Contact us to receive an offer.
| Manufacturer | Doosan |
|---|---|
| Model | T3600D |
| Year | 2021 |
| Location | United Kingdom
|
Overview
This listing is for a Doosan T3600D vertical machining centre, manufactured in 2021. The machine is configured as a twin-pallet (twin-table) production VMC intended to minimise non-cutting time and maximise spindle utilisation in high-volume, high-speed machining environments.
Spindle and Tooling
The machine is specified with a 12,000 RPM high-speed direct-drive spindle with a BT30 taper. Tool handling is via a 14-position automatic tool changer. A BLUM laser tool measurement system is included for automatic tool measurement and tool breakage detection. Quoted tool change performance is approximately 1.3 seconds tool-to-tool and approximately 3.0 seconds chip-to-chip.
Workholding and Pallet System
The twin-pallet configuration comprises two pallets sized 650 × 375 mm each, with a maximum table load of 200 kg per pallet. Two Granat zero-point clamping systems are specified to provide fast, repeatable workholding and rapid component changeover while one pallet is machined and the other is loaded or unloaded.
Travel and Performance
Travel dimensions are listed as X 520 mm × Y 360 mm × Z 350 mm. Rapid traverse speeds are quoted up to 48 m/min. The machine is described as having rigid cast-iron construction and is controlled by a Fanuc/Doosan CNC control.
Applications and Summary
This Doosan T3600D is presented as a compact, production-optimised twin-pallet machining centre suitable for high-speed, high-volume manufacturing where reduced setup and improved spindle utilisation are priorities. Key specifications and features are provided above; no additional condition, testing status, or service history is stated in the provided information.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
A premium Doosan T3600D Twin Table Vertical Machining Centre engineered for high-volume, high-precision production. Equipped with a 12,000 RPM direct-drive spindle, twin-pallet configuration, high-speed rapid traverses, dual Granat zero-point clamping systems and a BLUM laser tool measurement system, this machine is exceptionally well equipped to minimise setup and non-cutting time while maximising spindle utilisation.
The twin-table system allows one workpiece to be machined while the second pallet is loaded or unloaded, creating an efficient production workflow and significantly increasing throughput.
Key Features
12,000 RPM high-speed direct-drive spindle
Twin Table / Dual Pallet automatic pallet changer
Two Granat zero-point clamping table systems for fast, repeatable workholding and rapid component changeover
BLUM laser tool measurement system for automatic tool measurement and tool breakage detection
Travels: X 520 mm × Y 360 mm × Z 350 mm
Twin tables: 650 × 375 mm each
Maximum table load: 200 kg per pallet
BT30 spindle taper
14-position Automatic Tool Changer
Rapid traverse speeds up to 48 m/min
Tool-to-tool change time approximately 1.3 seconds
Chip-to-chip tool change approximately 3.0 seconds
Rigid cast-iron machine construction
Fanuc/Doosan CNC control
Compact footprint with exceptional production capability
Designed for high-speed, high-volume manufacturing
Production-Optimised Twin-Pallet Configuration
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
