Controller :
Siemens Sinumerik 810 M
Number of axis total
3
Table length
2280 mm
Table width
450 mm
Number of T-channels
3
Distance of the T-slots
150 mm
T-channel width
18 mm
Longitudinal travel (X-axis)
2000 mm
Transversal travel (y-axis)
400 mm
Vertical travel (z axis)
425 mm
Tool changer:
Number of tools
20
Tool diameter
65 mm
Diameter with free adjacent pockets
180 mm
Tool lenght
220 mm
Max. tool-weight
8 kg
Spindle nose SK
40 DIN 69871
Vertical spindle speeds:
stepless
from
20 rpm
up to
10500 rpm
Feeds:
Air connect
6 bar
Voltage 50 Hz 3x
400 Volt
Spindle motor
18 kW
Total power required
31 kVA
Machine's weight about
7200 kg
Overall dimensions machine:
Length
4000 mm
Width
3010 mm
Height
3040 mm
Various accessories:
Coolant system
Chip conveyor
Handwheel electroinic

Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. Exapro recommends to check the details with the seller before a purchase

Axis X 2000 mm
Axis Y 400 mm
Axis Z 425 mm
Rotary table (4th axis) no
Type of CNC Siemens Sinumerik 810 M
Table length 2280 mm
Table width 450 mm
Max. part weight 525 kg
Number of tool pockets 20
Spindle taper SK 40 DIN 69871
Max. spindle speed 10500 rpm
Spindle motor power 18 kW
-------------------
Length x width x height 4000.0 × 3010.0 × 3040.0
Weight 7200 kg
Worked hours
Hours under power
State good
At local norms ---------
Status
Datasheet Chiron FZ 18 L
Client type Reseller
Active since 2014
Offers online 202
Last activity April 17, 2024

Description

Controller :
Siemens Sinumerik 810 M
Number of axis total
3
Table length
2280 mm
Table width
450 mm
Number of T-channels
3
Distance of the T-slots
150 mm
T-channel width
18 mm
Longitudinal travel (X-axis)
2000 mm
Transversal travel (y-axis)
400 mm
Vertical travel (z axis)
425 mm
Tool changer:
Number of tools
20
Tool diameter
65 mm
Diameter with free adjacent pockets
180 mm
Tool lenght
220 mm
Max. tool-weight
8 kg
Spindle nose SK
40 DIN 69871
Vertical spindle speeds:
stepless
from
20 rpm
up to
10500 rpm
Feeds:
Air connect
6 bar
Voltage 50 Hz 3x
400 Volt
Spindle motor
18 kW
Total power required
31 kVA
Machine's weight about
7200 kg
Overall dimensions machine:
Length
4000 mm
Width
3010 mm
Height
3040 mm
Various accessories:
Coolant system
Chip conveyor
Handwheel electroinic

Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. Exapro recommends to check the details with the seller before a purchase


Specifications

Axis X 2000 mm
Axis Y 400 mm
Axis Z 425 mm
Rotary table (4th axis) no
Type of CNC Siemens Sinumerik 810 M
Table length 2280 mm
Table width 450 mm
Max. part weight 525 kg
Number of tool pockets 20
Spindle taper SK 40 DIN 69871
Max. spindle speed 10500 rpm
Spindle motor power 18 kW
-------------------
Length x width x height 4000.0 × 3010.0 × 3040.0
Weight 7200 kg
Worked hours
Hours under power
State good
At local norms ---------
Status
