Kolbus KM471

Handfeeding station 16 stations gatherer, model ZU804, age 2000 Compressors Setup element Transfer into the binder . Perfect binder, model KM471 21 clamps Vibrating element in feeder Milling station Roughening station Brushing station Hotmelt spine gluing Hotmelt side gluing Premelter LH Gauzing station Cover feeder First pressing station Second pressing station . Trolley wagon delivery Vertical pile delivery Further complete with: Instruction manuals Spare part catalogues Electrical wiring diagrams Technical specifications: Max. book block size : 310 x 390 x 60 mm or 190 x 460 x 60 mm Min. book block size : 100 x 125 x 3 mm Max. mechanical speed : upto 6.000 copies/hour

Consisting of: Gathering Machine ZU 801 - 20 stations - handfeeding station for 1 person - 3x decoupling possibilities of stations when not in use - transfer to the binder with jogging station Ratiobinder KM 470- 20 clamps - infeed with handfeeding station for 2 persons and coupling with ZU 801 - main milling station - 2 roughening and brushing stations - 1 additional brushing station - Hotmelt spine gluing unit - premelter LH with glue level adjustment control - Hotmelt side gluing unit - IR heating at curve - 2 trolleys for interchangeable glue units - stream cover feeder - scoring unit for 4scores - 2 pressing stations - gripper carriage delivery - lay-down device Size range: max. 460 x 190 x 60 mm max. 390 x 310 x 60 mm min. 125 x 100 x 4 mm capacity: up to 6.000 cycles/h. 1 Transport and DryingLine length approx. 50 m, incl. emergency delivery

Consisting of: Gathering Machine ZU 801 Year 1989 - 16 stations - handfeeding for 2 persons - 2 x decoupling possibilities of stations when not in use - transfer to the binder with jogging station Ratiobinder KM470 year 1989 - 20 clamps - infeed for linking-up with ZU - main milling station - 1 roughening and brushing unit - 1 additional brushing station with roller brush - Hotmelt spine gluing unit -Hotmelt side gluing unit - Premelter LH with glue level adjustment control - lining station - rotary cover feeder - scoring unit for 4 scores - pressing station - gripper carriage delivery - lay-down device Size range: max. 460 x 190 x 60 mm max. 390 x 310 x 60 mm min. 125 x 100 x 4 mm Capacity: up to 6.000 cycles/h. 1 KOLBUS Transport- and Drying Line length approx. 20 m Further complete with: Instruction manuals Spare part catalogues Electrical wiring diagrams

Consisting of: Gathering Machine ZU 801 Year 1989 - 16 stations - handfeeding for 2 persons - 2 x decoupling possibilities of stations when not in use - transfer to the binder with jogging station Ratiobinder KM470 year 1989 - 20 clamps - infeed for linking-up with ZU - main milling station - 1 roughening and brushing unit - 1 additional brushing station with roller brush - Hotmelt spine gluing unit -Hotmelt side gluing unit - Premelter LH with glue level adjustment control - lining station - rotary cover feeder - scoring unit for 4 scores - pressing station - gripper carriage delivery - lay-down device Size range: max. 460 x 190 x 60 mm max. 390 x 310 x 60 mm min. 125 x 100 x 4 mm Capacity: up to 6.000 cycles/h. 1 KOLBUS Transport- and Drying Line length approx. 20 m Further complete with: Instruction manuals Spare part catalogues Electrical wiring diagrams

Consisting of: Station Gatherer ZU Hand Feed Unit Reject Unit Ratio 26 Clamp Binder Book Saw Three Knife trimmer Rima Compensating Stacker · Automatic thickness control. · Optoelectronic recognition system so only the correct sections loaded the correct way will be fed through to the binder. · Hand feed station to enable a pre collated set to be added should the job require more than 18 stations. · Automatic removal of incorrect, incomplete or books not “knocked up” correctly without stopping the machine. · Computer controlled touch screen operation with automatic adjustments. · Milling and notching with waste exhaust system. · Cover feeder with 4 scores 2 for the spine and 1 each for front and back hinges. · Pre malting system. · Spine lining station with 1st pressing unit. · 2nd pressing unit for book cover. · Lay flat binding using Cold Glue, Hot Melt or PUR adhesives · Delivery to laydown system. · Counter in the magazine unit. · Shingle stream infeed. · Saw blade monitoring. · Program pre- selection. · Side Jogging. · Speed Synchronisation. · Mounted on castors for ease of moving.

Binding line KM 470 year 2005 1 perfect binder KM 470 Holt Melt 21 clamps 1 infeed station with vibration device Side glue station Premelter station 1 cover feeder station gathering ZU 804 16 stations 1 hand feeder 30 meters conveyors 2 cooling towers 1 trimmer Kolbus inline HD 140 P year 2002 1 stacker SMG MT 320 VF year 2010

• hand feeding station • 20 stations gatherer 801 (1995) • in feed in perfect binder (1992 17 clamps) • spine preparation station • premelter • hotmelt spine glueing • hotmelt side glueing • cold glue spine glueing • cold glue side glueing • cover feeder • 1st pressing unit • 2nd pressing unit • square delivery • lay down delivery • transport system • technical documentation

1986 Kolbus KM470 Perfect Binder w/ 15 clamps-Sn# 44, spine prep, hot melt spine, side glue, nipping station, pile cover feeder, laydown + 1986 Kolbus ZU801 Gatherer w/ 16 pockets + Handfeeding station, tranfer station - Sn# 159

Handfeeding element 12 stations gatherer model 804 Air center/pumps Setup element Tecgraf book block feeder, model XTG250 with extended infeed belt ENDSHEET TIPPING STATION Transfer into the binder Kolbus perfect binder, model KM470 21 clamps Milling and roughening station Hotmelt spine gluing Hotmelt side gluing Premelter Gauzing station Excluding cover feeder First nipping and pressing station Second pressing station Laydown delivery . Size range Kolbus KM470: Max.460 x 190 x 60 mm Max. 390 x 310 x 60 mm Min. 125 x 100 x 4 mm Capacity: up to 6.000 cycles/h. Further complete with: Instruction manuals Spare part catalogues Electrical wiring diagrams

Kolbus 26 Clamp Perfect Binder Kolbus ZU841 12 Station Gatherer Nordsun Pre Melt Nordsun PUR Gluing Signature Recognition 8 x log Loaders Kolbus HD153P Three Knife Trimmer Rima XRS130 Compensating Stacker

Equipped with: Handfeeding for 2 persons 16 stations gatherer model 801 Setup element Transfer into the binder Kolbus perfect binder, model KM470 20 clamp binder Infeed with jogging station Main milling station Roughening and brushing station Additional brushing station with roller brush Hotmelt spine gluing Hotmelt side gluing Premelter model LH Lining station Rotary cover feeder Pressing station Gripper carriage delivery Laydown device . Transport and drying system, approx. 20 meters. Perfecta automatic three knife trimmer, model SD100F, age 1989 With infeed from the left 2 sets of knives Further complete with: Instruction manuals Spare part catalogues Electrical wiring diagrams
