Volpak S-280 D Form, Fill and Seal (FFS) line
| Manufacturer | Volpak |
|---|---|
| Model | S-280 D |
| Year | 1997 |
| Location | Netherlands
|
Offer: Volpak S-280 D — Thermoforming Form-Fill-and-Seal (FFS) line
Overview
Manufacturer: Volpak
Model: S-280 D
Year of manufacture: 1997
Line type: Horizontal thermoforming form, fill and seal
Technical condition: listed as good
Ready configuration: set up to run flat pouches in duplex
Performance and pack size range
This is a thermoforming FFS line intended for horizontal packaging of flat pouches. The moulding dimensions are: moulding length 350.0 mm and moulding width 140.0 mm. The stated pouch size range is a minimum of 70 x 120 mm up to a maximum of 140 x 350 mm. The published maximum capacity is up to 180 pouches per minute.
Control, drive and handling features
The machine is equipped with an Omron PLC and a touchscreen operator interface. Material handling and web control components listed include a reel-edge aligner, a servo-driven unwinder and servo-driven pulling rollers. A photocell is included for registration control.
Sealing, forming and ancillary options
Sealing and forming related items called out in the listing include a double-arm driven bottom-seal bar and four vertical seals. The line also lists a pneumatic emboss coder, two round hole punchers and a front-load transfer arm. Detection and reject functionality specified comprises empty pouch detection, empty pouch reject and a no-pouch/no-fill interlock.
Notes
All specifications and options above are taken from the provided product information. No additional claims about testing, refurbishment or warranty are made.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Offer title: Volpak S-280 D Thermoforming - Form, Fill and Seal Line
Manufacturer: Volpak
Model: S-280 D
Year of manufacture: 1997
Technical condition: good
State: visible
Line type: Horizontal, form, fill and seal
Moulding length: 350.0 mm
Moulding width: 140.0 mm
Pouch size range: Min. 70 x 120 mm; Max. 140 x 350 mm
Capacity: Up to 180 pouches per minute
Ready to run: Flat pouches in duplex
Options: Reel-edge aligner; Servo driven unwinder; Touchscreen; Omron PLC; Servo driven pulling rollers; Pneumatic emboss coder; Photocell; Double arm driven bottomseal bar; Four vertical seal; Empty pouch detection; 2 x round hole puncher; Front load transfer arm; No pouch no fill; Empty pouch reject
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
