Contact us to receive an offer.
| Manufacturer | CMS |
|---|---|
| Model | Avant 1T/560-TX3/500-RR |
| Year | 2006 |
| Location | France
|
This listing is for a CMS Avant 1T/560-TX3/500-RR wood CNC machining center, manufactured in 2006. The machine features a moving bridge design with two racks and a fixed table during machining, allowing precise and stable operations. It has a welded steel support frame stabilized by double heat treatment, ensuring structural rigidity.
The mobile bridge supports two cross-slide carriages for transverse and vertical movements, providing the following travels: X axis of 5600 mm, Y axis of 2050 mm, and Z axis of 300 mm. The working speeds are up to 60 m/min on the X axis, 100 m/min on the Y axis, and 30 m/min on the Z axis, with positioning speeds matching these maximums.
Equipped with a TX3 vertical head mounted on a Z-TX3/12/L vertical carriage, the spindle delivers 15 kW power at 18,000 rpm, with a programmable rotation speed range from 1,800 to 24,000 rpm, using an HSK63E cone. The tool changer system includes two rotary tool magazines, each with 16 stations, totaling 32 stations. It supports tools with a maximum diameter of 250 mm and blades up to 400 mm.
The machine incorporates eight transverse beams with longitudinal positioning controlled by eight digital axes, and eight digitized transverse positions for clamps and suction pads. Additional features include automatic centralized lubrication, a chip evacuation conveyor, and two dry vacuum pumps. It is controlled by an OSAI S 10/510i numerical control system.
The machine is housed in a yellow and silver casing and appears clean and well-maintained with no visible damage. Multiple tool heads or clamps numbered 1 to 6 are visible on both sides of the machine. Dust extraction hoses are connected on top, and the control panel with screen and keyboard is positioned next to the machining area. The surrounding area is orderly.
The nameplate indicates the machine operates at 400 V ±10%, 3 phases, with a frequency of 50/60 Hz and a current of 80 A. This CNC machining center is suitable for wood processing applications requiring large working areas and flexible tooling options.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Sell 4 Axis CMS with movable bridge, Avant-1/B-560-TX3/RR with digitized table.
Moving bridge design with two racks. Fixed table during machining.
Welded steel support frame stabilized by double heat treatment.
Mobile bridge supporting a set of two cross-slide carriages for transverse and vertical movement.
Travels :
X axis: 5600mm
Y axis: 2050 mm
Z axis: 300 mm
Working and positioning speed:
X axis from 0 to 60 m/min , positioning speed 60m/min
Y axis from 0 to 100 m/min , positioning speed 100m/min
Z axis from 0 to 30 m/min , positioning speed 30m/min
Automatic centralized lubrication
TX3 vertical head with tool changer mounted on Z-TX3/12/L vertical carriage
Head power: 15kw at 18000 rpm
Programmable rotation speed from 1800 to 24000 rpm
HSK63E cone
2 rotary tool magazines with 16 stations each, for a total of 32 stations
Max. tool diameter: 250mm
Max. blade diameter: 400mm
8 transverse beams with longitudinal positioning controlled by 8 digital axes
8 digitized transverse positions for clamps and suction pads
Chip evacuation conveyor
2 dry vacuum pumps
OSAI S 10/510i numerical control
This machine is in perfect working order, serviced once a year by ANTB, and maintained in-house on a daily basis.
We're selling it because we no longer need it, having purchased a new machine with two work zones.
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
Is this CMS Avant 1T/560-TX3/500-RR in working condition?
This CMS Avant 1T/560-TX3/500-RR CNC machining center is in good working condition.
When was this CNC machining center manufactured?
This CNC machining center was manufactured in 2006.
What design features does this CMS Avant 1T/560-TX3/500-RR have?
This CMS Avant 1T/560-TX3/500-RR features a mobile bridge design with two rack and pinion systems.
Does this equipment have a fixed table?
This equipment has a fixed table during machining.
What type of frame does this CNC machining center have?
This CNC machining center has a welded steel frame stabilized by double heat treatment.
What movement capabilities does this CMS Avant 1T/560-TX3/500-RR offer?
This CMS Avant 1T/560-TX3/500-RR includes a mobile bridge supporting two cross-slide carriages for transverse and vertical movement.
What is the travel range of this CNC machining center?
This CNC machining center has a travel range of 5600 mm on the X-axis, 2050 mm on the Y-axis, and 300 mm on the Z-axis.
What are the working speeds of this equipment?
This equipment has a working and positioning speed of 0 to 60 m/min on the X-axis, 0 to 100 m/min on the Y-axis, and 0 to 30 m/min on the Z-axis.
This CMS Avant 1T/560-TX3/500-RR is what type of machine?
This CMS Avant 1T/560-TX3/500-RR is a CNC wood machining center.
The following questions and answers are generated using artificial intelligence based on the product information available. They are provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
