Contact us to receive an offer.
| Manufacturer | FLEXPACK |
|---|---|
| Model | NP 185 |
| Year | |
| Location | Spain
|
FLEXPACK NP 185 Horizontal Premade Pouch Filling and Sealing Machine
The FLEXPACK NP 185 is a horizontal machine for filling and heat-sealing premade flexible pouches, including 4-side-seal formats. It is specified for viscous or paste products, with a maximum filling capacity of 1.5 L, two filling heads and an output capacity of 3,000 units per hour. The listed engine power is 3.9 kW.
The machine takes pre-formed pouches through opening, dosing and sealing operations. The existing specification describes intermittent operation and a maximum speed of up to 50 cycles per minute, adjustable, with one pouch per cycle. The dosing arrangement includes a second dosing station for adding a second product to the same pouch. Sealing is provided by horizontal and vertical sealers with independent automatic temperature control. The listed safety functions stop dosing if a pouch does not open and stop the machine in the event of a sealer temperature fault.
Features listed in the description include a monoblock frame in AISI 304 stainless steel, a B&R control system with touchscreen HMI, an interchangeable pouch magazine, vacuum-cup pouch opening, and a dosing funnel. Pouch tensioning before sealing is intended to help prevent wrinkles. Discharge is by gravity through an outlet chute. The listed included equipment comprises one pouch format, mechanical pulling, an adjustable pouch-dispensing belt with step-by-step feed, and front vacuum pick-and-place transfer.
The machine is enclosed by transparent safety panels and has a control interface and stack light. A metal hopper is mounted above the enclosure, with conveyor or transfer sections at the sides. It is shown assembled in an indoor production area, with no obvious damage apparent in the available views; operational condition is not specified.
Additional listed specifications: maximum speed up to 50 cycles/min; pouch size 80 × 110 × 35 mm minimum and 185 × 300 × 90 mm maximum; electrical supply 220/400 V, three-phase, 50/60 Hz plus earth; net weight 1,500 kg; dimensions 2,130 × 1,200 × 2,080 mm (L × W × H).
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Title : Flexpack NP 185 Horizontal Premade Pouch Filling and Sealing Machine – Stand-up / 3-4 side seal
Description :
Horizontal premade pouch machine for liquid and paste products. Starting from pre-formed heat-sealable pouches, it opens, doses and seals stand-up pouches and 3/4-side-seal sachets in horizontal position with intermittent motion.
Technical specifications
Pouch size min. : 80 x 110 x 35 mm (L x H x gusset)
Pouch size max. : 185 x 300 x 90 mm (L x H x gusset)
Max. volume : 1,500 cc
Speed : up to 50 cycles/min (1 pouch per cycle), adjustable
Power consumption : 3.9 kW
Electrical : 220/400 V, 3 Ph, 50/60 Hz + earth
Net weight : 1,500 kg
Dimensions : 2,130 x 1,200 x 2,080 mm (L x W x H)
Design and operation
Monoblock frame in AISI 304 stainless steel, vertical main plate separating mechanics from the filling area (passages protected by silicone bellows)
Main drive by motor-gearbox on main shaft, cam-driven mechanisms
B&R control with touchscreen HMI : cycles/min display, programmable batch counter with machine stop, net production counter, electronic speed variator
Interchangeable pouch magazine, vacuum suction cup opening + funnel for dosing
Second dosing station for a second product in the same pouch
Top tensioning before sealing to avoid wrinkles
Horizontal and vertical sealers with independent automatic temperature control
Gravity discharge via outlet chute
Safety : no pouch opening → no dosing and machine stop ; sealer temperature fault → machine stop. CE safety guards, EMC compliant.
Included : 1 pouch format, mechanical pulling, pouch dispensing belt (adjustable, step-by-step feed), front transfer (vacuum pick & place).
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
