| Manufacturer | ONA |
|---|---|
| Model | NX8 B1 |
| Year | 2008 |
| Location | Spain
|
| Category | EDM (Electrical Discharge Machining) - Die-sinking EDM machines |
| CNC Type | |
| worked hours | |
| hours under power | |
| state | as-is, where-is |
| At local norms | --------- |
| status | |
| Datasheet | ONA NX8 B1 |
| Last availability date | 06/10/2026 |
| Product id | P260901356 |
| Language |
Die-sinking EDM machine — specification summary and equipment details
This listing provides the technical specification set for a die-sinking EDM machine. The information below is limited to the measurements and limits provided in the current description. No statements are made regarding operational condition, testing, or included accessories.
Key specifications:
- X-axis travel: 2000 mm
- Y-axis travel: 1000 mm
- Electrode holder travel (Z-axis): 800 mm
- Maximum electrode weight (standard): 200 kg
- Maximum electrode weight with C-axis (static): 50 kg
- Maximum electrode weight with C-axis (dynamic): 12 kg
- Maximum distance between electrode plate and table (without C-axis): 1200 mm
- Tank dimensions (L x W x H): 2800 x 2300 x 1000 mm
- Table dimensions (L x W): 2200 x 1600 mm
- Maximum table load: 10,000 kg
- Maximum dielectric fluid level: 950 mm
- Maximum workpiece height: 900 mm
- Machine overall height: 3585 mm
- CE compliant
- Approximate weight: 15,000 kg
Notes for prospective buyers:
- The data above reflects the provided specification list. The presence of a C-axis changes allowable electrode weights; static and dynamic limits are listed separately and should be considered when planning electrode size and fixturing.
- Tank and table dimensions, as well as the maximum dielectric fluid level and workpiece height, are included for planning handling, fixturing, and fluid containment arrangements.
- No additional components, condition statements, or operational status claims are included beyond the supplied specifications. Buyers should confirm suitability, condition, and any included accessories with the seller before purchase.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
SN: 11472
X-axis travel: 2000 mm
Y-axis travel: 1000 mm
Electrode holder travel (Z-axis): 800 mm
Maximum electrode weight: 200 kg
Maximum electrode weight with C-axis (static): 50 kg
Maximum electrode weight with C-axis (dynamic): 12 kg
Maximum distance between electrode plate and table (without C-axis): 1200 mm
Tank dimensions: 2800 x 2300 x 1000 mm
Table dimensions: 2200 x 1600 mm
Maximum table load: 10,000 kg
Maximum dielectric fluid level: 950 mm
Maximum workpiece height: 900 mm
Machine height: 3585 mm
CE compliant
Approximate weight: 15,000 kg
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
| Client type | Machinery dealer |
| Active since | 2025 |
| Offers online | 111 |
| Last activity | Oct. 7, 2026 |
