| Manufacturer | Cooling |
|---|---|
| Model | Tunnel |
| Year | |
| Location | Germany
|
| Category | Refrigeration - cooling tunnels |
| Band/belt width | 1300 mm |
| Refrigerant type | freon |
| worked hours | |
| hours under power | |
| state | as-is, where-is |
| At local norms | --------- |
| status | |
| Last availability date | 21/10/2026 |
| Product id | P251212115 |
| Language |
Охлаждащ тунел Cooling Tunnel
Chladící tunel Cooling Tunnel
Cooling Tunnel Kølingstunnel
Cooling Tunnel Kühltunnel
Σήραγγα ψύξης Cooling Tunnel
Cooling Tunnel
Túnel de enfriamento Cooling Tunnel
Tunnel de refroidissement Cooling Tunnel
Tunel za hlađenje Cooling Tunnel
Cooling Tunnel Hűtőalagút
Tunnel di raffreddamento Cooling Tunnel
Aušinimo tunelis Cooling Tunnel
Cooling Tunnel Koeltunnel
Tunel chłodniczy Cooling Tunnel
Túnel de resfriamento Cooling Tunnel
Tunel de răcire Cooling Tunnel
Cooling Tunnel Охлаждающий туннель
Tunel za hlađenje Cooling Tunnel
Cooling Tunnel Kyltunnel
Soğutma tüneli Cooling Tunnel
|
Manufacturer: Cooling
Model: Tunnel
This industrial cooling tunnel conveyor system is designed for efficient air cooling processes, suitable for various production lines requiring controlled temperature environments. The unit features a stainless steel construction, ensuring durability and hygiene in operation. The cooling tunnel measures approximately 2000 mm in length and 420 mm in width, with a belt width of 1300 mm, providing ample space for product handling.
The cooling system offers convection cooling from above, with options for additional bottom cooling, enabling flexible temperature control tailored to specific product requirements. The cooling area maintains temperatures between +6°C and +15°C, supporting a range of cooling needs.
Key technical features include an automatic belt alignment system driven by pneumatic motors located at both the start and end of the conveyor, ensuring precise tracking during operation. Belt tension is also automatically managed via pneumatic motors. The drive system comprises a vulcanized rubber drive drum powered by a 0.75 kW geared motor from Motovario, controlled by a Mitsubishi frequency converter, allowing belt speeds up to 6 meters per minute.
The tunnel is equipped with lengthwise adjustable knife edges and multiple hinged stainless steel covers that open on both sides, supported by gas springs for easy access and maintenance. High-performance polystyrene thermal insulation enhances energy efficiency, while a scraper with a stainless steel chute cleans the belt, facilitating bulk goods handling.
Additional safety and operational features include emergency stop buttons accessible from both sides of the tunnel, a condensate tray with drainage connections beneath the evaporator, and a pneumatic control system housed in a separate cabinet above the conveyor table. The machine is installed indoors on a clean concrete floor, ensuring stable operation.
This cooling tunnel is a robust solution for industrial cooling applications, combining stainless steel durability with advanced pneumatic and electrical controls for reliable and efficient performance.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Manufacturer: Cooling
Model: Tunnel
Total Length: Cooling length + approximately 2000m for inlet and outlet
Cooling Length: By arrangement – standard lengths of 10m, 15m, or 20m
Belt Width Options: 420mm, 620mm, 820mm, 1050mm, 1300mm
Types of Cooling:
- Air cooling from above (convection cooling)
- Air cooling from above (convection cooling) & bottom cooling
Technical Features:
- Convection cooling: 1 air cooler, 1 Freon cooling unit
- Automatic belt alignment via pneumatic motor, mounted at both the beginning and end of the conveyor belt
- Automatic belt tightening via pneumatic motor
- Vulcanized rubber drive drum with variable frequency drive
- Lengthwise adjustable knife edge
- Hoods opened on both sides, equipped with gas springs for raising the hood
- High-performance polystyrene thermal insulation
- Scraper for belt cleaning with stainless steel chute for bulk goods
- Emergency stop buttons on both sides
- Condensate tray under the evaporator with pipe connections for condensate water drainage
- Stainless steel design
- Pneumatic control system housed in a separate cabinet above the table
- 0.75kW geared motor by Motovario
- Frequency converter by Mitsubishi
- Temperature of cooling area: +6...+15°C
- Belt speed: up to 6 m/min
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Machinery dealer |
| Active since | 2019 |
| Offers online | 69 |
| Last activity | Oct. 29, 2026 |
Manufacturer: Cooling
Model: Tunnel
Total Length: Cooling length + approximately 2000m for inlet and outlet
Cooling Length: By arrangement – standard lengths of 10m, 15m, or 20m
Belt Width Options: 420mm, 620mm, 820mm, 1050mm, 1300mm
Types of Cooling:
- Air cooling from above (convection cooling)
- Air cooling from above (convection cooling) & bottom cooling
Technical Features:
- Convection cooling: 1 air cooler, 1 Freon cooling unit
- Automatic belt alignment via pneumatic motor, mounted at both the beginning and end of the conveyor belt
- Automatic belt tightening via pneumatic motor
- Vulcanized rubber drive drum with variable frequency drive
- Lengthwise adjustable knife edge
- Hoods opened on both sides, equipped with gas springs for raising the hood
- High-performance polystyrene thermal insulation
- Scraper for belt cleaning with stainless steel chute for bulk goods
- Emergency stop buttons on both sides
- Condensate tray under the evaporator with pipe connections for condensate water drainage
- Stainless steel design
- Pneumatic control system housed in a separate cabinet above the table
- 0.75kW geared motor by Motovario
- Frequency converter by Mitsubishi
- Temperature of cooling area: +6...+15°C
- Belt speed: up to 6 m/min
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
