80 m/min in the Y direction.
The machine is equipped with a control panel featuring a touchscreen and multiple buttons and switches. The overall condition appears clean and well-maintained, with no visible damage. Safety features include protective fencing surrounding the machine and pneumatic clamps for securing sheets. The loading and unloading areas are equipped with pallets for efficient material handling. This comprehensive setup is suitable for high-precision punching and nibbling operations in an industrial environment.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Amada EMK 3510 NT with L III + PR III UL
Year: 2008
Machine hours: 116.000 h
Amada EMK 3510 NT
Control: AMNC-F
Punching force: 300kN
Working area X/Y: 2500 x 1270 mm (With repositioning: 5000 x 1270 mm)
Max. sheet thickness: 4,5 mm (mild steel)
Max. table loading weight: 150 kg
Feed rate X/Y: 100 / 80 m/min (128 m/min simultaneous)
Positioning tolerance: +/- 0,1 mm
Number of stations in turret: 58
AutoIndex stations: 4 (2 x B, 2 x E)
Feed rate turret: 30 1/min
Max. number of hits: 1000/min
Machine frame: Bridge frame
Punching drive: servo-electric Twin Drive
Drives turret + table: AC-Servo motors
Clamps: pneumatical
Electrical connection: 400V / 50Hz
Electrical consumption: 1kW – 7kW
Air consumption machine: 250 l/min
Air consumption Air Jet Vakuum: 250 l/min
Machine weight: 22 to
Loading unit Loader L III 250:
Sheet size min.: 700 x 300 mm
Sheet size max.: 2500 x 1250 mm
Material thickness: 0,5 – 8,0 mm
Max. loading weight: 250 kg
Max. stack height: 300 mm
Max. pallet weight: 3000 kg
Number of magnets per pallet: 3
Number of suction cups: 28 pieces
Double sheet control: yes, with sheet thickness detector
Air consumption: 650 l/min, 6 bar inlet pressure
Electrical connection: 400V
Unloading unit Parts Remover PR III UL 250:
Part size min. / max.: 200 x 200 mm / 1000 x 1000 mm
Sheet thickness: 0,5 – 3,0 mm (4mm for EM-Serie)
Max. part weight: 25 kg
Storage table size: 3400 x 1200 mm
Min. part size for unloading clamps: 1400 x 300 mm
Max. part size for unloading clamps: 2500 x 1250 mm
Max. stack height skeleton table: 400 mm
Max. weight skeleton table: 2000 kg
Max. stack height storage table: 400 mm
Max. weight storage table: 4000 kg
Max. feed rate X- / Y-direction: 120 / 80 m/min
Air consumption: 400 l/min, 6 bar inlet pressure
Electrical connection: 400V
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
| Client type | Machinery dealer |
| Active since | 2019 |
| Offers online | 36 |
| Last activity | June 5, 2026 |
TBM Maschinenhandel GmbH is a leading player in the machinery trading sector based in Germany. With a strong commitment to quality and customer satisfaction, TBM specializes in the sale and distribution of high-performance industrial machinery. Their extensive portfolio includes a wide range of equipment tailored to meet the diverse needs of various industries, ensuring that clients have access to the latest technology and innovations. Founded on the principles of reliability and expertise, TBM Maschinenhandel GmbH prides itself on its knowledgeable team, which is dedicated to providing exceptional service and support. They understand the unique challenges faced by businesses in today’s competitive landscape and strive to offer solutions that enhance productivity and efficiency. Whether you are looking for new machinery or need assistance with maintenance and repairs, TBM is your trusted partner. In addition to their impressive product offerings, TBM places a strong emphasis on building long-term relationships with clients. Their customer-centric approach ensures that every interaction is focused on understanding and fulfilling the specific needs of each business. By choosing TBM Maschinenhandel GmbH, clients can expect not only top-quality machinery but also a partnership that fosters growth and success in their operations.
