Price on request
View price| Power in tons | 30 T |
| Metal length | 2500 mm |
| Power | 4000 W |
| Metal width | 1250 mm |
| CNC type | AMNC-F |
| ------------------- | |
| Weight | 27000 kg |
| worked hours | 20000 hours |
| hours under power | 51000 hours |
| state | excellent |
| At local norms | yes |
| status | in production |
| Last availability date | 28/05/2026 |
The Amada EML Z 3510 NT is a versatile combined laser and punch machine designed for industrial metalworking applications. Manufactured in 2008, this model features a robust bridge frame construction and weighs approximately 27,000 kg. It is equipped with a FANUC AF 4000 E resonator delivering a maximum continuous laser power of 4000 W, suitable for precise cutting tasks.
The machine offers a punch force of 300 kN and a working area for combined laser and punch operations measuring 2500 x 1250 mm. It supports metal sheets up to 6 mm in thickness and can handle a maximum table loading weight of 150 kg. The feed rates are 100 m/min in the X-axis and 80 m/min in the Y-axis, with a simultaneous feed rate of 128 m/min and positioning tolerance of ±0.1 mm.
The turret includes 45 stations, with 4 rotating stations, operating at a feed rate of 30 revolutions per minute and capable of up to 780 hits per minute. The punching drive is servo-electric, while the turret and table drives utilize AC servo motors. The working surface features brush tables with a black grid pattern and raised pins to support metal sheets securely.
Control is managed via the AMNC-F CNC system, featuring a 14-inch LCD screen and controlling seven axes (X/YP/YL/Z/T/C). It has a memory capacity of 10 MB Flash ROM and supports data transfer through 3.5" HD, CD-ROM, USB, RS 232, and Ethernet interfaces.
Additional equipment includes a part flap measuring 400 x 1270 mm, air jet vacuum, barcode reader, wedge leveling elements, sheet tilt-up monitoring, "Punch and Forming" capability, four tapping units, lifting brush table, nozzle and lens quick-changing system, automatic focal system, automatic gas pressure adjustment, high-pressure cutting device (CleanCut), aluminum cutting device (AluCut), dust collector, and chiller unit.
The machine is presented in a clean and well-maintained condition, installed indoors on stable support legs. It features a control panel with a computer keyboard and screen displaying machine interface parameters, including operating hours and program information. Safety features include a mounted safety mirror for enhanced visibility and an emergency stop button on the red end panel. Multiple hoses and cables are connected to the machine, indicating readiness for integration into production setups.
This Amada EML Z 3510 NT is suitable for operations requiring combined laser cutting and punching with high precision and efficiency, supported by advanced servo-electric drives and comprehensive CNC control.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Amada EMLZ 3510 NT (P&F) 4000 Watt
Year: 2008 – Installation 2010
Machine hours: about 51.000h/ 20.000h / 9.000h
Technical data:
Control: AMNC-F
Punch force: 300kN
Working area punch operation (XxY): 3050 x 1620 mm
Working area laser operation (XxY): 2550 x 1270 mm
Working area combined operation (XxY): 2500 x 1250 mm
Working area laser axis (Z): 380 mm
Max. material thickness: 6 mm
Max. table loading weight: 150 kg
Feed rate X/Y: 100 / 80 m/min
Simultaneous: 128 m/min
Positioning tolerance : +/- 0,1 mm
Number of stations in turret: 45
Thereof rotating stations: 4
Feed rate turret: 30 1/min
Max. number of hits: 780/min
Type of tables: brush tables
Part flap: 400 x 1270 mm
Machine frame: Bridge frame
Punching drive: servo-electric
Drives turret + table: AC servo motors
Machine weight: 27 to
Laser:
Resonator: FANUC AF 4000 E
Max. continuous laser power: 4000 W
Laser gas consumption: 10 l/h
System principle: half-flying optics
Laser wave length: 10,6 µm
Beam divergence: < 2mrad
Control:
CNC type: AMNC-F
Screen: 14“ LCD
Number of controlled axis: 7 (X/YP/YL/Z/T/C)
Memory capacity: 10 MB Flash ROM
Data mediums: 3,5“ HD, CD-ROM
Interfaces: USB, RS 232, Ethernet
Equipment:
- Part flap 400 x 1270mm
- Air Jet Vacuum
- Barcode reader
- Wedge leveling elements
- Sheet tilt up monitoring
- „Punch and forming“
- 4 times tapping unit
- Lifting brush table
- Nozzle and lense quick changing system
- Automatic focal system
- Automatic gas pressure adjustment
- High pressure cutting device (CleanCut)
- Aluminum cutting device (AluCut)
- Dust collector
- Chiller unit
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
What is the power rating of this Amada EMLZ 3510 NT (P&F)?
This Amada EMLZ 3510 NT (P&F) has a power rating of 4000 Watts.
When was this Amada EMLZ 3510 NT (P&F) manufactured?
This Amada EMLZ 3510 NT (P&F) was manufactured in the year 2008.
The following questions and answers are generated using artificial intelligence based on the product information available. They are provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
